Fluke Network Time Machine Portable 1.2 Quick Start Manual

Your Network Time Machine (NTM) comes with the software already installed and licensed.
After you have unpacked it from its shipping container, proceed as follows:
1. Connect cables as shown in the figure below.
2. Turn on the AC power and wait for the computer to boot up. The power switch is located in
the upper right hand corner when facing the rear of the computer.
3. Start the NTM application by selecting Start > All Programs > ClearSight > ClearSight
Network Time Machine.
4. When the Login screen appears, click OK. No password is needed.
Connect one of these
Ethernet ports to your
control network for
remote operation of
this NTM using
Remote Desktop.
Connect these
Ethernet ports to the
network(s) from
which you want to
monitor, capture
frames, and perform
analysis.
Network Time Machine
Quick Start Guide: Portable 1.2 Model
Connect a USB
keyboard and
mouse here.
Connect the
power cable
here.
