PARTS DESCRIPTION
Fig.1
1. Transmitter connection terminal boards
1 and 2 power supply
3 synchronisation connection
2. Fixing holes
3. Internal body fixing screws
4. Led lit when transmitter power is ON
5. Transmitter synchronisation dip-switch (no.1, no.2 and no.3)
6. Cable inlet
7. Receiver connection terminal boards
1 and 2 power supply
3 and 4 relay contact
8. Relay output type selection jumper:
a.: normally open contact
b.: normally closed contact
9 Led lit when transmitter and receiver are aligned
10 Receiver synchronisation dip-switch (no.1, no.2 and no.3)
