Fortin PATS 1 Installation Manual

PATS 1
Copyright © 2006, FORTIN AUTO RADIO INC
PATS KIT 1 FOR FORD & MAZDA
WIRING / CONNECTION GUIDE WIRING / CONNECTION GUIDE
2
1
START HERE
1
Vehicle harness
Connector 1 (Black):
Remove the covers surrounding the ignition barrel.
Peel off the adhesive back of the ring, place it on the ignition barrel.
(Secure the wire with tie-wrap.)
Connector 2 (White):
2
Connect the red wire to 12V constant
Connect the black wire to "Ground out when running".
#1
3
You have 5 seconds to complete the following procedure
#1
4
#2
VEHICLE FITGUIDE VEHICLE FITGUIDE
VEHICLES YEARS OF VEHICLE COMPATIBILITY
Ford
1996 1997
Contour
Crown Victoria
Excursion
Expedition
Explorer
F150
F250
F350
Heavy Truck
Mustang
Ranger
Taurus
Windstar
TECHNICAL SUPPORT / INFORMATION TECHNICAL SUPPORT / INFORMATION
Neither the manufacturer or distributor of this module is responsible of damages of
any kind indirectly or directly caused by this module, except for the replacement of this
module in case of manufacturing defects. This module must be install by qualified
technician. This instruction guide may change without notice. isit www.ifar.ca to get
latest version.
PATENT PENDING : Canada : 4,419,697
ALL RIGHTS RESERVED
1
Red
Black
Blue
3
ANTENNA (RING)
Connect wire to vehicle
INSTALLATION AND PROGRAMMING INSTRUCTIONS INSTALLATION AND PROGRAMMING INSTRUCTIONS
FORD PATS
Insert first key into ignition barrel
and turn the ignition ON
ignition ON until the security light
turns OFF .
Turn the key to the OFF position and
remove the first key from the barrel.
Insert the second key into the
ignition barrel and turn it to the
ignition ON.
Keep the ignition ON until the
security light turns OFF.
1998 1999 2000 2001 2002
V
USA : 60/449.414
12V Battery (+)
(-) While running
N.C
Connect wire to Remote-Starter/Alarm
You have 10 seconds to complete the following procedure
5
. Keep the
Theft
6
Note : If you try to start the engine with a improperly programmed
PATS, you will have to turn the ignition On for more than 1 minute to
reset the system.
VEHICLES
2003 2004
Lincoln
Blackwood
Continental
Navigator
Town Car
Mazda
B3000
B4000
Mercury
Cougar
Grand Marquis
Mountaineer
Mystique
Sable
Technical support:
TEL: 514-255-2720
FAX: 514-255-1367
Web: www.ifar.ca
INSTALLATION GUIDE
Made in Canada - V1.0.d - October 26, 2006
W e b s i t e : h t t p : / / w w w . i f a r . c a
X2
Two (2) functional keys required.
Keep the keys separate while
programming.
Each step must be completed in
the indicated delay, otherwise the
PATS Kit will not be programmed
therefore it is necessary to restart
the procedure.
#2
Turn the key to the OFF position and
remove the second key from the
barrel.
Activate the remote starter with the
PATS Kit connected.
The PATS Kit is now
programmed.
If the programming procedure is
successful, the engine will be running
and the
If the programming procedure is not
successful, the engine may run but
the Theft light will flash. If so you
must repeat from Step 3.
YEARS OF VEHICLE COMPATIBILITY
1996 1997 1998 1999 2000
1996 1997 1998 1999 2000
1996 1997 1998 1999 2000
OUTPUT INPUT
Theft light will turn OFF.
2001 2002 2003 2004
2001 2002 2003 2004
2001 2002 2003 2004
