PREMIUM ELECTRIC
CHAINSAW SHARPENER
INSTRUCTION BOOKLET
PLEASE READ CARE AND SAFETY INSTRUCTIONS BEFORE USE
www.swartstools.com.au

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SWB1705 and is the answer not in the manual?

Questions and answers

Summary of Contents for Swarts Tools SWB1705

  • Page 1 PREMIUM ELECTRIC CHAINSAW SHARPENER INSTRUCTION BOOKLET PLEASE READ CARE AND SAFETY INSTRUCTIONS BEFORE USE www.swartstools.com.au...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS Version 2.0 1. WARRANTY 2. SPECIFICATIONS 3. CONTENTS OF BOX 4. SAFETY INSTRUCTIONS 5. PARTS DIAGRAM 6. SETTING UP THE CHAINSAW SHARPENER 7. SETTING THE GRINDING ANGLE 8. SETTING THE VICE ANGLE 10. SETTING THE TILT ANGLE 11.
  • Page 3: Warranty

    This warranty is in lieu of all other warranties expressed or implied. No representative is authorised to assume for the seller any other liability in connection with the seller’s products. SPECIFICATIONS Item number: SWB1705 Max speed: 3000RPM Rated voltage: 240V - 50Hz Cord length: 1.5m...
  • Page 4: Safety Instructions

    Do not use any aftermarket accessory for this product, unless approved by Swarts Tools.This product may only be serviced by Swarts Tools or by an authorised repair centre. 1. KEEP WORK AREA CLEAN. Cluttered areas invite injuries.
  • Page 5 29. Check wheel for fissures and cracks and test for normal operation prior to use. 30. Only use grinding wheels recommended by Swarts Tools. 31. Always ease the abrasive wheel against the work piece when starting to grind. A harsh impact can break the wheel.
  • Page 6: Parts Diagram

    PART DIAGRAM SWB1705 1. TOP MOTOR SECTION 7. CHAIN BACK STOP 2. BASE 8. REAR BACKSTOP ADJUSTMENT SCREW 3. DEPTH STOP ADJUSTMENT KNOB 9. BACKSTOP ADJUSTMENT LOCKING KNOB 4. LOCKING NUT 10. CHAIN VICE LOCKING LEVER 5. MOUNTING NOTCHES 11. VICE LOCKING KNOB...
  • Page 7: Setting Up The Chainsaw Sharpener

    SETTING UP THE CHAINSAW SHARPENER SWB1705 ALWAYS CHECK YOUR GRINDING WHEELS PRIOR TO USE: CHECK FOR CRACKS, DEBRIS OR CHIPS. DO NOT USE THEM IF THEY APPEAR THIS WAY! MOUNTING & ASSEMBLY It is important to ensure this tool is securely mounted to a sturdy bench or upright post, using the bolts provided.
  • Page 8: Setting The Grinding Angle

    SETTING THE GRINDING ANGLE SWB1705 1. Loosen the locking knob at the back of the machine 2. Tilt the top motor section (1) to the right until your reach your desired angle 3. Re-tighten the locking knob SETTING THE VICE ANGLE 1.
  • Page 9: Setting The Back Top

    SETTING THE BACK STOP SWB1705 1. Release the chain vice locking lever (10) 2. Place the chain into the track, ensuring it can move freely forwards and backwards 3. Lower the chain backstop (7) and pull the chain firmly up against it...
  • Page 10: Sharpening The Chain

    SHARPENING THE CHAIN SWB1705 NOTE: ensure that you do not place your whole weight on the machine or force it down. Only minimal pressure is required, so that the wheel is only just skimming the surface of the tooth 2. Carry out a test grind on one tooth and adjust accordingly any setting angles if required 3.
  • Page 11: Standart Chain Size Chart

    STANDART CHAIN SIZE CHART SWB1705...
  • Page 12 SWB1705...
  • Page 13 SWB1705...
  • Page 14 www.swartstools.com.au...
