From Bicom Systems Wiki
Contents
1 Introduction - How to use the Sipura SPA 2000 with PBXware
2 Registering Sipura SPA 2000
2.1 Requirements
2.2 Manual Configuration
2.3 Auto Provisioning
3 Glossary
Introduction - How to use the Sipura SPA
2000 with PBXware
This "How to" is written as a general guide on how to use your Sipura SPA 2000 with PBXware
using
2.0.13(g)
Sipura SPA 2000 firmware. It covers the most common tasks required to have
your Sipura SPA 2000 working efficiently.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Sipura Technology SPA 2000
Summary of Contents for Sipura Technology SPA 2000
- Page 1 3 Glossary Introduction - How to use the Sipura SPA 2000 with PBXware This "How to" is written as a general guide on how to use your Sipura SPA 2000 with PBXware using 2.0.13(g) Sipura SPA 2000 firmware. It covers the most common tasks required to have...
- Page 2 - The Sipura SPA 2000 "Dial Plan" field value needs to be changed using web interface. STEP ONE: Sipura SPA 2000 Web Interface. 1. Open a new browser window and enter the IP address in order to access the Sipura SPA 2000 administration interface.
-
Page 3: Manual Configuration
4. Navigate down to "Dial Plan" group. Clear the "Dial Plan" field, then copy and paste the following value. (*x.|**x.|*xx|[3469]11|0|00|[2-9]xxxxxx|1xxx[2-9]xxxxxx|xxxxxxxxxxxx.) 5. Click on the "Submit All Changes" button. The Sipura SPA 2000 will reboot for changes to take effect. Manual Configuration UAD Settings STEP ONE: PBXware IP address. - Page 4 STEP THREE: UAD status. 1. Make sure the UAD is enabled. To check the UAD status, navigate to "Settings:UAD", and click on the "edit" icon corresponding to "Sipura SPA 2000".
- Page 5 2. Make sure "Status" is set to "Active", "Auto provisioning" is set to "No" and "DHCP" is set to "Yes".
- Page 6 STEP ONE: Add Extension. 1. Navigate to "Extensions". Click on "Add Extension". 2. The standard options window (below) will be shown. 3. Select Sipura SPA 2000 from the "UAD" select box. 4. Select Location: "Local" or "Remote". Note: -"Local" is for all extensions registered on LAN.
- Page 7 5. Click on the "Next" button. STEP TWO: Extension values. 1. Enter values into the required field text boxes. REQUIRED FIELDS: Name: Enter a name for the extension being created. Example: John Smith. E-mail: Enter the e-mail address associated with this extension. This e-mail address will receive all system notification messages.
- Page 8 - Connect the other end of the cable to an analog telephone. Registering ATA - The Sipura SPA 2000 needs electricity, so plug the adapter into its jack and connect it to the electricity network. - Connect the ethernet port to a hub, router or switch as to access LAN.
- Page 9 Find out the IP address of the Sipura SPA 2000 connected to network. 1. Dial ****. 2. Dial 110#. STEP THREE: Sipura SPA 2000 Web Interface. 1. Open a new browser window and enter the IP address in order to access the administration interface.
-
Page 10: Auto Provisioning
Other fields: Other "options" or "fields" should be left blank or as is by default, they have no importance for registering your Sipura SPA 2000 to PBXware. - Conclusion: If everything is done as above described, you should have successfully registered *123 your Sipura SPA 2000 to PBXware. - Page 11 3. Login to PBXware with your e-mail address and password. STEP THREE: UAD status. 1. Make sure the UAD is enabled. To check the UAD status, navigate to "Settings:UAD" and click on the "edit" icon corresponding to "Sipura SPA 2000".
- Page 12 2. Make sure "Status" is set to "active", "Auto provisioning" is set to "No" and "DHCP" is set to "Yes".
- Page 13 STEP ONE: Add Extension. 1. Navigate to "Extensions". Click on "Add Extension". 2. The standard options window (below) will be shown. 3. Select Sipura SPA 2000 from the "UAD" select box. 4. Select Location: "Local" or "Remote". Note: -"Local" is for all extensions registered on LAN.
- Page 14 Enter the e-mail address associated with this extension. This e-mail address will receive all system notification messages. Example: john@domain.com. Auto provisioning: Set to "Yes". MAC Address: Sipura SPA 2000 MAC address. Example: 001646f5f797 Creating Extension/Extensions Add an example with details filled in 2. Click on the "Save" button.
- Page 15 - Connect the other end of the cable to an analog telephone. Registering ATA - Your Sipura SPA 2000 needs electricity, so plug the adapter into its jack and connect it to the electricity network. - Connect the ethernet port to a hub, router, or switch as to access LAN.
- Page 16 2. On the display, scroll to the IP address using the "Up and Down button". 3. Press the "Menu" button. STEP THREE: Sipura SPA 2000 Web Interface. 1. Open a new browser window and enter the IP address in order to access the Sipura SPA 2000 administration interface. Example: http://192.168.1.101 an example with IP address 2.
- Page 17 5. Navigate to the bottom of the page and click on the "Submit All Changes" button. The Sipura SPA 2000 will reboot for changes to take effect. - Conclusion: If everything is done as above described, you should have successfully registered your Sipura SPA 2000 to PBXware.
- Page 18 2. Navigate down to the "Auto Provisioning" group. - LAN IP: Enter your PBXware local (LAN) IP address. Example: 192.168.1.2 - WAN IP: Enter your PBXware wide (WAN) IP address. Example: 89.146.131.130 an example with details filled in 3. Click on the "Save" button. You'll be prompted to click on the "OK" button to restart PBXware for changes to take effect.
- Page 19 office or small group of buildings such as a college. - LAN = Local Area Network. - PIN = Personal Identification Number. - Remote = Network devices that are managed or controlled from a network system other than the system to which they are directly connected. - Router = A device that forwards data packets from one local area network (LAN) or wide area network (WAN) to another.
