120800
ASSEMBLY INSTRUCTION
4UHX1
30" Slide Bar with Fixed Shower Head,
Adjustable Hand Held Shower & Diverter
4UHX1
REMOVAL OF FAUCET:
Always turn the water supply off before removing the existing faucet or disassembling a valve. Open both faucet handles to relieve water pressure
and to ensure that the water has been successfully turned off.
CARE OF FAUCET:
The use of warm water and a soft cloth is all that is required to clean Rubinet products. The patina of our living fi nishes (Oil Rubbed Bronze &
Tuscan Brass) will change as a result of normal use. Applying Mineral Oil on occasion will create a softer look, subtle color changes and character.
