ENHANCE SPECTRA E11 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SPECTRA E11
User Manual
（ Version 1.0 ）

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPECTRA E11 and is the answer not in the manual?

Questions and answers

Related Manuals for ENHANCE SPECTRA E11

Summary of Contents for ENHANCE SPECTRA E11

  • Page 1 SPECTRA E11 User Manual （ Version 1.0 ）...

  • Page 2: Attentions

    Attentions This manual details functions, installation, operation principles and methods of teacher tracking camera. Please read this manual carefully before installation and use. How to use In order to prevent this product or products connected to it from being damaged, please use it within its prescribed scope of use. 1) Keep the device from rain or moisture.

  • Page 3: Table Of Contents

    Magnetic field interference Magnetic field under specific frequency may affect this product image; this is Class A product. Application in domestic environment may cause radio interference. Therefore, user should take corresponding measures. Content ATTENTIONS..............................1 1. FAST INSTALLATION..........................4 1.1 CAMERA INTERFACE EXPLANATION.....................4 1.2 POWER-ON INITIAL CONFIGURATION..................
  • Page 4 3.2.2 APPLICATIONS........................14 3.3 MENU SETTING...........................16 3.3.1 MAIN MENU........................16 3.3.2 SYSTEM SETTING......................17 3.3.3 CAMERA SETTING......................17 3.3.4 P/T/Z..........................20 3.3.5 VERSION.......................... 21 3.3.6 RESTORE DEFAULT......................21 4. SERIAL COMMUNICATION CONTROL....................22 4.1 VISCA PROTOCOL LIST......................22 4.1.1 CAMERA RETURN COMMAND..................22 4.1.2 CAMERA CONTROL COMMAND..................25 4.1.3 INQUIRY COMMAND.....................

  • Page 5: Fast Installation

    1. Fast Installation 1.1 Camera Interface Explanation Photo 1.1 Interfaces Interface： 1. Camera Lens 5. Locating Hole 9. USB 2.0 Interface 2. Remote Controller 6. RS232 Control Interface (input ) 10. DC12V Input Power Supply Socket Receiver Light 3. Camera Base 7.

  • Page 6: Video Output

    1.3 Video Output This camera have video output from USB2.0 a. Network Cable Connection Port: As Photo 1.1 Label 9 showed b. Connect the camera and the computer via USB2.0 video cable, open video conference software, select image device, and then video output will be available. 1.4 Bracket mount Note: Bracket can only be wall mounted or upside down mounted on template and concrete wall, but can not be installed on plasterboard.

  • Page 7: Installatin

    Upside down mount step...

  • Page 8: Product Overview

    2. Product overview 2.1 Product Introduction 2.1.1 Product Model There are two main series according to different optical zoom lens. As the Photo 2.1 showed Model NO.X—XXXX 03 --- 3X Optical Zoom Lens 10 --- 10X Optical Zoom Lens Photo 2.1 Camera Model Please refer to corresponding features in this manual.

  • Page 9: Accessory

    2.1.3 Accessory When you unpack, check that all the supplied accessories are included: Model NO. Configuration Power adapter 1 piece USB2.0 cable 1 piece Standard User manual 1 piece IR Remote controller 1 piece Accessory Rubber pad Warranty card 1 piece Optional Wall mounting bracket Upside-down mounting bracket...

  • Page 10: Technical Specification

    2.3 Technical specification Model Camera Parameter Sensor 1/2.9 inch high quality HD CMOS sensor 16: 9 2.07 megapixel H264/H265/MJPG:1920×1080P@30/25/20/15/10/5fps；128720P@30/25/20/15/10/5fps； 960*540@30/25/20/15/10/5fps； 800*600@30/25/20/15/10/5fps； 720*576@30/25/20/15/10/5fps； 720*480@30/25/20/15/10/5fps； 640*480@30/25/20/15/10/5fps； 640*360@30/25/20/15/10/5fps； 352*288@30/25/20/15/10/5fps；320*240@30/25/20/15/10/5fps； Effective Pixels YUY2:1280*720@10/5fps; 800*600@10/5fps; 640*480@30/25/20/15/10/5fps; Video Format 640*360@30/25/20/15/10/5fps; 320*180@30/25/20/15/10/5fps View Angle 34.1°(tele)-- 85°(wide) 8.8°(tele)--66°(wide) Optical Zoom f=3.35mm～10.05mm f=4.34mm～41.66mm...

  • Page 11: Interface Instruction

    Preset Speed Pan: 60°/sec, Tilt: 40°/sec Preset Number 255 presets (10 presets by remote controller) Other Parameter Supply Adapter AC110V-AC220V to DC12V Input Voltage DC12V±10% Input Current 4.98A(Max) Consumption 2.5W (Max) -10℃ to + 70℃ Store Temperature Store Humidity 20% - 90% Working Temperature -10℃...

  • Page 12: Rs-232 Interface

    2.4.2 RS-232 Interface 1) RS-232 interface specification as shownbelow Computer or keyboard and camera connectionmethod WindowsDB-9 Camera 1.DCD 2.RXD 3.TXD 4.DTR 5.GND 6.DSR IR OUT 7.RTS 8.CTS 2) RS-232 Mini-DIN 8-pin Port Definition Port Definition Data Terminal Ready Data Set Ready Transmit Data System Ground Receive Data...
  • Page 13 3) RS232 (DB9) Port Definition Definition Port Data Carrier Detect Receive Data Transmit Data Data Terminal Ready System Ground Data Set Ready Request to Send Clear to Send Ring Indicator 4) VISCA networking as shown below: Camera cascade connection method Camera 1 Camera 2 1.DTR...

  • Page 14: Application Instruction

    3. Application Instruction 3.1 Video Output 3.1.1 Power-On Initial Configuration Connecting the power, the camera will have initial configuration, R indicator light will be flashing. When the camera return to the HOME position (middle position for P/T) and the lens finish zooming in/out, the auto-testing is finished.

  • Page 15: Keys Introduction

    3.2.1 Keys Instruction 1. Standby Key After a 3-second long press, the camera will step into standby mode. Long press for 3- second again, then the camera will self-test and back to HOME position. (Note: If the power is on and Preset 0 is set, and there is no operation within 12s, it will automatically point to the specified preset position.
  • Page 16 2. When a key-combination is required, do it in sequence. For example,“ 【 * 】 + 【 # 】 + 【 F1 】 ”means press“【*】”first and then press“【#】” and last press“【F1】”. 1) Camera Selection Select the camera address to control. 2) Pan/Tilt Control press Down: press...

  • Page 17: Menu Setting

    4) Zoom Control ZOOM IN: press “ZOOM “ key ZOOM OUT: press “ZOOM ” key Press and hold the key, the camera will keep zooming in or zooming out and stops as soon as the key is released. 5) Focus Control Focus (near):Press “【focus+】”...

  • Page 18: System Setting

    MENU ＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝ Language English (Setup) (Camera) (P/T/Z) (Version) (Restore Default) [↑↓]Select [← →]Change Value [Menu]Back [Home]OK LANGUAGE: Language setting, Chinese / English SETUP: System setting CAMERA OPTION: Camera setting PTZ OPTION: Pan tilt setting VERSON: camera version setting Restore Default: Reset setting [↑↓] Select: for selecting menu [←...
  • Page 19 Auto flip: On/Off 3.3.3 Camera Setting Move the pointer to the (CAMERA) in the Main Menu, click the【HOME】key and enter the (CAMERA) as follow, CAMERA ＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝ (Exposure) (Color) (Image) (Focus) (Noise Reduction) Style Default [↑↓]Select [← →]Change Value Back EXPOSURE: Enter into Exposure setting COLOR: Enter into color setting Image: Enter into image setting Focus: Enter into focus setting...
  • Page 20 Anti-Flicker: OFF/50Hz/60Hz for options (only available in Auto/Iris priority/Brightness priority modes) Gain Limit: 0~15(only available in Auto/ Iris priority /Brightness priority mode) WDR: Off, 1-8 Shutter Priority:1/25, 1/30, 1/50, 1/60, 1/90, 1/100, 1/120, 1/180, 1/250, 1/350, 1/500, 1/1000, 1/2000, 1/3000, 1/4000, 1/6000, 1/10000 (only available in Manual and Shutter priority mode) IRIS Priority:OFF,F11.0,F9.6,F8.0,F6.8,F5.6,F4.8,F4.0,F3.4,F2.8,F2.4,F2.0,F1.8(only available in Manual and Iris priority mode)
  • Page 21 IMAGE ＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝ Brightness Contrast Sharpness Flip-H Flip-V B&W-Mode Color Gamma Default Close Low-Light Mode [↑↓]Select [← →]Change Value [Menu]Back Brightness: 0~14 Contrast: 0~14 Sharpness: 0~15 Flip-H: On/Off Flip-V: On/Off B&W Mode: color, black/white Gamma: default, 0.45, 0.50, 0.55,0.63 DCI: Dynamic Contrast: Off,1～8 Super Low Illumination:On/Off 4) FOCUS Move the pointer to the (FOCUS) in the Menu, click the【HOME】and enter the (FOCUS) as follows:...

  • Page 22: P/T/Z

    NOISE REDUCTION ＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝ NR-2D NR-3D Dynamic Hot Pixel [← →]Change Value [↑↓]Select [Menu]Back 2D Noise Reduction: Auto, close, 1~7 3D Noise Reduction: Close, 1~8 Dynamic Hot Pixel: Close, 1~5 3.3.4 P/T/Z Move the pointer to the (P/T/Z) in the Main Menu, click the【HOME】and enter the (P/T/Z) as follows: P/T/Z ＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝...

  • Page 23: Restore Default

    3.3.6 Restore Default Move the pointer to the (RESTORE DEFAULT) in the Main Menu, click the 【 HOME 】 and enter the (RESTORE DEFAULT) as follows: RESTORE DEFAULT ＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝ Restore Default? [↑↓]Select [← →]Change Value [Menu]Back [Home]OK Restore default: options: yes/no; after restoring default, the video format won’t be restored. Note: If the address of the former remoter is not 1, but another one from 2, 3, and 4, the corresponding camera address will go back to 1 when all parameters or system parameters are restored.
  • Page 24 Returned when the command format is different or when a Syntax Error z0 60 02 FF command with illegal command parameters is accepted Returned when a command cannot be executed due to current Command Not Executable z0 61 41 FF conditions.
  • Page 25 Command Function Command packet Note Direct 8x 01 04 43 00 00 0p 0q FF pq: R Gain Reset 8x 01 04 04 00 FF 8x 01 04 04 02 FF Manual Control of B Gain CAM_ Bgain Down 8x 01 04 04 03 FF Direct 8x 01 04 44 00 00 0p 0q FF pq: B Gain...

  • Page 26: Camera Control Command

    Command Function Command packet Note Reset 8x 01 04 3F 00 pq FF pq: Memory Number(=0 to 254) CAM_Memory 8x 01 04 3F 01 pq FF Corresponds to 0 to 9 on the Remote Commander Recall 8x 01 04 3F 02 pq FF 8x 01 04 61 02 FF CAM_LR_Reverse Image Flip Horizontal ON/OFF...

  • Page 27: Inquiry Command

    Command Function Command packet Note 8x 01 06 07 01 0W YYYY: Pan Limit Position(TBD) Clear 07 0F 0F 0F 07 0F 0F 0F FF ZZZZ: Tilt Limit Position(TBD) 4.1.3,Inquiry command Command Function Command packet Note y0 50 02 FF CAM_PowerInq 8x 09 04 00 FF y0 50 03 FF...

  • Page 28: Pelco-D Protocol Command List

    CAM_IDInq 8x 09 04 22 FF y0 50 0p FF p: Gamma ID y0 50 02 FF IR_ReceiveInq 8x 09 06 08 FF y0 50 03 FF y0 07 7D 01 04 00 FF Power ON/OFF y0 07 7D 01 04 07 FF Zoom tele/wide y0 07 7D 01 04 38 FF AF ON/OFF...

  • Page 29: Pelco-P Protocol Command List

    Focus Far 0xFF Address 0x00 0x80 0x00 0x00 Focus Near 0xFF Address 0x01 0x00 0x00 0x00 Stop 0xFF Address 0x00 0x00 0x00 0x00 Set Preset 0xFF Address 0x00 0x03 0x00 Preset ID Clear Preset 0xFF Address 0x00 0x05 0x00 Preset ID Call Preset 0xFF Address...

  • Page 30: Camera Maintenance And Troubleshooting

    Response Byte Query Zoom Position 0xA0 Address 0x00 0x55 0x00 0x00 0xAF Query Zoom Position Value Low 0xA0 Address 0x00 0x5D Value High Byte 0xAF Response Byte 5. Camera Maintenance and Troubleshooting Camera Maintenance 1) If the camera is not used or will not be used for a long time, please turn off the power adapter switch and AC plug. 2) Use a soft dry cloth or tissue to clean the camera cover.

  • Page 31: Modification Record

    c. Check whether the camera’s working mode is in the normal operating mode. (see Table 2.2 and Table 2.3) 6. Modification record Table 1 document modification record New Version Proofreader Date Modification 2018/ V1.0 03/12 7. Copyright Notice All the contents of this manual and the copyright ownership belong to the company. No one shall imitate, copy, reproduce or translate this arbitrarily without the approval of the company.
