MANUTENZIONE
Per la normale pulizia si
consiglia di utilizzare
detergenti di uso comune.
Si sconsiglia l'utilizzo di
detergenti abrasivi, acidi e
anticalcare.
NOTA
La ferramenta in dotazione
permette Il ssaggio del
lavabo su pareti in mattoni
pieni o forati e in
calcestruzzo.
Per pareti in cartongesso è
necessario rinforzare
adeguatamente la zona
interessata ed
eventualmente adottare
sistemi di ssaggio speci ci.
ISTRUZIONI DI MONTAGGIO
ASSEMBLY INSTRUCTIONS
MAINTENANCE
For normal cleaning use
common detergents.
Do not use either abrasive
detergents or solvents, acids
and anti limestone.
NOTE
The assembly material
supplied allows the
installation of the washbasin
on solid and hollow brick
walls and on concrete walls.
For plasterboard walls it is
necessary to reinforce
adequately the area
concerned and to adopt
speci c xing systems if
necessary.
Lavabo / Washbasin
CARRARA
ACER0730S
Lavabo indipendente in marmo bianco di Carrara
Indipendent Washbasin in white Carrara marble
1/5

Advertisement

loading
Need help?

Need help?

Do you have a question about the CARRARA ACER0730S and is the answer not in the manual?

Questions and answers

Summary of Contents for agape CARRARA ACER0730S

  • Page 1 ISTRUZIONI DI MONTAGGIO ASSEMBLY INSTRUCTIONS Lavabo / Washbasin CARRARA ACER0730S Lavabo indipendente in marmo bianco di Carrara Indipendent Washbasin in white Carrara marble MANUTENZIONE MAINTENANCE Per la normale pulizia si For normal cleaning use consiglia di utilizzare common detergents. detergenti di uso comune. Do not use either abrasive Si sconsiglia l'utilizzo di detergents or solvents, acids...
  • Page 2 ISTRUZIONI DI MONTAGGIO ACER730S - CARRARA ASSEMBLY INSTRUCTIONS COD. VERS. 00320 20141202/3 - SV CONTENUTO DELLA CONFEZIONE STRUMENTI PACKAGE CONTENTS TOOLS ø 8 (5/16) supporti Viti M5x10 ssaggi lavabo support screw xing washbasin trasparente - antimu a nastro adesivo di carta. masking tape.
  • Page 3 ISTRUZIONI DI MONTAGGIO ACER730S - CARRARA ASSEMBLY INSTRUCTIONS ø 8 (5/16”) 624 (24”9/16) 160 (6”5/16) 400 (15” 3/4) Scarico al centro Drain in the center...
  • Page 4 ISTRUZIONI DI MONTAGGIO ACER730S - CARRARA ASSEMBLY INSTRUCTIONS ø 8 (5/16”) 90°...
  • Page 5 ISTRUZIONI DI MONTAGGIO ACER730S - CARRARA ASSEMBLY INSTRUCTIONS Applicare un adeguato strato di silicone tra il lavabo e la parete. Apply a suitable quantity of silicone between washbasin and wall. STOP 24 h.
