OPTIC ALIGNMENT
The VEDO180PRO photocells can be horizontally adjusted to over 180°.
Slacken screw 3 in figures 1 and 2, rotate the internal parts of the
photocells until they are out of alignment, then carefully tighten the screws.
The red led of the receiver (detail 9 fig. 1) is on when the photocells are
aligned.
Slight vertical alignment differences are compensated by a self-centring
lens system.
FINAL ADVICE
Do not perform any wiring or modifications to the connections prior to
having isolated the power supply.
The non-observance of the said instructions could prejudice the correct
function of the equipment.
TELCOMA decline any responsibility for possible malfunction and/or da-
mage due to their non-observance.
TELCOMA srl reserve the right to make modifications at any time they
deem necessary in order to improve the aesthetical and/or functional
aspect of the product.
