Summary of Contents for Clarion EA1276
- Page 1 Owner’s manual CeNET iPod INTERFACE ® Clarion Co., Ltd. All Rights Reserved. Copyright © 2006: Clarion Co., Ltd. Printed in Malaysia 280-8370-00...
-
Page 2: Table Of Contents
Contents 1. INTRODUCTION ... 3 2. CAUTION ... 3 3. CONNECTION ... 4 4. INSTALLATION ... 5 Using Velcro or Double-Sided Tapes ... 5 Using Screw ... 5 5. iPod CONNECTION ... 6 Start-up ... 6 Disconnecting ... 6 6. MAIN FEATURES ... 6 Playback ... -
Page 3: Introduction
Clarion, For list of main unit compatible to EA1276, please ® consult your nearest Clarion dealer. For iPod operations, please refer to your iPod Owner’s Manual. -
Page 4: Connection
3. CONNECTION Please consult your nearest Clarion dealer before attempting to connect EA1276 to your main unit and iPod. Improper connection might damage your main unit, EA1276 , iPod or your vehicle wiring. Please make sure the Yellow wire ( Bus power lead ) is connected on the CeNET compatible Main Unit ( This wire usually has a 3 Amp Fuse inserted ) connects to battery. -
Page 5: Installation
4. INSTALLATION There are no moving parts in EA1276. However, caution must be taken to ensure minimum damage to the unit. Do not press, puncture or drop the unit at anytime. Install the unit where there is no direct sunlight, away from vents or high moisture areas and away from other vehicle electronic components. -
Page 6: Ipod Connection
Disconnecting iPod automatically switches “on” after connecting to EA1276, and it’s battery is charged as long as it stays connected with the vehicle ignition key turned to ACC or ON. To switch off iPod manually, disconnect from EA1276 adaptor. - Page 7 Supported Operation Here are the operations supported by EA1276 and can be controlled through the main unit. • iPod Menu mode • Category Direct • Play/Pause • Song (Track) Up/Down • Fast Forward or Fast Backward functions • All Song Play mode •...
-
Page 8: Playlist
However, “On-the-go” playlist which is created by the iPod itself will not be supported. When iPod is connected to EA1276 and main unit, main unit will search for available playlist. 7. USABLE iPod MODELS iPod 4th Generation ( Software Version 3.1 or higher ) . -
Page 9: 10. Specifications
Current Consumption: Less than 1 A Weight: 0.5 kg Dimensions (Figure 1): 100 mm (Width) x 30 mm (Height) x 110 mm (Depth) 11. IDENTIFICATION OF PARTS EA1276 Owner’s manual CeNET cable (2.5 m) iPod Connection Cable (2 m) Parts bag •...
