OVERVIEW
This device is a combo 2.4GHz Wireless mini QWERTY
mini keyboard and Touch Pad combo with USB interface
receiver. In addition to standard keyboard functionality,
this device offers multimedia control keys and PC gaming
control keys. It has a built-in programmable smart touch
pad. This touchpad can be used in horizontal and vertical
directions. It also has power indicator, RF signal indicator,
CAPSLOCK light, low-voltage indicator and keypad back-
light to facilitate the use in dark environments.
In addition, this mini keyboard is also a universal infrared
remote controller with learning function. The remote control
is very effective at identifying unknown format with a wide
and reliable range of learning formats which means about
99.9% TV infrared remote control on the market can be
learned .After learning, the signals can be transmitted with
a high precision wide learning range of 20kHz~60kHz and
a small frequency error of (±1kHz).
Touchpad
The touchpad can be used in a horizontal or vertical posi-
tion. To switch between horizontal or vertical mode, hold
the Fn key and hit the Alt key.
Wireless 2.4G receiver
Connecting the receiver
Take out the 2.4G dongle from the giftbox, and insert
to the device into a standard USB interface. Once con-
nected, slide the power switch to the "ON"
position located on the left side of the unit to establish
the connection.
Enabling the backlight
Once the keyboard has established a connection to the
receiver, the backlight keys will automatically turn on for
3 seconds. The backlight will turn off after 3 seconds to
preserve battery life. To manually turn the backlight on,
simply press the key with light bulb symbol on upper left
hand corner.
Auto sleep and wake feature
The keyboard also features an auto sleep and auto
wake mode. If there is a long period of inactivity, the
keyboard will automatically go into a sleep mode. Dur-
ing the sleep mode, the user can wake the unit up by
pressing any key. The 2.4 GHz receiver and keyboard's
RF indicator will continue to flash and will not power
down
