Select Models Certified by
CSA International *
Meets: ANSI Z21.97-2010
ACR97-003
WARNING
•Improper installation, adjustment, alteration, service, or maintenance can cause injury or property
damage. Read the installation, operating, and maintenance instructions thoroughly before installing or
servicing this equipment.
WARNING
•Do not store or use gasoline or other flammable vapors and liquids in vicinity of this or any other
appliance.
•An LP-cylinder not connected for use shall not be stored in the vicinity of this or any other appliance.
DANGER
If you smell gas:
1) Shut off gas to appliance.
2) Extinguish any open flame.
3) If odor continues, keep away from appliance and immediately call gas supplier or fire
department.
* Select Models CSA Certified: Bowl: 19SS90HWI, 25SS150HWI, 37SS300HWI-HC,
Hearth Products Controls Co.
Remote Electronic HWI Fire Pit
Installation & Operation Instructions
(Exclusive Thermocouple / Hot Wire Ignition System)
WARNING: FOR OUTDOOR USE ONLY
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
& 43SS400HWI-HC
Flat: 18FSS90HWI, 24FSS150HWI, 36FSS300HWI-HC,
& 42FSS400HWI-HC
828
706 Congress Park Dr.
Dayton, OH 45459
1
Advertisement
Table of Contents
Related Manuals for Hearth Products Controls 19SS90HWI
Summary of Contents for Hearth Products Controls 19SS90HWI
- Page 1 3) If odor continues, keep away from appliance and immediately call gas supplier or fire department. INSTALLER: Leave this manual with the appliance. CONSUMER: Retain this manual for future reference. * Select Models CSA Certified: Bowl: 19SS90HWI, 25SS150HWI, 37SS300HWI-HC, & 43SS400HWI-HC Flat: 18FSS90HWI, 24FSS150HWI, 36FSS300HWI-HC, & 42FSS400HWI-HC...
- Page 2 We require that our products be installed and serviced by professionals who are certified in t he U.S. by NFI (National Fireplace Institute) or in Canada by WETT (Wood Energy Technical Training). Installer must follow all instructions carefully to ensure proper performance and safety. Hearth Products Controls Company is not responsible for your actions.
- Page 3 HWI Fire Pit Clearances Under Valve Box 6” Sides Surrounding Fire Pit 48” Overhead Clearance 120” IMPORTANT: Overhead Clearance applies to tree limbs and branches only- DO NOT install unit under overhang or ceiling. CONSTRUCTION OF THE ENCLOSURE WARNING: THERE MUST BE AN ELECTRICAL (WALL SWITCH OR BREAKER) AND GAS SHUTOFF ON THE EXTERIOR OF THE FIRE PIT OR ON ADJACENT WALL TO ALLOW FOR EASY ACCESS FOR SHUTDOWN OR IN THE CASE OF AN EMERGENCY.
- Page 4 pan and valve box to protect internal components from heat damage. This may need to be trimmed on smaller enclosures for proper fit. PLEASE USE THIS AT ALL TIMES. • WARRANTY REQUIREMENT: Warranty is void if valve box is opened •...
- Page 5 OVERHEATING: The fire pit will automatically close gas valve if temperature exceeds 175º F inside valve box to prevent component damage. When unit cools below 175º F, the unit will automatically restart. To correct overheating, ensure enclosure has adequate ventilation- see “Construction of Enclosure”. FIRE PIT SHUTDOWN 1.
- Page 6 3) BLOWOUT BOX: Do not cover vents 3) Apply top coat of glass to lava rock, with lava rock- leave open. Do not again just deep enough to hide lava rock allow any rock to block flame opening. and pan. Blowout Box: Do not cover blowout box vents or opening with lava rock or glass- this must remain open.
- Page 7 Please see list below for replacement parts as needed. Please contact your known dealer for these parts- if unsure please contact HPC and we will be happy to help you. Bowl Style Pan: 37SS300HWI- Component / Model # 19SS90HWI 25SS150HWI 31SS300HWI 43SS300HWI-HC Fire Ring...
- Page 8 TPHC-36 x 2ea. TPHC-48 x 2ea. Limited Warranty Hearth Products Controls Company (HPC) warranties HWI fire pits against manufacturing defects that prevent safe and correct function as follows: ●Electronics, Gas Valve, & Pilot Assembly: Commercial-6mos; Residential- 1 yr. ●Stainless Steel Pan, Fire Ring, & Valve Box: Commercial-1yr.; Residential 3yrs.
