Summary of Contents for LFF LWS163
- Page 1 WIRELESS WEATHER STATION Ref LWS163 -USER MANUAL-...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Please read this user manual carefully before you use this product. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC The lighting flash and arrow The exclamation point within head within the triangle is the triangle is a warning sign SHOCK DO NOT REMOVE COVER (OR BACK). - Page 3 1 WEATHER STATION UNIT 9 10 11...
-
Page 4: Main Features
Touch buttons on the top (for adjust the backlight) Outdoor temperature & humidity display Current time display “Mode”key “Settings” key Weather forecast display “Alarm Active/Deactive” key Moon Phase “Channel” key Atmospheric pressure and atmospheric pressure trend animation “Down /Rcc”key “Up /Mem”key Weekday Month &... - Page 5 3 OUTDOOR TEMPERATURE & HUMIDITY SENSOR STATION 3.1 MAIN FEATURES • Temperature & Humidity measurement. • Low Battery Indication. 3.2 TX BUTTONS ON THE BACK RF Channel Selection. Battery Compartment for 2 x AAA, 1.5V batteries. 3 Press and release to interchange the temperature unit between degree Celsius and degree Fahrenheit.
- Page 6 4 FIRST TIME TO USE 4.1 PAIR THE OUTDOOR REMOTE SENSOR First of all, it needs to do the pairing between outdoor remote sensor and weather station. Please follow below procedure to pair the sensor. 1). Plug the included DC adaptor into the weather station. (optional) insert 2 new “AAA”alkaline batteries for backup.
- Page 7 4). Keep the outdoor sensor 5-10 feet from the weather station. 5). When the RF connection is established, the temperature and humidity readings will appear on the station. 6). After 5 min sensor pairing time, the weather station will automatically receive atomic clock signal, the tower icon will be flashing.
- Page 8 8). Put the weather station away from interference, such as electronic devices (TV, computer, microwave, radio, etc.) 9). When the atomic clock signal is received successfully , the time and date will be updated. 10). Allow the outdoor sensor and weather to sit together for 15 minutes to establish a strong connection.
- Page 9 During atomic clock reception, press and hold "Down /RCC" key over 3s to exit atomic clock reception. For information about WWVB, visit www.nist.gov/pml/div688/grp40/wwvb.cfm 6 SWITCH DIFFERENT MODE DISPLAYS In Normal display, press to switch into different modes display. Time/Calendar → Alarm → Atmospheric pressure → Indoor/Outdoor temperature &...
- Page 10 7 SETTIME ZONE, TIME, DATE etc. In Normal display, press once switching to the time/Calendar display. Press and hold over 2s to enter time set mode, time zone (Default: PST) will be flashing. Press and release to adjust the values. Hold to adjust quickly. Press and release to confirm and move to the next item.
-
Page 11: Set Alarm Time
For the Time Zone Setting, there are 8 time zones to be selected: AST, NST, EST, CST, MST, PST, AKT, HAT. Set the Time Zone to your area for the hours to be correct. 9 SET ALARM TIME 1. In Normal display, press twice switching to the alarm time display. -
Page 12: Alarm Setting Order
9.2 ALARM SETTING ORDER AL1 on → AL2 on → AL1 & AL2 on → AL1 & AL2 off. 10 SNOOZE When the alarm rings, press button to pause the alarm for 5 minutes. The alarm icon (bell) and Zz icon keep flashing. Press any button except to silence alarm for 24 hours. - Page 13 12 INDOOR & OUTDOOR TEMPERATURE ALERT First you will arm the alert you wish to set, then you set the alert value. If an alert is not armed (OFF), you will skip that alert value and move to arm the next alert.
-
Page 14: Hi/Lo Temperature & Humidity Records
12.2 Alert Sounds: • When armed alert value is reached, station will beep 5 times each minute, until out of alert range. • The flashing alert icon will indicate the type of alert HI or LO. • Press any button to stop the alert from sounding. 13 HI/LO TEMPERATURE &... -
Page 15: Temperature Trend Arrows
15 TEMPERATURE TREND ARROWS The temperature trend indicators update with every 15 minutes and look back over the past hour. • Change in temperature (2°F/1°C) Temperature has Temperature has Temperature has risen > 1°C/2°F in not changed more fallen < 1°C/2°F in the past hour than 1°C/2°F in the the past hour... -
Page 16: Low Battery Indication
Light Snow Heavy Rain Heavy Snow • When the forecast would normally be light rain or heavy rain, and the outdoor temperature is below 32°F, the forecast will show snow. 18 LOW BATTERY INDICATION • Low battery icon by outdoor humidity, replace batteries in the sensor. •... -
Page 17: Care And Maintenance
22 SWITCH READING DISPLAY FOR THE OUTDOOR TEMPERATURE/HUMIDITY SENSORS • In Normal display, press and release to interchange the reading display for the outdoor temperature/humidity sensors. • There are CH1, CH2 CH3 or cycle display. • In cycle display mode, the outdoor temperature/humidity reading will be switched every 3s. -
Page 18: Specifications
25 SPECIFICATIONS Indoor • Temperature Range: 14°F－122°F (-10°C－50°C) • Humidity Range: 1－99% RH Outdoor • Temperature Range: -40°F－158°F (-40°C－70°C) • Humidity Range: 1－99% RH Note: Temperature below -4°F require Lithium batteries in the outdoor sensor • Distance: 330ft (100m) • Transmission frequency: 433MHz Power •... - Page 19 NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
-
Page 20: Weather Station
WEATHER STATION LWS163 support@lfftech.com Made in China...
Need help?
Do you have a question about the LWS163 and is the answer not in the manual?
Questions and answers
how do i set time and date in lws163
To set the time and date on the LFF LWS-163 Weather Station:
1. Time Zone will flash first. Use the buttons to adjust. Hold to adjust quickly.
2. Press and release to confirm and move to the next item.
3. Follow the setting order:
- Time Zone (AST, NST, EST, CST, MST, PST, AKT, HAT)
- DST On/Off
- Year
- Date Format
- Month
- Day
- 12/24 Hour Format
- Hour
- Minute
- Second
4. After setting each item, press and release the button to confirm and move to the next one.
5. "End of Setting" appears when finished.
This answer is automatically generated
buttons are not working
If the buttons on the LFF LWS163 are not working, the issue could be that the backup batteries are dead.
This answer is automatically generated
I cannot get my lws 163 station to show the outdoor temp and humidity readings.How can I get this to display?
