PART 1: INTRODUCTION
T
his manual contains useful information for the safe and
efficient operation of your Peterbilt Model 387. It also pro-
vides information on maintaining your vehicle in the best
condition, with an outline for performing safety checks and
basic preventive maintenance inspections.
We have tried to present the information you'll need to
learn about your vehicle's functions, controls, and opera-
tion—and to present it as clearly as possible. We hope
you'll find this manual easy to use.
Please remember, though—this manual is not a training
manual. It can't tell you everything you need to know
about driving your Peterbilt vehicle. For that you need a
good training program or truck driving school. If you have
not been trained, get the proper training before you drive.
Only qualified drivers should drive this vehicle.
There will be times when you need to take this manual out
of your Peterbilt. When you do, please be sure to return it
to the cab when you are finished using it. That way it will
be there when you need it the next time or when you pass
the vehicle on to the next user.
(R10/06)
PART 1: INTRODUCTION
How To Find What You Want
There are several tools built into this manual to help you
find what you need quickly and easily.
First is the Quick Table of Contents. Located at the front
of the manual, this lists the main subjects covered and
gives page numbers where you can find these subjects.
Use the Quick Table of Contents to find information on a
large subject like "Maintenance."
Cross-referenced citations also help you get the informa-
tion you need. If some other part of the manual contains
further information on the subject you are reading about,
we'll indicate that in a cross-reference like this: (See
"PART 6: DRIVER'S
searching for more information.
Finally you'll find a helpful Subject Index. It's in the back
of the manual and alphabetically lists the subjects cov-
ered. So if you want information on brakes, for example,
just look under Brake in the Subject Index. You'll find all
the pages listed where brakes or braking are discussed.
Y53-6007
HOW TO FIND WHAT YOU WANT
CHECKLIST"). You won't have to go
– 3 –

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 387 and is the answer not in the manual?

Questions and answers

Related Manuals for Peterbilt 387

Summary of Contents for Peterbilt 387

  • Page 1 There will be times when you need to take this manual out of the manual and alphabetically lists the subjects cov- of your Peterbilt. When you do, please be sure to return it ered. So if you want information on brakes, for example, to the cab when you are finished using it.

  • Page 2: A Special Word About Repairs

    Peterbilt. If you are missing any of these manuals, ask your Peterbilt dealer to supply them. – 4 –...
  • Page 3 PART 1: INTRODUCTION WARNINGS Your Model 387’s glove box also contains a copy of the WARNING! When you see this symbol & word, the message that follows is especially vital. Truck Driver’s Handbook, published by the American This signals something that can cause seri- Trucking Association.

  • Page 4: Vehicle Safety

    WARNING! Something that could injure you seriously. cannot tell you everything you need to know about driving your Peterbilt vehicle. For that you need a good training CAUTION: Something that could cause injury to you program or truck driving school. If you have not been or your vehicle.
  • Page 5 PART 2: GETTING INTO & OUT OF THE CAB AND FRAME ACCESS PART 2: GETTING INTO & OUT OF THE CAB AND FRAME ACCESS Be careful whenever you get into or out of your vehicle’s cab. Always maintain at least three points of contact with your hands on the grab handles and your feet on the steps.

  • Page 6: Door Lock And Keys

    DOOR LOCK AND KEYS PART 2: GETTING INTO & OUT OF THE CAB AND FRAME ACCESS WARNING! To lessen the chance and/or sever- ity of personal injury in case of an accident, always lock the doors while driving. Along with using the lap/shoulder belts properly, locking the doors helps prevent occupants from being thrown from the vehicle.
  • Page 7 PART 2: GETTING INTO & OUT OF THE CAB AND FRAME ACCESS DOOR LOCK AND KEYS Press the UNLOCK button once. The driver's door will 2. Remove the battery. unlock and the parking lights will come on for 40 sec- 3.

  • Page 8: Climbing Onto The Deck Plate

    NOTE: Any alteration (adding bulkheads, head- the area behind the cab. Peterbilt did not ache racks, tool boxes, etc.) behind the cab or intend for the area to be a step if handrails sleeper that affects the utilization of grab handles, or proper steps are not provided.
  • Page 9 PART 2: GETTING INTO & OUT OF THE CAB AND FRAME ACCESS CLIMBING ONTO THE DECK PLATE Three points of contact as you reach the deck area Hold handles as you step up Three points of contact as you step to the deckplate Three points of contact (R10/06) Y53-6007...
  • Page 10 CLIMBING ONTO THE DECK PLATE PART 2: GETTING INTO & OUT OF THE CAB AND FRAME ACCESS – 12 – Y53-6007 (R10/06)

  • Page 11: Part 3: Getting To Your Engine

    PART 3: GETTING TO YOUR ENGINE HOOD TILT PART 3: GETTING TO YOUR ENGINE Hood Tilt Follow this procedure to tilt the hood. WARNING! Before opening or closing the hood, be sure there are no people or objects in the way. A hood could hurt someone in the way of its opening or descent.
  • Page 12 HOOD TILT PART 3: GETTING TO YOUR ENGINE 2. Grasp the lever and turn it towards you. The hood will WARNING! If the hood falls, anyone under it could be injured. Always ensure that a hood is release and pop open to a neutral position, approxi- fully tilted open any time anyone gets under a mately 2”...

  • Page 13: Part 4: Controls And Displays

    Your Instrument Panel Please remember that each Model 387 is custom-made. Your instrument panel may not look exactly like the one in the pictures that follow.

  • Page 14: Left Side

    YOUR INSTRUMENT PANEL PART 4: CONTROLS AND DISPLAYS Typical Cab Instruments and Controls LEFT SIDE 1. ID/Clearance Lamps Switch 10. Air Cleaner Restriction 2. Ignition Switch 11. Primary Air Pressure 3. Headlamps Switch 12. Secondary Air Pressure 4. Voltmeter 13. Fuel 5.
  • Page 15 PART 4: CONTROLS AND DISPLAYS YOUR INSTRUMENT PANEL RIGHT SIDE 1. Parking Brake Valve 12. Engine Brake 2. Trailer Air Supply Valve 13. Engine Brake 3. Heater/AC Control Panel 14. Load Lights Switch 4. Fog Lights Switch 15. Interaxle Differential Lock Switch 5.
  • Page 16 STEERING COLUMN-MOUNTED CONTROLS PART 4: CONTROLS AND DISPLAYS Steering Column-Mounted Controls Your turn signal lever is mounted on the left side of the steering column below the steering wheel. Green direc- Turn Signal and Indicator Lights tional indicator lights appear on the instrument panel. NOTE: The ignition key must be turned to ON for the signal/switch to operate.

  • Page 17: Hazard Flasher

    PART 4: CONTROLS AND DISPLAYS STEERING COLUMN-MOUNTED CONTROLS Hazard Flasher Pull it out to activate the system. All turn signals will flash at once. To turn it off, move the turn signal lever up or down. WARNING! Use your Hazard Flasher Warning System any time you have to stop off the road or on the side of the road, day or night.

  • Page 18: Electric Horn

    Air Horn All Peterbilt vehicles come equipped with a combination Your Model 387 has an air horn in addition to an electric turn signal and high beam/low beam switch. To switch horn. Control the air horn by pulling on the lanyard extend- your headlights lower or higher, gently pull the turn signal ing from the overhead header panel.

  • Page 19: Trailer Brake Hand Valve

    PART 4: CONTROLS AND DISPLAYS STEERING COLUMN-MOUNTED CONTROLS Trailer Brake Hand Valve To operate the trailer brake hand valve: pull down on the lever under the right side of the steering wheel. See the Index, under Brake Safety and Emergency for more complete information on when and how to use your trailer brake WARNING!

  • Page 20: Tilt/Telescoping Steering Column

    TILT-TELESCOPING STEERING COLUMN PART 4: CONTROLS AND DISPLAYS Tilt-Telescoping Steering Column WARNING! Adjusting the Tilt-Telescoping Steering Wheel while the vehicle is in motion could cause loss of control. You would not be able to steer properly and could have an acci- dent.

  • Page 21: Ignition Switch

    PART 4: CONTROLS AND DISPLAYS DASH-MOUNTED FEATURES Ignition Switch • IGN & ACC: This position allows you to turn on the engine and all accessory power. • START: Starter activation to start engine. Headlights IGN & ACC ACC ONLY START 02890 The headlights are controlled by the control panel switch 02977A...
  • Page 22 DASH-MOUNTED FEATURES PART 4: CONTROLS AND DISPLAYS WARNING! Do not use daytime running lights 2. To brighten the instrument panel lights, turn the knob (DRL) during periods of darkness or reduced clockwise (to the right). visibility. Do not use DRL as a substitute for 3.
  • Page 23 PART 4: CONTROLS AND DISPLAYS DASH-MOUNTED FEATURES When your clearance lights are turned on, you may blink Fog/ Driving Lights Switch or flash them by operating the flash switch located on the right side of the dash showing the symbol below. Press and release this rocker switch to flash your clearance lights.

  • Page 24: Dome Light Switch

    DASH-MOUNTED FEATURES PART 4: CONTROLS AND DISPLAYS Dome Light Switch – Press a third time: Light will turn off. Windshield Wipers and Washers 02896 Wiper To turn on the wipers rotate the knob to the right. As the 02894A knob is rotated, the speed of the wipers increases. To turn off the wipers, rotate the knob to the left.

  • Page 25: Air Suspension Deflate Switch (Dump Valve)

    Intermittent Windshield Wiper Control 03035 Two-speed intermittent windshield wipers are controlled Your Model 387 may have an air suspension deflation by the control panel knob with the symbol shown above. switch that allows the air in the suspension to be To turn on the wipers, rotate the knob to the right.

  • Page 26: Engine Fan Switch

    DASH-MOUNTED FEATURES PART 4: CONTROLS AND DISPLAYS CAUTION: Operating a vehicle with air sus- fan switch in the AUTOMATIC position, the engine fan will pension bags either overinflated or underin- automatically turn on when the engine coolant reaches a f l a t e d m ay c a u s e d a m a g e t o d r i v e l i n e °...

  • Page 27: Mirror Heat Switch

    PART 4: CONTROLS AND DISPLAYS DASH-MOUNTED FEATURES Mirror Heat Switch Power Mirror Switch The power mirror control controls the adjustment of the right or left outside mirrors, depending on the option 03022 selected. It is located in the driver side armrest. Mirror heat is controlled by the control panel switch shown NOTE: The Power Mirror Switch does not control above.

  • Page 28: Cruise Control Switch

    DASH-MOUNTED FEATURES PART 4: CONTROLS AND DISPLAYS Cruise Control Switch NOTE: Cruise control functions and features may vary depending upon which engine you have. For specific explanation of your cruise control, see the cruise control or engine manual included with your vehicle.
  • Page 29 PART 4: CONTROLS AND DISPLAYS DASH-MOUNTED FEATURES The ON/OFF toggle switch turns the system ON or OFF. If your vehicle is equipped with a two-speed rear axle, you can select the axle range by the dash mounted switch • In Caterpillar- Cummins-powered vehicles...

  • Page 30: Fifth Wheel Lock (Slider Adjustment) Switch

    DASH-MOUNTED FEATURES PART 4: CONTROLS AND DISPLAYS UNLOCK the differential. The guard over this switch pre- Vehicles having an air slide fifth wheel have a fifth wheel vents you from accidentally activating the lock. See “Inter- slider lock controlled by a switch on the instrument panel. axle Differential”...

  • Page 31: Parking Brake Valve And Trailer Air Supply Valve

    PART 4: CONTROLS AND DISPLAYS DASH-MOUNTED FEATURES Parking Brake Valve and Trailer Air Supply WARNING! Valve • Do not leave the cab without applying the parking brake. The truck could roll and cause an injury accident. Always apply the parking brake before you leave the cab. •...
  • Page 32 DASH-MOUNTED FEATURES PART 4: CONTROLS AND DISPLAYS WARNING! Never drive your vehicle with the CAUTION: Never idle your vehicle for pro- parking brake applied. Always release the longed periods of time if you sense that parking brakes prior to moving the vehicle. exhaust fumes are entering the cab .
  • Page 33 PART 4: CONTROLS AND DISPLAYS DASH-MOUNTED FEATURES NOTE: Do not stay in the vehicle with the engine To Set the Heater-Air Conditioning Controls running or idling for more than 10 minutes with The cab’s control panel may have up to six controls (see the vehicle’s Heater / AC ventilation system in illustration below): RECIRC or at LOW FAN SPEED.
  • Page 34 DASH-MOUNTED FEATURES PART 4: CONTROLS AND DISPLAYS • A rocker switch (E) on the lower center portion to send • A rotary knob in the right portion controlling the air power to the “bunk” or sleeper control panel. temperature. • A rocker switch (F) in the lower right portion to select 02981B either fresh or recirculated air mode.
  • Page 35 PART 4: CONTROLS AND DISPLAYS DASH-MOUNTED FEATURES portant for you to follow the instructions per- • To cool the cab, turn on the A/C switch, set the tem- t a i n i n g t o t h e f u n c t i o n a n d u s e o f t h e perature knob to cool (the blue position on the con- ventilation/heating and defogging/defrosting trol), and the blower to high until the cab becomes...

  • Page 36: Cigarette Lighter

    DASH-MOUNTED FEATURES PART 4: CONTROLS AND DISPLAYS 6. After the cab temperature cools to a comfortable level, To operate your lighter, push the knob in. After a few adjust the blower speed and controls to keep the moments the lighter will automatically pop out, ready to desired condition.
  • Page 37 PART 4: CONTROLS AND DISPLAYS GAUGES Glove Compartment Gauges On the pages that follow you will find descriptions of some of the gauges on your instrument panel. For more infor- mation about using them in driving, see “PART 7: START- ING &...
  • Page 38 GAUGES PART 4: CONTROLS AND DISPLAYS Speedometer-Message Center (SMC) A Select/Reset switch on the right side of the dash con- trols the display. The odometer is normally displayed on the screen. To choose another function, press and release the Select switch until it appears.
  • Page 39 PART 4: CONTROLS AND DISPLAYS GAUGES NOTE: Neither the odometer nor the hourmeter e. Press & release the Reset switch; the min- can be reset. utes digits will stop flashing. The clock is now set. 1. Turn the ignition switch to ON. •...
  • Page 40 GAUGES PART 4: CONTROLS AND DISPLAYS – To deactivate the buzzer when the alarm Tachometer sounds, press & release the Select switch. (Note: The alarm will automati- cally deactivate after 60 seconds.) NOTE: When the ignition is OFF, the SMC will be in a “sleep”...
  • Page 41 PART 4: CONTROLS AND DISPLAYS GAUGES Air Application Gauge The primary gauge shows the front reservoir air pressure: 11458 1146 This gauge will show you how much air pressure is being The secondary gauge shows rear reservoir pressure. applied from your foot brake valve or trailer brake hand valve.
  • Page 42 GAUGES PART 4: CONTROLS AND DISPLAYS WARNING! The air pressure warning light and Engine Oil Pressure Gauge the audible alarm indicate a dangerous situa- tion. There is not enough air pressure in the reservoirs for repeated braking and the brake system has failed.

  • Page 43: Water Temperature Gauge

    PART 4: CONTROLS AND DISPLAYS GAUGES • If your oil pressure suddenly drops while you are driv- and 210° - 225° F (99° and107° C), depending on the ing, bring the vehicle to a stop as soon as possible in engine.

  • Page 44: Fuel Gauge

    GAUGES PART 4: CONTROLS AND DISPLAYS Wait until the coolant temperature is below 122° F (50° C). Return the idle speed to normal after 2 or 3 minutes. If Protect your face, hands, and arms by covering the cap the warning light doesn’t go off or the temperature with a large, thick rag to protect you against escaping fluid gauge doesn’t begin to drop, then turn the engine off.
  • Page 45 PART 4: CONTROLS AND DISPLAYS GAUGES WARNING! Do not remove a fuel tank cap near an open flame. Hot fuel vapors are combusti- ble and can cause an explosion or fire result- ing in injury or death . The fuel gauge shows the approximate amount of fuel in 09091 the fuel tanks.

  • Page 46: Transmission Temperature Gauge

    GAUGES PART 4: CONTROLS AND DISPLAYS The warning lights may indicate something is wrong with Transmission Temperature Gauge one of the vital systems on your vehicle. Check the lights frequently, and respond properly as soon as you see one go on. These lights could save you from a serious acci- dent.

  • Page 47: Manifold Pressure Gauge

    PART 4: CONTROLS AND DISPLAYS GAUGES Front Drive Axle or Rear Drive Axle vary, depending upon the axle and type of lubricant. Very high temperatures signal a need to have your axle(s)’ Temperature Gauge lubrication checked. Manifold Pressure Gauge 11425 CAUTION: Driving with very hot temperatures in your rear drive axles can cause serious 11453-1...
  • Page 48 GAUGES PART 4: CONTROLS AND DISPLAYS Pyrometer den changes in engine operating temperature. See your engine owner’s manual for maximum temperature recom- mendations. Voltmeter 11467 Your vehicle may be equipped with a pyrometer gauge. The pyrometer gauge indicates engine exhaust gas tem- 11497 perature.

  • Page 49: Shift Pattern Display

    PART 4: CONTROLS AND DISPLAYS GAUGES Air Filter Restriction Indicator Gauge CAUTION: Continued operation with the Air Filter Re-striction Gauge reading 25” H O may cause damage to the engine. Inspect the filter and replace if necessary. Holes in the paper element render an air cleaner useless and may cause the Air Filter Restriction Gauge to give a false reading, even if the element is...

  • Page 50: Luggage Compartment(S)

    GAUGES PART 4: CONTROLS AND DISPLAYS Your vehicle is equipped with outside mirrors to enable Appliances in the Cab you to see to the sides and behind your vehicle. Be sure You may decide to equip your vehicle with a radio, a refrig- they are adjusted properly before you drive off.
  • Page 51 PART 4: CONTROLS AND DISPLAYS GAUGES NOTES: • To turn the refrigerator and cooling fan on, move the REFRIG/FAN switch to ON, then turn the thermostat • For additional information about the refrigera- dial (located inside the refrigerator) clockwise from tor, refer to the refrigerator owner’s manual that the OFF setting.
  • Page 52 GAUGES PART 4: CONTROLS AND DISPLAYS – 54 – Y53-6007 (R10/06)

  • Page 53: Part 5: Seat And Restraint Systems

    PART 5: SEAT AND RESTRAINT SYSTEMS SEAT PART 5: SEAT AND RESTRAINT SYSTEMS Seat Seat Belts And Their Proper Use For information on the features and adjustment of the Seat (or safety) belts have proven to be the single most seat, see the seat manufacturer’s literature included with effective means available for reducing the risk of serious the vehicle.

  • Page 54: Shoulder Belt

    SEAT BELTS AND THEIR PROPER USE PART 5: SEAT AND RESTRAINT SYSTEMS • The lap portion should be worn as low on the hips as possible 02998 Person In Crash, Unbelted Shoulder Belt Your combination shoulder-lap belt needs proper adjust- ment: Properly worn belt –...
  • Page 55 PART 5: SEAT AND RESTRAINT SYSTEMS SEAT BELTS AND THEIR PROPER USE • The shoulder portion should fit snugly across your body. It should always be worn over the shoulder next to the door. It you put the belt under your arm, it can’t protect you properly.
  • Page 56 SEAT BELTS AND THEIR PROPER USE PART 5: SEAT AND RESTRAINT SYSTEMS • Be sure, also, that your belt is not too loose. A loose belt could allow you to slide under it in an accident, and that could bring the belt up around your abdo- men.
  • Page 57 5. When you want to get out of the cab, release the latch, then just push the button on the buckle. Your Peterbilt contains a feature designed to eliminate cinching and provide improved safety and comfort. Cinch- Pregnant Women: Sometimes pregnant women worry ing is the condition where a belt becomes continually that in a crash the seat belt could hurt the baby.

  • Page 58: Sleeper Bunk Restraints

    SEAT BELTS AND THEIR PROPER USE PART 5: SEAT AND RESTRAINT SYSTEMS CAUTION: To avoid damage when lifting a bunk, remove all items from the top of the bunk mattress, and arrange bedding so that items will not slide down the mattress and fall behind the bunk.
  • Page 59 You will notice that if your Peterbilt has an upper bunk, it has no restraint device. This is because no one should ever be in an upper bunk when the vehicle is moving.

  • Page 60: Tether Belts

    • Before driving or riding in a vehicle, ensure • If any seat belt is not working properly, see an autho- that there is adequate head clearance at rized Peterbilt dealer for repair or replacement. maximum upward travel of seat. Serious – 62 –...
  • Page 61 PART 5: SEAT AND RESTRAINT SYSTEMS INSPECTION OF THE RESTRAINT SYSTEM injury may occur if head clearance is not • In typical passenger vehicle automotive seat belt adequate. Shorten the tether belt as neces- applications, the normal life of the vehicles is usually 8 sary to provide adequate head clearance.
  • Page 62 INSPECTION OF THE RESTRAINT SYSTEM PART 5: SEAT AND RESTRAINT SYSTEMS • Environmental conditions represent another major dif- WARNING! It is important to remember that any time a vehicle is involved in an accident, ference in the systems in automobiles and heavy duty the entire seat belt system must be replaced.
  • Page 63 PART 5: SEAT AND RESTRAINT SYSTEMS INSPECTION OF THE RESTRAINT SYSTEM ical places where the web will experience cutting or abrasion. Cuts, fraying, or excessive wear would indi- cate the need for replacement of the seat belt system. 2. The D-loop web guide is the area where almost con- stant movement of the seat belt webbing occurs because of relative movement between the seat and the cab.
  • Page 64 INSPECTION OF THE RESTRAINT SYSTEM PART 5: SEAT AND RESTRAINT SYSTEMS 5. Inspect the retractor web storage device, that is 8. Check web in areas exposed to ultraviolet rays from mounted on the floor or B-pillar of the vehicle for dam- the sun.
  • Page 65 PART 5: SEAT AND RESTRAINT SYSTEMS INSPECTION OF THE RESTRAINT SYSTEM the original components that were removed. This will system has been developed and tested specifically for this maintain the design integrity of the mounting points for the vehicle. If the vehicle was originally equipped with a lap seat belt assembly.
  • Page 66 INSPECTION OF THE RESTRAINT SYSTEM PART 5: SEAT AND RESTRAINT SYSTEMS – 68 – Y53-6007 (R10/06)

  • Page 67: Safe Vehicle Operation

    For more information, you can refer to Federal Motor Car- Much has gone into the manufacturing of your Peterbilt, rier Safety Regulation 392.7 which tells you that interstate including advanced engineering techniques, rigid quality commercial motor vehicles are not to be driven unless the control, and demanding inspections.

  • Page 68: Approaching The Vehicle

    SAFE VEHICLE OPERATION PART 6: DRIVER’S CHECKLIST WARNING! Do not drink and drive . Your 3. Check for damaged, loose, or missing parts. Are there reflexes, perceptions, and judgment can be parts showing signs of excessive wear or lack of lubri- affected by even a small amount of alcohol.
  • Page 69 PART 6: DRIVER’S CHECKLIST SAFE VEHICLE OPERATION 7. Check the power steering fluid reservoir; top up as 6. Check emergency flashers and exterior lamps. necessary. 7. Check the fuel tanks. Is there enough fuel? Are the 8. Check the steering components (pitman arm, dra- tank caps secure? glink, power steering hoses, etc.) WARNING!
  • Page 70 SAFE VEHICLE OPERATION PART 6: DRIVER’S CHECKLIST 11. Is the trailer spare wheel secure? Inflated? INTO & OUT OF THE CAB AND FRAME ACCESS” of this manual for more informa- 12. Is the landing gear up and the handle secured? tion.
  • Page 71 PART 7: STARTING & OPERATING THE VEHICLE NORMAL TEMPERATURE STARTING PROCEDURE PART 7: STARTING & OPERATING THE VEHICLE Since each Model 387 is custom-equipped, all engine 4. Turn the key switch to ON. operation instructions in this manual are general. You will •...

  • Page 72: Cold Temperature Starting Procedure

    COLD TEMPERATURE STARTING PROCEDURE PART 7: STARTING & OPERATING THE VEHICLE CAUTION: Never operate the starter motor 2. Slowly engage (release) the clutch after the engine while the engine is running. The starter and has started. flywheel gears could clash or jam, severely 3.

  • Page 73: Engine Warmup

    PART 7: STARTING & OPERATING THE VEHICLE ENGINE WARMUP Engine Warmup 2. After a few minutes of idling at 600 RPM, increase your idle speed to 900 or 1000 RPM. Continue your The purpose of engine warmup is to allow oil film to be warmup.
  • Page 74 • Use only a winterfront available from your serious illness. Peterbilt dealer that is compatible with a EPA-compliant engine cooling system. CAUTION: Never idle your vehicle for pro- T h e s e w i n t e r f r o n t s a r e s p e c i f i c a l l y...

  • Page 75: Idling The Engine

    PART 7: STARTING & OPERATING THE VEHICLE TRANSMISSION WARMUP NOTES: Transmission Warmup • Keep the engine exhaust system and the vehi- In cold weather you may find shifting sluggish when you cle’s cab/sleeper ventilation system properly first start the engine. Transmission warmup is especially maintained.

  • Page 76: Putting The Vehicle In Motion

    This section discusses the clutch and transmission opera- engines, which can result in a fire, never leave tion to get your Peterbilt underway. the engine idling without an alert driver present. If the engine should overheat, as...

  • Page 77: Shifting The Transmission

    PART 7: STARTING & OPERATING THE VEHICLE PUTTING THE VEHICLE IN MOTION Shifting The Transmission Operating the Clutch You will find a shift pattern either on a decal in your cab or “Riding” the Clutch on a medallion in the shift knob. Check to be sure you The clutch pedal is not a footrest.
  • Page 78 PUTTING THE VEHICLE IN MOTION PART 7: STARTING & OPERATING THE VEHICLE The total stroke of the clutch pedal is about 10 inches. The Clutch Adjustment first 1 3/4 to 2 inches is free travel. After that is the release Inspect manual and self-adjusting clutches regularly to stroke, the part that fully releases the clutch.
  • Page 79 PART 7: STARTING & OPERATING THE VEHICLE PUTTING THE VEHICLE IN MOTION CAUTION: Be careful not to apply the clutch • Upshifts - Let the engine and gears slowdown to the RPM required for the next gear. Use the tachom- brake while the vehicle is moving.
  • Page 80 PUTTING THE VEHICLE IN MOTION PART 7: STARTING & OPERATING THE VEHICLE WARNING! • Do not put the differential lock in the LOCK position while the wheels are spinning freely (slipping), you could lose control of the vehicle or cause axle damage—you could be injured.

  • Page 81: Dual Range (Two Speed) Axles

    PART 7: STARTING & OPERATING THE VEHICLE PUTTING THE VEHICLE IN MOTION To reduce load on the drive train, ease up on the throttle Using Your Dual Range Axle pedal whenever you shift into LOCK or UNLOCK. WARNING! Never shift the axle when moving Dual Range (Two Speed) Axles downhill.
  • Page 82 PUTTING THE VEHICLE IN MOTION PART 7: STARTING & OPERATING THE VEHICLE d. Then release the accelerator until the axle has • To avoid damaging your vehicle, shift the axle at a shifted. slower speed until you are used to driving with the e.

  • Page 83: Auxiliary Transmission

    PART 7: STARTING & OPERATING THE VEHICLE PUTTING THE VEHICLE IN MOTION Automatic and Automated Transmission An automatic or automated transmission makes shifting much easier. It remains important to completely under- stand how to operate the transmission to optimize its effi- ciency.
  • Page 84 PUTTING THE VEHICLE IN MOTION PART 7: STARTING & OPERATING THE VEHICLE If Your Vehicle Must Be Towed 2. Cover open hubs when removing drive axle shafts. CAUTION: Water, dirt and other material can Follow these directions to ensure your vehicle is not dam- enter an open hub or axle.
  • Page 85 PART 7: STARTING & OPERATING THE VEHICLE PUTTING THE VEHICLE IN MOTION a. Remove the air line and firmly cap CAUTION: Failure to install the caging bolt when towing vehicles with driver-control main Air Line - Remove to Install differential lock can result in damage by fail- Caging Bolt ing to lock internal components in position.
  • Page 86 (90 kph). Information Returning a Towed Vehicle to Service A Model 387 is equipped with an anti-lock braking system You will have to add lubricant to prevent damage after (ABS). This ABS reduces the possibility of wheel lock-up. your vehicle has been towed.
  • Page 87 PART 7: STARTING & OPERATING THE VEHICLE ANTI-LOCK BRAKING SYSTEM OPERATING INFORMATION WARNING! may not function in an emergency. You will still have conventional brakes, but not anti- • The brake system is a critical vehicle safety lock brakes. If any warning lamp indicates a system.
  • Page 88 ANTI-LOCK BRAKING SYSTEM OPERATING INFORMATION PART 7: STARTING & OPERATING THE VEHICLE CAUTION: If the trailer ABS warning lamp does not illuminate when the ignition is first turned on, there is a problem with the bulb or wiring. The driver should have this checked as soon as possible.
  • Page 89 PART 7: STARTING & OPERATING THE VEHICLE ANTI-LOCK BRAKING SYSTEM OPERATING INFORMATION CAUTION: 2. If an ABS-equipped trailer is properly connected, the trailer ABS warning lamp will remain illuminated for a • The center pin of the 7-way trailer light line few more seconds while the trailer ABS is tested.
  • Page 90 ANTI-LOCK BRAKING SYSTEM OPERATING INFORMATION PART 7: STARTING & OPERATING THE VEHICLE ues are approached, the system will intervene to assist A Real World Example Of How The RSP the driver. System Operates: Roll Stability Program Excessive speed for road conditions creates forces Bendix RSP, an element of the overall ESP system, that exceed the threshold at...
  • Page 91 PART 7: STARTING & OPERATING THE VEHICLE ANTI-LOCK BRAKING SYSTEM OPERATING INFORMATION Yaw Stability Yaw Control Yaw stability counteracts the tendency of a vehicle to spin Yaw Control responds to a wide range of low- to high-fric- about its vertical axis. During operation, if the friction tion surface scenarios including rollover, jackknife and between the road surface and the tires is not sufficient to loss of control.
  • Page 92 ANTI-LOCK BRAKING SYSTEM OPERATING INFORMATION PART 7: STARTING & OPERATING THE VEHICLE IMPORTANT SAFETY INFORMATION ABOUT THE STABILITY SYSTEM ESP May Reduce The Vehicle Speed Automati- cally To minimize unexpected deceleration and reduce the risk of a collision the operator must: •...
  • Page 93 PART 7: STARTING & OPERATING THE VEHICLE ANTI-LOCK BRAKING SYSTEM OPERATING INFORMATION WARNING! Exercise extreme care when tow- • If very rapidly winding steering inputs are inputted at ing doubles or triples with a vehicle equipped high speeds, with Electronic Stability Program. Excessive •...
  • Page 94 ANTI-LOCK BRAKING SYSTEM OPERATING INFORMATION PART 7: STARTING & OPERATING THE VEHICLE Truck Chassis Modifications the steering wheel is changed or re-centered, the Steer- ing Angle Sensor must be re-calibrated. The ESP system was specifically calibrated and validated only for your vehicle’s original factory-built configuration. If WARNING! If the Steering Angle Sensor is not re-calibrated, the Yaw Control system will not your vehicle’s chassis components are altered (for exam-...

  • Page 95: Brake Safety And Emergency

    PART 7: STARTING & OPERATING THE VEHICLE BRAKE SAFETY AND EMERGENCY The Wheel Spin Control warning lamp will briefly illumi- Brake Safety and Emergency nate and then go out when the ignition switch is first To stop your vehicle in an emergency, vary the service turned on.

  • Page 96: Overheated Brakes

    BRAKE SAFETY AND EMERGENCY PART 7: STARTING & OPERATING THE VEHICLE • Unless you have an anti-lock braking sys- Parking Brakes and Their Use tem, always avoid completely depressing The yellow diamond-shaped knob on your instrument the service brake pedal, if possible, even panel controls your parking brakes.
  • Page 97 PART 7: STARTING & OPERATING THE VEHICLE BRAKE SAFETY AND EMERGENCY WARNING! • Do not leave the cab without applying the parking brake. The truck could roll and cause an injury accident. Always apply the parking brake before you leave the cab. •...
  • Page 98 BRAKE SAFETY AND EMERGENCY PART 7: STARTING & OPERATING THE VEHICLE NOTE: Today’s diesel electronic engines have • To release the full combination of brakes, push in significant torque and startability power at low BOTH yellow and red knobs. RPM. Combinations of engine speed and avail- Trailer Air Supply Valve able torque may over-power the vehicle’s parking brakes.
  • Page 99 PART 7: STARTING & OPERATING THE VEHICLE BRAKE SAFETY AND EMERGENCY Manually Releasing Spring Brakes • Disassembling the spring brake chamber is dangerous and could cause serious injury. There may be an occasion when you need to tow the vehi- These chambers contain a powerful spring cle but the air system does not produce enough operating that is compressed.
  • Page 100 BRAKE SAFETY AND EMERGENCY PART 7: STARTING & OPERATING THE VEHICLE To release spring brakes manually 1. Remove the cap from the spring chamber. 02936A 2. Remove the release stud assembly from the side pocket; remove the release nut and washer from the release stud.
  • Page 101 PART 7: STARTING & OPERATING THE VEHICLE BRAKE SAFETY AND EMERGENCY 3. Slide out the release stud 02936C 02937A 4. Insert the release stud through the opening in the spring chamber where the cap was removed. Insert it into the pressure plate. Turn the release stud 1/4-turn clockwise in the pressure plate.
  • Page 102 BRAKE SAFETY AND EMERGENCY PART 7: STARTING & OPERATING THE VEHICLE 5. Assemble the release stud washer and nut on the release stud. 02937B 6. With a wrench, turn the release stud assembly nut until the compression spring is 90% - 95% caged. While doing this, check to make sure the push rod (adapter push rod or service push rod) is retracting.
  • Page 103 PART 7: STARTING & OPERATING THE VEHICLE BRAKE SAFETY AND EMERGENCY • The retarder is NOT intended as the primary Retarders brake for the vehicle, nor is it an emergency Various retarders are available which function against the brake. The retarder only helps the service engine, driveline, or transmission.
  • Page 104 BRAKE SAFETY AND EMERGENCY PART 7: STARTING & OPERATING THE VEHICLE Driving Bobtail or with an Unloaded Trailer If you watch engine speed and exhaust temperature ranges, the pyrometer can help you operate your truck We recommend that you do not use your engine retarder more efficiently and avoid sudden changes in engine to slow down when you are bobtailing or pulling an empty operating temperature.
  • Page 105 PART 7: STARTING & OPERATING THE VEHICLE STOPPING THE ENGINE Stopping The Engine 100°F (55°C) above the temperature reached during oper- ation. A sudden rise in temperature like this could cause Before Stopping The Engine the bearings to seize or the oil seals to loosen. A hot engine stores a great amount of heat.

  • Page 106: Final Stop

    STOPPING THE ENGINE PART 7: STARTING & OPERATING THE VEHICLE Final Stop 2. If you are parked on a steep grade, block the wheels To make sure your vehicle is ready to go after a long stop (such as over night), please follow the suggestions below. Your vehicle will be easier to get going when you are ready, and it will be safer for anyone who might be around it.

  • Page 107: Setting Ride Height

    U-joint working angles. This can result in prema- ture driveline wear and driveline vibration. If your vehicle is equipped with a Peterbilt rear air suspension, and if it becomes necessary to reset the ride height, you may tem- porarily set it by following the next procedure. Proper ride height measurement and values are shown in the illustra- tion and table below.
  • Page 108 CAUTION: Completing this procedure will enable you to safely reach the nearest autho- rized Peterbilt repair facility to have ride height and pinion angle reset using the proper FORWARD equipment and technique. Do this as soon as 02941A possible to avoid potential driveline damage.
  • Page 109 PART 7: STARTING & OPERATING THE VEHICLE SETTING RIDE HEIGHT • On dual-valve systems, begin with the LH DELIVERY TO RH AIR BAG(S) valve on the next step. SUPPLY FROM FORWARD AIR TANK 2. Loosen the fasteners mounting a height control valve to its bracket.

  • Page 110: Driving With Deflated Air Springs

    SETTING RIDE HEIGHT PART 7: STARTING & OPERATING THE VEHICLE • For tandem axles, make the vertical measurement WARNING! Your brakes could fail if you con- at the centerline of the suspension (see illustration tinue driving with deflated air springs. Air page 109).

  • Page 111: Driving Tips And Techniques

    This section covers additional driving tips and techniques high speeds you could seriously damage your on how to drive your Peterbilt more efficiently. For further vehicle or cause an accident when you put the information, read the American Trucking Association's transmission in gear.

  • Page 112: Descending A Grade

    DRIVING TIPS AND TECHNIQUES PART 7: STARTING & OPERATING THE VEHICLE Coasting with the transmission in neutral also prevents NOTE: Often these recommendations are sec- ondary to maintaining an adequate and safe proper transmission component lubrication. During coast- speed relative to the surrounding traffic and road ing the transmission is driven by the rear wheels, and the conditions.

  • Page 113: Warning Alarms

    Warning alarms can be generated by brake, keeping the engine speed below 2,100 rpm. two main sources in a Model 387: the multiplex instrumen- tation system and (if equipped) the digital message center. When the engine speed reaches its maximum governed...
  • Page 114 WARNING ALARMS PART 7: STARTING & OPERATING THE VEHICLE A multiplex instrumentation system alarm can be sig- An alarm’s warning message on the SMC will preempt all nalled by up to four indicators: other SMC displays until the condition that is causing the •...
  • Page 115 PART 7: STARTING & OPERATING THE VEHICLE WARNING ALARMS 2. Continue to check and act on all warning messages Activation Deactivation Display Gauge LED Buzz until the odometer is displayed. Condition Display LOW AIR2 Low air pressure Secondary AIR2 OK Multiplex Instrumentation System Alarm Summary in air tank #2 air pressure...
  • Page 116 WARNING ALARMS PART 7: STARTING & OPERATING THE VEHICLE – 118 – Y53-6007 (R10/06)

  • Page 117: Preventive Maintenance Schedule

    “PART 6: DRIVER’S you could make your vehicle unsafe. Do only CHECKLIST” for these. If you check your Peterbilt vehicle those maintenance items you are fully trained and equipped to do. regularly, you can avoid many large, expensive, and time- consuming repairs.
  • Page 118 PREVENTIVE MAINTENANCE SCHEDULE PART 8: MAINTENANCE AND SERVICE • Disconnect the battery ground strap when- • Never start or let the engine run in an ever you work on the fuel system or the enclosed, unventilated area. Exhaust fumes electrical system. When you work around from the engine contain carbon monoxide, fuel, do not smoke or work near heaters or a colorless and odorless gas.
  • Page 119 PART 8: MAINTENANCE AND SERVICE PREVENTIVE MAINTENANCE SCHEDULE NOTES: vices more frequently. The charts on the following pages show the maintenance intervals for recommended main- • Where questions or discrepancies develop tenance practices. between these recommendations and compo- nent supplier recommendations, consult the NOTES: supplier for specific recommendations.
  • Page 120 PREVENTIVE MAINTENANCE SCHEDULE PART 8: MAINTENANCE AND SERVICE Table 2 Preventative Maintenance Schedule Recommended PM Interval SYSTEM COMPONENT MAINTENANCE TASK Frame Fifth Wheel Check the kingpin lock and plate for wear and function; lubricate (NLGI #2 grease). Frame Fasteners Check for tightness; tighten to the specified torque value as required (see page 185).
  • Page 121 PART 8: MAINTENANCE AND SERVICE PREVENTIVE MAINTENANCE SCHEDULE Table 2 Preventative Maintenance Schedule (Continued) Recommended PM Interval SYSTEM COMPONENT MAINTENANCE TASK Front Spring Pins Lubricate. Suspension Shock Absorbers Inspect for leaking, body damage, and damaged or worn bushings. Replace as required. Shock Absorbers Check for proper function.
  • Page 122 PREVENTIVE MAINTENANCE SCHEDULE PART 8: MAINTENANCE AND SERVICE Table 2 Preventative Maintenance Schedule (Continued) Recommended PM Interval SYSTEM COMPONENT MAINTENANCE TASK Drive Axle Breather Clean or replace. Lube Pump (ON HIGHWAY) Remove the magnetic strainer and inspect for wear particles. Wash in sol- (Dana) vent and dry in air.
  • Page 123 PART 8: MAINTENANCE AND SERVICE PREVENTIVE MAINTENANCE SCHEDULE Table 2 Preventative Maintenance Schedule (Continued) Recommended PM Interval SYSTEM COMPONENT MAINTENANCE TASK Drive Axle Axle Housing Drain and replace the lubricant. See information on page (Meritor) Lubricant filter Change the filter. Breather Check the operation.
  • Page 124 Check the plunger boot for cracks. Lubricate roller pin, pivot pin, and plunger (NLGI #2 grease). Brake treadle valve Rebuild through an authorized Peterbilt service facility. Brake air system Check air lines and fittings for leaks (see page 152).
  • Page 125 PART 8: MAINTENANCE AND SERVICE PREVENTIVE MAINTENANCE SCHEDULE Table 2 Preventative Maintenance Schedule (Continued) Recommended PM Interval SYSTEM COMPONENT MAINTENANCE TASK Disc Brakes Brake pads Inspect; replace as required. (All) Brake disc/rotor Inspect for visible cracks, heat checking, galling, or scoring of surface. Check thickness minimum of 1.46”...
  • Page 126 PREVENTIVE MAINTENANCE SCHEDULE PART 8: MAINTENANCE AND SERVICE Table 2 Preventative Maintenance Schedule (Continued) Recommended PM Interval SYSTEM COMPONENT MAINTENANCE TASK Hub, Drum, LMS Hubs (Dana) Check the bearing endplay and adjust as required (see page 164). & Hubcap LMS Hubs (Dana) with Clean the components and check for excessive wear or damage.
  • Page 127 PART 8: MAINTENANCE AND SERVICE PREVENTIVE MAINTENANCE SCHEDULE Table 2 Preventative Maintenance Schedule (Continued) Recommended PM Interval SYSTEM COMPONENT MAINTENANCE TASK Main & aux- Main & auxiliary transmission Check the oil level; refill as required (see page 144 page 146). iliary trans- Main &...
  • Page 128 PREVENTIVE MAINTENANCE SCHEDULE PART 8: MAINTENANCE AND SERVICE Table 2 Preventative Maintenance Schedule (Continued) Recommended PM Interval SYSTEM COMPONENT MAINTENANCE TASK Clutch Clutch pedal shaft Check for excessive looseness and lubricate (NLGI #2 grease). Clutch pedal Check for proper free pedal (see page 182).
  • Page 129 PART 8: MAINTENANCE AND SERVICE PREVENTIVE MAINTENANCE SCHEDULE Table 2 Preventative Maintenance Schedule (Continued) Recommended PM Interval SYSTEM COMPONENT MAINTENANCE TASK Cooling Components Check the radiator and heater hoses for leaks. Radiator Pressure Cap Check radiator pressure cap System (ELC) Check the freeze point (see page 171).
  • Page 130 PREVENTIVE MAINTENANCE SCHEDULE PART 8: MAINTENANCE AND SERVICE Table 2 Preventative Maintenance Schedule (Continued) Recommended PM Interval SYSTEM COMPONENT MAINTENANCE TASK Tires & Tires Check inflation pressure (see page 156). Weekly “cold” using cali- Wheels brated gauge Tires Inspect for cuts, irregular wear, missing lugs, sidewall damage, etc. Disc wheels Inspect the wheel disc for any cracks or surface irregularities.
  • Page 131 PART 8: MAINTENANCE AND SERVICE PREVENTIVE MAINTENANCE SCHEDULE Table 2 Preventative Maintenance Schedule (Continued) Recommended PM Interval SYSTEM COMPONENT MAINTENANCE TASK Power Steering gear Grease the trunnion bearing (EP NLGI #2 lithium-based, moly-filled, HD Steering grease). Steering gear Grease the input shaft seal (EP NLGI #2 lithium-based, moly-filled, HD grease).
  • Page 132 PREVENTIVE MAINTENANCE SCHEDULE PART 8: MAINTENANCE AND SERVICE Table 2 Preventative Maintenance Schedule (Continued) Recommended PM Interval SYSTEM COMPONENT MAINTENANCE TASK Power Draglink and tie rod arm ball Lubricate (EP NLGI #2 lithium-based, moly-filled, HD grease). Steering sockets (ON HIGHWAY) Steering intermediate shaft Lubricate (EP NLGI #2 lithium-based, moly-filled, HD grease).
  • Page 133 PART 8: MAINTENANCE AND SERVICE PREVENTIVE MAINTENANCE SCHEDULE Table 2 Preventative Maintenance Schedule (Continued) Recommended PM Interval SYSTEM COMPONENT MAINTENANCE TASK Driveshafts Models 1610-1810 & SPL-90 Lubricate. slip member & U-joints Model SPL-100 slip member Lubricate. & U-joints Models SPL-140/140HD/170/ Lubricate.
  • Page 134 PREVENTIVE MAINTENANCE SCHEDULE PART 8: MAINTENANCE AND SERVICE Table 2 Preventative Maintenance Schedule (Continued) Recommended PM Interval SYSTEM COMPONENT MAINTENANCE TASK Battery Battery cables Check the condition of the cables, cushion clamps, and routing. Replace a Boxes, Tool cushion clamp if the rubber has deteriorated. Repair or tighten terminals, Boxes, and and secure cables to prevent chafing.
  • Page 135 PART 8: MAINTENANCE AND SERVICE PREVENTIVE MAINTENANCE SCHEDULE Table 2 Preventative Maintenance Schedule (Continued) Recommended PM Interval SYSTEM COMPONENT MAINTENANCE TASK Electrical & Headlamps Check the aim and adjust as required. lights Warning lights in light bar Check at the ignition start position to verify bulbs function (see page 47).
  • Page 136 PREVENTIVE MAINTENANCE SCHEDULE PART 8: MAINTENANCE AND SERVICE Table 2 Preventative Maintenance Schedule (Continued) Recommended PM Interval SYSTEM COMPONENT MAINTENANCE TASK Cab struc- Hood Lubricate the lower hood pivot (only if lube fittings are present). ture, doors, Hinges and latch Lubricate with silicone spray.
  • Page 137 PART 8: MAINTENANCE AND SERVICE PREVENTIVE MAINTENANCE SCHEDULE Table 2 Preventative Maintenance Schedule (Continued) Recommended PM Interval SYSTEM COMPONENT MAINTENANCE TASK Air compressor governor Replace air strainer. Air lines Check condition and routing to prevent chafing. System (see Lubricate page 168 Inline filters Replace elements or clean with solvent.

  • Page 138: Lubricant Specifications

    PREVENTIVE MAINTENANCE SCHEDULE PART 8: MAINTENANCE AND SERVICE Lubricant Specifications Engine WARNING! Handle lubricants carefully. Vehi- NOTE: The engine in this vehicle may comply with 2007 EPA emission standards. Consult the cle lubricants (oil and grease) are poisonous engine manufacturer’s manual for changed lubri- and can cause sickness.
  • Page 139 PART 8: MAINTENANCE AND SERVICE PREVENTIVE MAINTENANCE SCHEDULE CAUTION: Never idle your vehicle for pro- NOTE: Use only exact replacement components in exhaust systems. Certain components contain longed periods of time if you sense that integral catalytic converters essential for compli- exhaust fumes are entering the cab or sleeper.

  • Page 140: Master Lubrication Index

    PREVENTIVE MAINTENANCE SCHEDULE PART 8: MAINTENANCE AND SERVICE Master Lubrication Index Table 3 Lubricant Symbol Key CJ-4 Engine oil Table 3 Lubricant Symbol Key Multipurpose chassis grease Dextron III/Mercon approved Automatic Trans- Type C4 transmission fluid (torque fluid) mission Fluid Extreme Pressure Lubricant Ball Bearing grease Straight mineral gear lubricant...
  • Page 141 PART 8: MAINTENANCE AND SERVICE PREVENTIVE MAINTENANCE SCHEDULE Table 4 Component Lubrication Index (Continued) Component Lubrication Index Table 4 Clutch Release Bearings Universal Joints Brake Shoe Anchor Pins Drive Shaft Splines Brake Cam Bearings Wheel Bearings (driven hubs) Slack Adjusters Wheel Bearings (nondriven hubs) CD50 Water Pump...

  • Page 142: Fuller Transmission Lubrication

    PREVENTIVE MAINTENANCE SCHEDULE PART 8: MAINTENANCE AND SERVICE 2. Change oil regularly. 3. Use the correct grade and type of oil. 4. Buy oil from a reputable dealer. Lubrication Change and Inspection Off-Highway Use Refer to the Eaton Fuller transmission manual for servic- 02942 ing information.
  • Page 143 Below 10° F (-12° C) GL-1 CAUTION: Exceeding the recommended oil Synthetic Lubri- change intervals may be harmful to the life of cant* the transmission and the transmission oil * See your Peterbilt dealer for approved brands. cooler. (R10/06) Y53-6007 – 145 –...

  • Page 144: Spicer Transmission Lubrication

    PREVENTIVE MAINTENANCE SCHEDULE PART 8: MAINTENANCE AND SERVICE Spicer Transmission Lubrication Table 6 Recommended Lubricants It is extremely important to use the proper lubricants and maintain the correct oil levels in Spicer units. This will Ambient Type Grade (SAE) Temperature ensure proper lubrication and operating temperatures in these units.
  • Page 145 PART 8: MAINTENANCE AND SERVICE PREVENTIVE MAINTENANCE SCHEDULE Oil Changes Refilling CAUTION: When adding oil, types and brands Remove all dirt around filler plug. Refill with new oil of the of oil should not be intermixed because of grade recommended for the existing season and prevail- p o s s i b l e i n c o m p a t i b i l i t y, w h i c h c o u l d ing service.

  • Page 146: Meritor Axle Lubrication

    • Refer to the Meritor Field Maintenance Manual for a particular axle for lubricant specifications. Synthetic with Pump 120,000 mi.(192,000 and Filter • See your Peterbilt dealer for Meritor-approved lubri- cant brands. Mineral Base 120,000 mi. (192,000 – 148 –...

  • Page 147: Eaton/Dana Axle Lubrication

    1 quart (921 ml) of oil is required for proper particular axle for lubricant specifications. lubrication of each drive hub. Add oil through the filler hole • See your Peterbilt dealer for Eaton-approved lubricant in the hub; if none, add oil through the differential filler brands.

  • Page 148: Universal Joint Lubrication

    PREVENTIVE MAINTENANCE SCHEDULE PART 8: MAINTENANCE AND SERVICE through the bearings when initially filling a hub. Maintain Universal Joint Lubrication the differential oil level by adding oil until its surface is Refer to the Spicer Universal Joints and Driveshafts ser- even with the bottom of the filler hole (see page 144).
  • Page 149 Every 240,000 (24,000) (384,000)/24 Every 15,000 Every 240,000 Sheppard (24,000) (384,000)/24 *Extremely low temperatures may require lower viscosity fluids; con- sult your Peterbilt dealer for recommendations @See TRW or Sheppard Service Manuals for additional fluid listings (R10/06) Y53-6007 – 151 –...

  • Page 150: Brake Adjustment

    To operate your vehicle safely and profitably, you need some understanding of its brake systems. For more on This section will help you keep your Peterbilt vehicle in brakes, see the Index, under Brakes. good running condition. There are a number of checks...
  • Page 151 PART 8: MAINTENANCE AND SERVICE BRAKE ADJUSTMENT tem. All of the following areas are interrelated and must All vehicle operators should check their brakes regularly. conform to original specifications: Always adjust your brakes when they are cool. • Tire Size WARNING! Brake linings and pads with a •...
  • Page 152 To perform a leakage test, refer to the detailed instructions in the Peterbilt Maintenance Manual, or take your vehicle to an authorized Peterbilt dealer. Air Disc Brakes...
  • Page 153 PART 8: MAINTENANCE AND SERVICE BRAKE ADJUSTMENT • Proper Running Clearance is 0.08” (2 mm) of move- • A correctly installed and functioning auto slack ment of the brake caliper (approximately the thickness adjuster will produce the following strokes: of a nickel) in the inboard/outboard direction. •...
  • Page 154 TIRES, WHEELS, AND RIMS PART 8: MAINTENANCE AND SERVICE WARNING! Manual adjustment of automatic quent inspection and the right care will give you the assur- slack adjusters is a dangerous practice that ance of safe and reliable tire operation. Here are some could have serious consequences.
  • Page 155 PART 8: MAINTENANCE AND SERVICE TIRES, WHEELS, AND RIMS Underinflated Tires WARNING! Do not exceed the load rating of your tires (molded on the side wall of your Low pressure is a tire’s worst enemy. Underinflation allows tire) or the maximum vehicle load rating, tires to flex improperly, causing high temperatures to build whichever is less.
  • Page 156 TIRES, WHEELS, AND RIMS PART 8: MAINTENANCE AND SERVICE WARNING! Overinflated tires can cause acci- WARNING! dents. They wear more quickly than properly • Mismatched tires are dangerous. Mixing tire inflated tires. And they are more subject to types may lessen the road-holding ability of punctures, cracks, &...
  • Page 157 PART 8: MAINTENANCE AND SERVICE TIRES, WHEELS, AND RIMS Drive Axles or Trailers: Replace tires on drive axles or trailers when less than 2/32 in. of tread depth remains in any major groove. Check at three places equally spaced around the tire. See the next illustration for recommended measuring points for tread depth.
  • Page 158 TIRES, WHEELS, AND RIMS PART 8: MAINTENANCE AND SERVICE NOTE: To prolong your tires’ life and make them Speed Restricted Tires safer, have their radial and lateral run-out checked at WARNING! This vehicle may be equipped with your dealer. And of course you should have your tires speed restricted tires.
  • Page 159 PART 8: MAINTENANCE AND SERVICE TIRE LOAD AND INFLATION TABLES Tire Load and Inflation Tables Table 12 Load Range Letters and Corresponding Ply Rating ( G = 14 ply; H = 16 ply) SINGLE RADIAL TIRES FOR VEHICLES IN HIGHWAY SERVICE Tire Load Tire Load Limits At Various Cold Inflation Pressures (psi)

  • Page 160: Vehicle Loading

    GVW rating of • The components of your vehicle are your Peterbilt vehicle. designed to provide satisfactory service if the vehicle is not loaded in excess of either...

  • Page 161: Wheels And Rims

    PART 8: MAINTENANCE AND SERVICE VEHICLE LOADING Load Distribution: Be sure any load you carry is distrib- Hub, Drum, and Stud Assembly uted so that no axle has to support more than its load • The hub pilot mounting system uses M22x1.5 met- limit.
  • Page 162 VEHICLE LOADING PART 8: MAINTENANCE AND SERVICE Wheel Nuts procedure for the wheels on your truck. This is a job you may not be able to do yourself. You need the right torquing • Hub pilot nut has a hex body and a flange for clamp- equipment to do it.
  • Page 163 PART 8: MAINTENANCE AND SERVICE VEHICLE LOADING Disc Wheels To check the torque on disc wheels, follow the crisscross sequence shown. See the Specifications chart for proper torque specification. WARNING! • Grooves in the wheel disc or other damage to the disc can lead to a serious accident. The disc will be weakened and can eventu- ally come off, maybe causing you to lose control of your vehicle.
  • Page 164 VEHICLE LOADING PART 8: MAINTENANCE AND SERVICE WARNING! Improperly mounting and demount- wheels should be serviced only by trained personnel using proper equipment. Do not ing tire and rim assemblies is dangerous. Failure reinflate a tire that has been run flat or is seri- to observe proper precautions could cause the ously low on air without first removing the tire tire-rim assembly to burst explosively, causing...
  • Page 165 PART 8: MAINTENANCE AND SERVICE VEHICLE LOADING Table 13 Cap Nut Torque Specifications (R12/01) TORQUES FOR INNER & OUTER CAP NUTS WHEEL AND NUT STUD SIZE CONFIGURATION Lb. Ft. Stud-Piloted Disc 3/4”-16 Inner 450-500 610-680 Wheels 1 1/8”-16 Outer Heavy Duty Stud- 15/16”-12 Inner Piloted Disc Wheels 1 5/16”-12...
  • Page 166 YOUR VEHICLE’S AIR SYSTEM PART 8: MAINTENANCE AND SERVICE Your Vehicle’s Air System • Never attempt to disassemble a component until you have read and understood recom- WARNING! Prior to the removal of any air sys- mended procedures. Some components tem component, always block and hold the contain powerful springs and injury can vehicle by a secure means other than the...

  • Page 167: Air Supply System

    PART 8: MAINTENANCE AND SERVICE YOUR VEHICLE’S AIR SYSTEM Air Supply System Periodically • Clean filter screens ahead of the valves by removing WARNING! Do not operate the vehicle if leakage the screens and soaking them in solvent. Blow them in the air system is detected.

  • Page 168: Air Dryer

    YOUR VEHICLE’S AIR SYSTEM PART 8: MAINTENANCE AND SERVICE Air Dryer Every 900 operating hours or 30,000 miles/48,000 km or 3 months, check for moisture in the air brake system by WARNING! Use of incorrect air dryer could opening reservoirs, drain valves, or valves and checking cause air system failure, leading to loss of for the presence of water.

  • Page 169: Engine Cooling System

    PART 8: MAINTENANCE AND SERVICE ENGINE COOLING SYSTEM Engine Cooling System This information is found in the engine manufac- turers owner’s manual. It is the owner’s respon- Your engine’s cooling system is standard with Extended sibility to follow all requirements listed in the engine manufacturers owner’s manual.
  • Page 170 ENGINE COOLING SYSTEM PART 8: MAINTENANCE AND SERVICE ELC Condition (Contamination and Inhibitor Concentra- page 119. Never use filters that contain SCAs in an ELC- tion) filled system. Perform a visual inspection of the ELC. It should have no Topping Off cloudiness or floating debris.
  • Page 171 PART 8: MAINTENANCE AND SERVICE ENGINE COOLING SYSTEM Check the coolant level after each trip. Add coolant as Proper Coolant Level necessary. You may find your coolant level is not up to the NOTE: Do not overfill a cooling system. Excess correct level soon after you have filled the radiator.

  • Page 172: Battery Care

    ELECTRICAL PART 8: MAINTENANCE AND SERVICE 6. Complete the filling. Do it as quickly as possible. Battery Care 7. Idle the engine until it reaches normal operating tem- Regular attention to the charging system will help prolong perature. the service life of your batteries. Here are some common causes of battery failure: 8.
  • Page 173 PART 8: MAINTENANCE AND SERVICE ELECTRICAL Recharging Batteries • Always make sure the battery charger is OFF before connecting or disconnecting the cable clamps. Except for using small trickle chargers to maintain battery condition, you should have your vehicle’s batteries WARNING! Always shield your eyes and avoid charged by a qualified service facility.
  • Page 174 ELECTRICAL PART 8: MAINTENANCE AND SERVICE • Before attempting any work on the batteries or electri- • Keep the battery clean and dry. cal system, remove all jewelry. If metal jewelry or • Look for any signs of damage. other metal comes in contact with electrical circuits, a •...
  • Page 175 PART 8: MAINTENANCE AND SERVICE ELECTRICAL Slow Battery Charging Peterbilt Dealer or a reputable towing service. But if you are unable to do this, and must jump-start your vehicle, NOTE: Follow the instructions that come with then ensure that you follow the precautions and instruc- your batter y charger.
  • Page 176 ELECTRICAL PART 8: MAINTENANCE AND SERVICE any other metal on the vehicle at the same tially different capacity rating may cause an time. Remove metal jewelry; avoid leaning explosion. To avoid serious personal injury over a battery. If metal jewelry or other and damage to the vehicle, heed all warn- metal comes in contact with electrical cir- ings and instructions of the jumper cable...
  • Page 177 PART 8: MAINTENANCE AND SERVICE ELECTRICAL CAUTION: Departures from these procedures WARNING! If you do not cover the filler open- could also cause serious damage to both ings on the battery, electrolyte could boil out vehicles. Improper use of a booster battery to of the openings and hurt someone or damage start a vehicle may cause an explosion.

  • Page 178: Headlamp Adjustment

    ELECTRICAL PART 8: MAINTENANCE AND SERVICE WARNING! When disconnecting jumper cables, Headlamp Adjustment make sure they do not get caught in any moving Follow the procedure below to adjust a headlamp. parts in the engine compartment. NOTE: This lamp has provisions for vertical adjustment 7.
  • Page 179 PART 8: MAINTENANCE AND SERVICE ELECTRICAL 1. Ensure that the hood is properly adjusted. 2. Ensure that the hood is closed and completely latched. 3. Ensure that the tires are inflated to an on-highway set- ting. 4. Ensure that the headlamp surfaces are clean and dry. 5.

  • Page 180: Specification

    TRANSMISSION AND DRIVE TRAIN PART 8: MAINTENANCE AND SERVICE 9. Repeat for opposite headlamp. Specification Use only diesel fuel as recommended by engine manufac- Low beams and high beams are integrated; only low turers. beams need adjustment. The high beams should be level wht the H-H line once the low beams are WARNING! A mixture of gasoline or alcohol adjusted the the A-A line.
  • Page 181 PART 8: MAINTENANCE AND SERVICE STEERING • When installing spin-on (throwaway) filters, hand Steering tighten them only to 1/2 to 2/3 turn after gasket con- Guidelines For Checking A Steering System tact. Mechanical tightening of these filters may distort or crack the filter head. WARNING! A steering system that is not work- ing properly can cause an accident.
  • Page 182 If you see uneven wear, take your vehicle to a service cen- ularly by an authorized mechanic. ter familiar with aligning front ends on Peterbilt vehicles. • For on-highway vehicles, tighten the U- bolts after the first 15,000 miles (24,000 km).
  • Page 183 PART 8: MAINTENANCE AND SERVICE FASTENERS cle conditions, including: hard steering, axle Fasteners misalignment, spring breakage or abnormal Frame Fastener Torque Specifications tire wear. • Do not replace U–bolts and nuts with common Table 14 Frame Fastener Torque Specifications U–bolts or standard nuts. These parts are crit- ical to vehicle safety.
  • Page 184 FASTENERS PART 8: MAINTENANCE AND SERVICE Table 15 Capscrew Torgue Specifications (Continued) Standard Capscrew Torque Specifications SAE Grade Number Table 15 Capscrew Torgue Specifications 58 - 87 79 - 118 86 - 123 117 - 167 SAE Grade 9/16-12 78 - 111 105 - 151 110 - 158 149 - 214...

  • Page 185: Engine Accessories

    PART 8: MAINTENANCE AND SERVICE ENGINE ACCESSORIES Frame Fasteners Engine Accessories • Go around your vehicle as per the Preventive Mainte- Accessory Drive Belts nance Schedule and tighten all frame fasteners with a You can extend the reliability and service life of your vehi- torque wrench.

  • Page 186: Air Intake System

    AIR INTAKE SYSTEM PART 8: MAINTENANCE AND SERVICE On/Off Fan Drives - Check the clutch operation by starting the engine when it is cold. Idle the engine at about 800 RPM. Listen for air leaks. Check that the fan is not work- ing while the engine is warming up.

  • Page 187: Air Cleaners

    PART 8: MAINTENANCE AND SERVICE AIR INTAKE SYSTEM Under severe operating conditions, such as heavy off- WARNING! The exhaust piping, muffler, con- verter muffler or independent converter highway use, the disassembly and cleaning should be become extremely hot during engine opera- more frequent.

  • Page 188: Exhaust System

    EXHAUST SYSTEM PART 8: MAINTENANCE AND SERVICE WARNING! Do not operate engine with turbo- Anti-lock Braking System (ABS) charger intake piping disconnected. Working For details of use and maintenance of your anti-lock sys- around a turbocharger with the intake piping tem, see the anti-lock braking system service literature removed can be dangerous.
  • Page 189 PART 8: MAINTENANCE AND SERVICE ANTI-LOCK BRAKING SYSTEM (ABS) hub is reinstalled. On rear axles, the sensor should be a malfunction, and automatic shut-down of the system. If pushed fully into the mounting block before reinstall- the air system is intact (indicated by the pressure ing the hub.

  • Page 190: Cab Heater-Air Conditioner

    • Check the drain pan of the fresh air vent for trapped water before assuming that there is a leak in the heat- ing system. • If the heater core is leaking, take the vehicle to a Peterbilt dealer for proper heater service or repair. – 192 – Y53-6007 (R10/06)
  • Page 191 Clean the heater core if necessary. If the through the core in the opposite direction of normal air condition persists, take the vehicle to a Peterbilt flow. dealer for proper heater service or repair.
  • Page 192 APPEARANCE PART 8: MAINTENANCE AND SERVICE Special Precautions Appearance WARNING! Excessive heat may cause your air Painted Surfaces conditioning system to explode. Never weld, solder, steam clean, or use a blow torch near CAUTION: Do not aim the water jet directly at any part of the air conditioning system.

  • Page 193: Stainless Steel

    After cleaning, Cleaning Cab Interiors wax flat surfaces and apply a thin coat of rust preven- Peterbilt cab and sleeper interiors are built using a variety tive lubricant around bolts or other fasteners. of different materials including fabrics, carpet, polyure-...
  • Page 194 APPEARANCE PART 8: MAINTENANCE AND SERVICE • Always test a commercial cleaning agent on thane, and painted plastic surfaces. These cleaning pro- an inconspicuous area of the surface to be cedures will ensure that interior components remain in cleaned before using it. good condition for the life of the vehicle.
  • Page 195 PART 8: MAINTENANCE AND SERVICE APPEARANCE Interior Trim, Dash Shell, and Instrument Panels • Remove soap with a clean, damp rag. CAUTION: To avoid possible damage to these • If a stronger cleaning solution is required, use a foam- components, do not use abrasive cleaners, type carpet shampoo.
  • Page 196 APPEARANCE PART 8: MAINTENANCE AND SERVICE • Clean with the cloth dampened with lukewarm water. • Wash and protect painted and metal surfaces, and also weatherstripping, as outlined in the preceding • Dry with a clean cloth. “Appearance” information. • For difficult stains, use a commercial leather cleaner. •...

  • Page 197: Tampering With Noise Control System Prohibited

    Peterbilt Motors Company, was designed, built by any person. and equipped to conform at the time it left Peterbilt’s con- trol with all applicable U.S. EPA Noise Control Regula- Among those acts presumed to constitute tampering are tions.
  • Page 198 NOISE CONTROL SYSTEM PART 8: MAINTENANCE AND SERVICE • Removing shields or skirts. Noise Insulating Blankets • Removing noise insulators from engine block or from • Cutting away parts of shields, skirts or damaged or around the oil pan. loose portions of shields or skirts. •...
  • Page 199 PART 8: MAINTENANCE AND SERVICE NOISE CONTROL SYSTEM Inspection & Maintenance Instructions for Joints and Clamps Noise Control System Check for leaks, and tighten as necessary. Check for dete- rioration or dents in pipes and clamps which could allow The following instructions are based on regular inspection exhaust to escape.
  • Page 200 NOISE CONTROL SYSTEM PART 8: MAINTENANCE AND SERVICE Check clamps and mounting brackets for security. Check Hood Insulation Blanket internal baffling for security. You can do this by listening for Fasteners rattling sounds while tapping the muffler with a rubber Check all fasteners for condition and security.
  • Page 201 PART 8: MAINTENANCE AND SERVICE NOISE CONTROL SYSTEM Insulators • Check cab skirts, sills, and brackets for overall condi- tion and repair them as necessary. Damaged rubber Check insulators around fasteners and stress points, fender shields or cab skirting cannot be repaired. You especially where they may be affected by engine vibra- will need to replace it.
  • Page 202 NOISE CONTROL SYSTEM PART 8: MAINTENANCE AND SERVICE Table 16 Noise Control System Maintenance Logs RECOMMENDED DATE & REPAIR DATE & REPAIR WORK PERFORMED COMPONENT WORK PERFORMED INTERVAL R.O. NUMBER FACILITY & R.O. NUMBER FACILITY & (MILES) LOCATION LOCATION Exhaust System Rout- 25,000 ing Integrity Muffler Internal...

  • Page 203: Part 9: Vehicle Identification Numbers

    Each vehicle completed by Peterbilt Motors Company EXAMPLE VIN: 1XP 9D2X9 6 X D 345678 uses a Vehicle Identification Number (VIN) that contains the model year designation of your Peterbilt. The practice Model Year Serial Number is in compliance with 49 CFR 565, Code of Federal Regu- lations.
  • Page 204 PART 9: VEHICLE IDENTIFICATION NUMBERS – 206 – Y53-6007 (R10/06)

  • Page 205: Federal Safety Standard Certification Label

    How To Order Parts reproductive harm. This warning requirement When you need replacement parts for your Peterbilt vehi- is mandated by California law (Proposition 65) and does not result from any change in the...

  • Page 206: Nhtsa Consumer Information

    Ottawa ON K1A 0N5 paign. However, NHTSA cannot get involved in individual problems between you, your dealer, and Peterbilt Motors For additional road safety information, please visit the Company.

  • Page 207: Environmental Protection

    Peterbilt trucks are manufac- For additional information on your rights associated with tured. the use of this data, contact...

  • Page 208: State Of California

    STATE OF CALIFORNIA PART 10: CONSUMER INFORMATION – 210 – Y53-6007 (R10/06)

  • Page 209: Part 11: Subject Index

    PART 11: SUBJECT INDEX PART 11: SUBJECT INDEX Cruise Control Switch Dome Light Switch Alarms Electric Horn Anti-lock brakes 89, Engine Brake Appearance Engine Fan Switch Appliances in the Cab Fifth Wheel Lock (Slider Adjustment) Switch Fog Lights Switch Battery Hazard Flasher compartment cover Headlights...
  • Page 210 PART 11: SUBJECT INDEX Engine Oil Pressure Gauge Fuel Gauge Dash Manifold Pressure Gauge Defogging/defrosting system Primary And Secondary Air Pressure Gauges Door lock Pyrometer Driver’s Checklist Speedometer-Message Center Driving Tachometer vehicle inspection Transmission Temperature Gauge Voltmeter Economical driving Warning Lights and Buzzers Electrical system Water Temperature Gauge batteries...
  • Page 211 PART 11: SUBJECT INDEX Steering Gear Seat Transmission 144–?? Servicing Specific Systems types and brands Air Intake System Universal Joint Air System Wheel Bearing Anti-lock Braking System (ABS) Lubrication Index Brake Adjustment Luggage Compartment(s) Cab Heater-Air Conditioner Electrical Engine Accessories Maintenance Schedule Engine Cooling System Mirrors...
  • Page 212 PART 11: SUBJECT INDEX Interaxle Differential Tire Load and Inflation Tables Manually Releasing Spring Brakes Transmission Operating the Clutch lubrication Overheated Brakes warmup Parking Brakes and Their Use Pyrometer Vehicle Retarders driving Setting Ride Height Vehicle Identification Number Shifting The Transmission Vehicle inspections Starting Procedure Vehicle weight rating...

Table of Contents

Save PDF
