Retina RET1028 User Manual

RET1028
Retina Weather Proof Color Camera
with SONY High Resolution CCD Sensor & On-Screen Adjustability
INTRODUCTION
The RET1028 color camera employs the latest SONY technology optical components.
This high definition stability camera provides strong anti-jamming, rich and real color.
Easy to install and convenient to use. It will adapt to most CCTV systems. Please read
this instruction manual carefully to ensure proper use of the product.
WARNINGS
To prevent fire or shock hazard, do not expose the unit to prolonged
contact with water.
This symbol is intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the literature
accompanying the application.
This symbol is intended to alert the user to the presence of uninsulated
"dangerous voltage" within the product's enclosure that may be of
sufficient magnitude to constitude a risk of electrical shock to persons.
CAUTION
Risk of Electrical Shock DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK DO NOT REMOVE COVER
OR BACK. NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
CAUTION: TO PREVENT ELECTRICAL SHOCK AND RISK OF FIRE HAZARDS, DO NOT
USE OTHER THAN SPECIFIED POWER SOURCE.
CAUTION
Risk of Damaging Camera
CAUTION: PLEASE NOTE THE CAMERA'S OPERATING TEMPERATURE AND ENVIRON-
MENT REQUIREMENTS. AVOID USING THE CAMERA AT EXTREME TEMPERATURES.
CAUTION: NEVER POSITION THE CAMERA TO FACE THE SUN OR A BRIGHT OBJECT.
THIS MIGHT DAMAGE THE CCD.
CAUTION: DO NOT MOUNT THE CAMERA NEAR A HEAT SOURCE.
CAUTION: USE ONLY THE RECOMMENDED POWER SUPPLY.
CAUTION: WHEN USING THE CAMERA IN LIGHTNING CONDITIONS, BE SURE TO
INSTALL A SURGE – PROTECTION DEVICE, OR DISCONNECT POWER SUPPLY PLUG
AND CABLE.
CAUTION: IN ORDER TO CAPTURE HIGH QUALITY PICTURES, THE POWER SUPPLY'S
CABLE AND VIDEO OUTPUT CABLE SHOULD NOT BE TOO LONG.
USER MANUAL
IN THE BOX
(1) RET1028 Weather Proof Color Camera
(1) User Manual
PRODUCT OVERVIEW
Sensor (CCD)
SONY 1/3" High Resolution CCD Sensor
Auto Gain Control (AGC)
Built-in auto gain control (AGC) circuit. The color camera can provide high definition
picture in low light conditions.
Scanning Mode
NTSC or PAL mode.
On-Screen Adjustability
The camera has a built-in OSD with an easy-to-use adjustment controller that gives you
complete control over the picture.
CONNECTIONS
Video
Link wire rule：
Video
Moniter
Power
12V DC
RET1028
DC 12V Power Supply
*sold separately
