- Page 1 INSTALLATION & USER GUIDE For Connecting Four/Six Pairs of Speakers to an Amplifier or Receiver S-4 / S-6 SPEAKER SELECTION SYSTEM...
-
Page 2: Table Of Contents
S-4 / S-6 SPEAKER SELECTION SYSTEM TABLE OF CONTENTS Features...1 Product Overview...2 Package Contents ...3 Preparing for Installation...3 Installation...3 Operation...5 Specifications ...7 Warranty...7... -
Page 3: Features
FEATURES S-4: Safely connect up to four speaker pairs to a single amplifier or receiver S-6: Safely connect up to six speaker pairs to a single amplifier or receiver High power handling capability Built-in protection circuit Compatible with all 4 ohm capable amplifiers or receivers Non-skid feet for unit stability Includes customized room labels Installation friendly design:... -
Page 4: Product Overview
PRODUCT OVERVIEW Recessed areas for custom room labels. Attractive low- profile design. Simple push-button operation. In/On Out/Off Connect up to four pairs of Protection switch safeguards your speakers. receiver or amplifier even with all 4 pairs of speakers playing. Removable screwless connectors. -
Page 5: Package Contents
PACKAGE CONTENTS S-4 S-4 x 1 Room/Zone labels x 1 PACKAGE CONTENTS S-6 S-6 x 1 Room/Zone labels x 1 PREPARING FOR INSTALLATION The Speaker wires and Amplifier wires must reach the proposed location of the S-4/S-6 Speaker Selector. Mark the cables with Wire labels, describing where the cables originate from, rather than where they will terminate. - Page 6 10. Locate the pre-printed Room Labels. Affix the appropriate label to the recessed area over each on/off selector button. See installation diagram. INSTALLATION DIAGRAM Stereo Receiver Speaker Speaker Speaker Pair 4 Pair 3 Pair 2 JobSite S-4 Back Speaker Pair 1...
-
Page 7: Operation
OPERATION Playing One Pair of Speakers At a Time: 1. Make sure the amplifier or receiver power is OFF and set the volume to minimum. 2. Locate the on/off button on the unit’s front panel, which corresponds to the speaker pair you wish to play. - Page 8 3. Locate the on/off buttons on the S-4/S-6, which correspond to the speaker pairs you wish to play. Set them to the ON position. 4. Turn on the amplifier or receiver and select a source, such as the tuner or CD player. 5.
-
Page 9: Specifications
S-6: 11-1/2" wide x 2" high x 6-3/4" deep Warranty: 10 year limited LIMITED WARRANTY JobSite Systems (“JOBSITE”), a Niles Audio Corporation company, warrants its passive products (those not requiring AC or battery power) to the original purchaser to be free of manufacturing defects in material and workmanship for a period of ten years from date of purchase. - Page 10 SHIPPING INSTRUCTIONS FROM JOBSITE. If the above conditions are met, the purchaser’s sole remedy shall be to return the product to JOBSITE, in which case JOBSITE will repair or replace, at its sole option, the defective product without charge for parts or labor.
- Page 11 This warranty gives you specific legal rights, and you may also have other rights, which vary from state to state. For the name of the nearest authorized JOBSITE wholesale distributor, contact: JobSite Systems 12331 S.W.
- Page 12 WWW.JOBSITESYSTEMS.COM © 2004 JobSite Systems. All rights reserved. JobSite, Pure Custom and Niles are registered trademarks of Niles Audio Corporation and the JobSite Logo is a trademark of Niles Audio Corporation. All other trademarks are the property of their respective owners. Some JobSite products (or components thereof) are manufactured under one or more U.S.
