Page 2
IP201 Contents Montage Anschluss Konfiguration Ethernet-Anschluss Installation Platzierung von Leuchtdioden (Ausschnitt des Moduls) Status-Leuchtdioden 7.1 Action 7.2 Wink 7.3 Err 7.4 Wartungstaste Port B Modulübersicht Kamstrup A/S • 5512937_C1_GB_05.2017...
Page 3
NAT (Network Address Translation). 3 Configuration The IP201 module is always supplied configured with either default IP settings or custom IP settings. These settings can be changed subsequently by using IP Tool, which can be obtained by contacting Kamstrup.
Page 4
For connection directly to PC (also possible on hub, switch, etc. with auto sense of crossed connection): Terminal no. T-568B colour code 114 / Green / White 115 / Green Orange / 116 / White 117 / Orange Termnial number. Silk screen print on 5550844 rev. G. Ethernet connection Kamstrup A/S • 5512937_C1_GB_05.2017...
Page 5
3 The Err diode starts flashing when the host is recognised (meter or concentrator have been detected). 4 The Err diode turns off when the module has been registered by the collecting server. If the module cannot connect to the meter and/or server, IP201 will restart. Start-up ACT/LINK...
Page 6
The Err diode is used for indicating irregularities. Steady light: The module has just started and is waiting for an IP address. Flashing: The module has not yet recognised the unit in which it is mounted (the host) Turned off: Normal situation. Kamstrup A/S • 5512937_C1_GB_05.2017...
Page 7
IP201 7.4 The service button The service button is used by Kamstrup in connection with service and reprogramming of the module. 8 Port B Port B is a serial (RS232/Kamstrup 3-wire) connection that can be used for connecting additional external equipment.
