Instructions for Power Supply Maintenance
Version date: 2010.7.23
File Category: Maintenance Guide
Content of this Volume: It mainly describes the troubleshooting of various faults of the power
supply APW8, and how to use the test tool for accurate positioning.
※ The copyright of this article belongs to Bitmain. The article shall solely be reprinted, extracted or used in
any other ways with the permission of the copyright owner. Please contact Bitmain official customer service if
there is any need of reprinting or quoting.
I. Requirements on the Maintenance Platform
1. The constant temperature soldering iron above 80W (soldering temperature: 300-350°C). The tip
soldering iron head is used for soldering chip resistors and capacitors. The blade type soldering iron
head is used for soldering and replacement of plug-in components (soldering temperature: 380-
420°C)
2. The thermal chimney is used for chip disassembly and soldering, be careful not to heat for a long
time to avoid PCB foaming (soldering temperature: 260°C ±2 °C).
3. The AC controllable power supply voltage regulator (output 200-250V, can limit 0-20A current)
is used for APW8 power-on inspection. If there is no such condition, a 100W ordinary light bulb
can also be strung on the AC fire line with mains. Be careful.
4. For electronic load (power 2KW, meet the voltage 0-50V), if there is no such condition, a
resistive load that matches the APW8 can also be made.
5. The multimeter, suction gun, tweezers, V9-1.2 test jig and special power test card firmware (if
there is condition, an oscilloscope can be configured).
6. Flux, lead-free tin wire, water for cleaning panel with anhydrous alcohol; water for cleaning
panel is used to clean flux residue and appearance after maintenance.
7. Thermally conductive silicone grease (2500) is used to repair the thermal conduction between the
MOS and the cooling fin, thermal conductive silicone (704 silica gel) is used for fixing and
covering the glue damage at the original after the repair of the PCBA components
II. Requirements on Maintenance Operations
1. The maintenance personnel must have certain electronic knowledge, more than one year of
maintenance experience, and a certain understanding of the working principle of switching power
supply, and well master the soldering technology.
APW8 Power Supply Maintenance Guide
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the APW8 and is the answer not in the manual?

Questions and answers

Summary of Contents for Antminer APW8

  • Page 1 3. The AC controllable power supply voltage regulator (output 200-250V, can limit 0-20A current) is used for APW8 power-on inspection. If there is no such condition, a 100W ordinary light bulb can also be strung on the AC fire line with mains. Be careful.
  • Page 2 III. The Principle and Structure of the Power Supply 1. Principle overview 1.1 APW8 consists of 1 large panel, 2 fans and the upper and lower enclosures. The normal input AC220V has two DC output voltages, which are SB 12V respectively. The main voltage...
  • Page 3 PIC port and the mining machine communication, and different models’ DC voltage range is (8V-9.2V, 10V-11V, 16.32V-20.04V) 1.2 Performance characteristics and scope of use: S15, T15 with APW8 power supply 16.32V- 20.04V as follows: APW8 power supply is a high-efficiency DC power supply designed and manufactured by our company.
  • Page 4 APW8 Power Supply Maintenance Guide AC Input Air Inlet Note: If you need to turn on the default voltage 16.32V test, you can use the adapter cable to short connect the voltage Pin EN to GND. ● Distribution on the front panel of the power supply: one triangle-shape AC input...
  • Page 5 Definition of 6PIN PCIE terminal positive and negative poles: Positive pole: yellow 1, yellow 2, yellow 3 Negative pole: black 4, black 5, black 6 1.4 Parameters of APW8 Power Supply: DC voltage 16.32V-20.04V (Power on default voltage 15.9V-16.3V) Lower limit 15.9V-16.3V, upper limit 19.95V-20.5V...
  • Page 6 APW8 Power Supply Maintenance Guide Rated current (at 220V input) Ripple and noise <1% Voltage accuracy 12.2V---12.4V Source regulation <1% rate Load regulation <1% rate Startup, rise time <2S Power down >10mS holding time Voltage range 200-240V AC Frequency range...
  • Page 7 APW8 Power Supply Maintenance Guide 基本原理工作流程图:Basic principle work flow chart AC 输入 200V- 240V:AC input of 200V-240V EMI/LC 电路:EMI/LC circuit 整流电路:Rectifier circuit PFC 电路:PFC circuit VBUS 滤波大电容:VBUS filter large capacitor FAN 电路、12V 反馈及 OUTPUT:FAN circuit, 12V feedback and OUTPUT 12V/VCC 电路:12V/VCC circuit 主开关...
  • Page 8 APW8 Power Supply Maintenance Guide DC 同步整流主输出电路:Main output circuit of DC synchronous rectification 12V 及 VC 电路:12V and VC circuits 主开关 MOS:Main switch MOS PWM 主控电路:PWM main control circuit PIC 调控:PIC regulation PFC 电路:PFC circuit 大电容高压滤波储能:Large-capacity high-voltage filter energy storage...
  • Page 9 APW8 Power Supply Maintenance Guide Physical picture, there will be small differences in product versions, but the principle is similar. 2.21 AC inputs EMI to PFC circuit schematic, focus on measuring whether F1 insurance, U2 rectifier bridge, Q4, D7, D5, D6 are damaged.
  • Page 10 APW8 Power Supply Maintenance Guide 2.22 12V auxiliary circuit principle, focus on measuring whether voltage detection starts resistor R33, 47K and connecting with HV to D1, D2, and whether Q5, D8, D9, T1 is damaged. 高电压输入:High voltage input 电压检测启动:Voltage detection starts 12V 主开关...
  • Page 11 APW8 Power Supply Maintenance Guide 12V 正常时,PFC 大电容 370-380V 电压正常,自动开 VCC12V 主控制供电:When 12V is normal, the PFC large capacitor 370-380V voltage is normal, and the VCC12V main control power supply is automatically turned on 2.23 The main control PWM drive circuit, PIC control voltage regulation schematic diagram, focus on the main IC VCC power supply and drive transformer.
  • Page 12 APW8 Power Supply Maintenance Guide OLP 过载保护:OLP overload protection 主控全桥开关 MOS 电路:Master control full bridge switching MOS circuit 注:如只有 2 个 MOS 为半桥电路:Note: If there is only 2 MOS, it is a half-bridge circuit 主 变 压 器 转 换 同 步 MOS 整 流 滤 波 :Main transformer conversion synchronous MOS rectification filter DC 输出电路: DC output circuit...
  • Page 13 APW8 Power Supply Maintenance Guide Figure 1 SMD patch side location Figure 2 Plug-in side location...
  • Page 14 APW8 Power Supply Maintenance Guide 2.3 Maintenance steps 2.31. Check whether the appearance of the power supply is seriously damaged or deformed, and whether the DC fan and the AC socket are damaged. 2.32. Power on AC220V, check whether the fan is rotating normally, and use the multimeter to measure whether the output J6 terminal’s voltage is 12V (12.1V-12.50) to eliminate measuring...
  • Page 15 APW8 Power Supply Maintenance Guide (一)测试设备:功率计、万用表、电子负载、或者其他同类型自动测试仪器。(DC 输出正常时,如没有负载也可以用带矿机测试)。 (1) Test equipment: power meter, multimeter, electronic load, or other similar automatic test equipment. (When the DC output is normal, it can be tested with a mining machine if there is no load).
  • Page 16 TEST11 与 TEST7 负 极万 用 表 量 测 VCC 12-13V: TEST11 and TEST7 negative multimeters measure VCC 12-13V 2.41 Diagram for S15 control panel V1.2 and APW8 power PIC port connection test, label 1 is the dedicated card test firmware, 2 is the DC voltage debugging high-low conversion button, 3 is the PIC communication port, 4 is the control panel socket, 5 is 12V power supply;...
  • Page 17 APW8 Power Supply Maintenance Guide stops outputting again. Output is normal, the fan The fan is faulty 1. Check if the fan is blocked by debris does not work 2. The fan is faulty The normally working Overcurrent protection Check whether the current of the load exceeds the upper limit of the...
