Installation/Connection
Installing the unit (in-dash mounting)
1
2
Hook on the top side
Orientate the trim
plate as illustrated
before fitting.
Do the required wiring.
(Page 32)
Dashboard of your car
Bend the appropriate tabs to hold the sleeve
firmly in place.
Installing the unit (without mounting sleeve)
1 Remove the mounting sleeve and trim plate from the unit.
2 Align the holes in the unit (on both sides) with the vehicle mounting
bracket and secure the unit with supplied screws.
Use only the specified screws. Using wrong screws might damage the
unit.
Removing the unit
1 Detach the faceplate.
2
Remove the trim plate.
3
Insert the extraction keys deeply into the slots on each side, then
follow the arrows as shown on the illustration.
31
