DR
®
WALK-BEHIND LEAF AND LAWN VACUUM
SAFETY & OPERATING INSTRUCTIONS
Model:
PILOT XT
PILOT XTSP
Serial No.
Order No.
Read and understand this manual and all instructions before operating the DR WALK-BEHIND LEAF AND LAWN
VACUUM.
DR Power Equipment
Toll-free phone: 1-800-DR-OWNER (376-9637)
Website: www.DRpower.com
Advertisement
Related Manuals for DR PILOT XT
Summary of Contents for DR PILOT XT
- Page 1 WALK-BEHIND LEAF AND LAWN VACUUM SAFETY & OPERATING INSTRUCTIONS Model: PILOT XT PILOT XTSP DR Power Equipment Serial No. Toll-free phone: 1-800-DR-OWNER (376-9637) Order No. Website: www.DRpower.com Read and understand this manual and all instructions before operating the DR WALK-BEHIND LEAF AND LAWN VACUUM.
-
Page 2: Table Of Contents
Chapter 2: Setting Up The DR ® WALK-BEHIND LEAF AND LAWN VACUUM .................. 7 Chapter 3: Operating the DR WALK-BEHIND LEAF AND LAWN VACUUM ..................14 Chapter 4: Maintaining the DR WALK-BEHIND LEAF AND LAWN VACUUM ................... 17 Chapter 5: Troubleshooting .................................. 23 Chapter 6: Parts Lists and Schematic Diagrams .......................... -
Page 3: Chapter 1: General Safety Rules
Shown below are copies of all the Safety and Information labels that appear on the equipment. Take a moment to study them and make a note of their location on your DR WALK-BEHIND LEAF AND LAWN VACUUM as you set up and before you operate the unit. - Page 4 Keep children out of the work area and under the watchful care of a responsible adult. • Be alert and always turn off the DR Walk-Behind Leaf and Lawn Vacuum engine if children or pets enter the work area. •...
- Page 5 • Allow the engine to cool completely and empty the debris bag before storing the DR Walk-Behind Leaf and Lawn Vacuum in any enclosure. Remember, decomposing material generates heat and could start a fire. Never store the machine with gas in the tank or a fuel container, near an open flame or spark such as a water heater.
- Page 6 Keep in mind that the operator or user is responsible for accidents or hazards occurring to other people, their property, and themselves. • Your DR Walk-Behind Leaf and Lawn Vacuum is a powerful tool. Exercise extreme caution at all times. The design of this machine is to vacuum debris. Do not use it for any other purpose. •...
-
Page 7: Walk-Behind Leaf And Lawn Vacuum
WALK-BEHIND LEAF AND LAWN VACUUM It may be helpful to familiarize yourself with the controls and features of your DR WALK-BEHIND LEAF AND LAWN VACUUM as shown in Figures 2a and 2b before beginning these procedures. If you have any questions at all, please feel free to contact us at www.DRpower.com. - Page 8 4 ......A0000330872 - Bag, Paper, 5 Pack ......1 Compare the contents of the Shipping Crate, with the Parts Supplied list above. If you have any questions, please contact us at www.DRpower.com or call 1-800-DR-OWNER (376-9637) for assistance. Figure 3 ®...
- Page 9 1. Remove the machine from the pallet and place it on a clean, level surface for assembly (Figure 4). 2. For the Pilot XT: Remove the Upper Handlebar and place it to the side. For the Pilot XTSP: Rotate the Upper Handlebar and set it on the ground...
- Page 10 Adding the Engine Oil and Gasoline • You must add Oil before starting the Engine. This machine is shipped without Oil. Traces of Oil may be in the reservoir from factory testing, but Height Adjust you must add Oil before starting the Engine. Fill the reservoir slowly, Lever checking the level frequently to avoid overfilling.
- Page 11 Connecting the Battery Wire (Electric Start Models) Protective Cap We ship all Electric-Starting DR WALK-BEHIND LEAF AND LAWN VACUUMS with the Black Negative Battery Wire disconnected. This prevents the Battery from discharging during shipment. You must connect the Battery wire before using your machine.
- Page 12 Bag Clamping Ring Figure 16 Figure 17 Figure 18 ® LEAF and LAWN VACUUM...
- Page 13 Emptying/Replacing the Collection Bag The Debris bags can be reused if they are in good condition. Do not reuse if there are tears or overly wet/soiled areas. • Replace or empty the Bag as soon as it is full (check by feeling sides of Bag). Overfilling the bag will cause the vacuuming performance to decrease or stop completely and could lead to clogging of the discharge tube, snout, or both.
-
Page 14: Chapter 3: Operating The Dr Walk-Behind Leaf And Lawn Vacuum
Chapter 3: Operating the DR WALK-BEHIND LEAF AND LAWN VACUUM It may be helpful to better familiarize yourself with the features of your DR WALK-BEHIND LEAF AND LAWN VACUUM by reviewing Figure 2 in Chapter 2 before beginning the steps outlined in this Start Pull Cord chapter. - Page 15 Before leaves drop, mow your lawn to the shortest recommended height. Your DR WALK-BEHIND LEAF AND LAWN VACUUM will perform better on short grass. • The DR WALK-BEHIND LEAF AND LAWN VACUUM is designed to be used frequently during periods when leaves are dropping. It is not recommended to let leaves get 4″, or deeper. •...
- Page 16 Adjusting the Vacuum Snout Height The machine may try to fall to the lowest Snout height setting when Raise the Height Adjust Handle is moved out of the slot. Lower The height of the Vacuum Snout can be adjusted to allow you to vary the suction to meet the surface conditions.
-
Page 17: Chapter 4: Maintaining The Dr Walk-Behind Leaf And Lawn Vacuum
1/2" Wrench. Figure 28 Chapter 4: Maintaining the DR WALK-BEHIND LEAF AND LAWN VACUUM Regular maintenance is the way to ensure the best performance and long life of your machine. Please refer to this manual and the Engine Manufacture’s Owner’s Manual for maintenance procedures. Service intervals listed in the checklist below supersede those listed in the Engine Manufacture’s Owner’s Manual. - Page 18 Changing The Engine Oil Tools and Supplies Needed: Fill/Dipstick • Engine Oil (see your Engine Manual for Oil specifications) • Oil Extractor* • Small Funnel • Rags *The Engine does not have a Drain Plug. An Oil Extractor can be used to remove Oil.
- Page 19 Removing/Replacing the Chipper Knife (PILOT XTSP) The PILOT XTSP model is shipped with a sharp Chipper Knife and, depending Chipper upon material being chipped, will remain acceptably sharp for 40 plus hours. Chute When you notice diminished feeding, it is time to replace the knife. You may also choose to have the knife sharpened instead as described on the next page.
- Page 20 Belt Note: Another way to quickly tell what direction the Belt should be assembled Pulley is to see what direction the “V” shaped opening is pointing. The “V” is pointing right when viewed from the left side of the machine. 4.
- Page 21 Assembling the Belt Links This section explains the assembly of the Belt Links and is for reference when installing the Belt onto the machine. The Belt can be assembled by hand but if you are having difficulty twisting the Tabs, Needle Nose Pliers can be used. Be careful not to damage the Tabs when using the Pliers.
- Page 22 Operate the Engine for at least 45 minutes to maintain proper Battery charge. If the Battery loses its charge, you'll need to use a trickle Charger (like the DR Battery Charger) to recharge it. The Charger should have an output of 12 volts at no more than 2 amps.
-
Page 23: Chapter 5: Troubleshooting
Most problems are easy to fix. Consult the Troubleshooting Table below for common problems and their solutions. If you continue to experience problems, contact us at www.DRpower.com or call toll-free 1-800-DR-OWNER (376-9637) for support. Before performing any maintenance procedure or inspection, stop the Engine and wait five minutes to allow all parts to cool. - Page 24 Troubleshooting Table (Continued) YMPTOM OSSIBLE AUSE ORRECTIVE CTION Vacuuming too fast; Clean out housing and vacuum at slower speed. Debris build-up in Vacuuming/Chipper Housing Drive Engagement Cable Loose; Adjust Drive Engagement cable. Loss of traction (XTSP Stretched or broken Drive Belt; Replace Belt. Model) ...
- Page 25 CONTACT US AT www.DRpower.com...
-
Page 26: Chapter 6: Parts Lists And Schematic Diagrams
Chapter 6: Parts Lists and Schematic Diagrams Parts List –Handlebar and Bagger Assembly (XT Model) Note: Part numbers listed are available through DR Power Equipment. Ref# Part# Description Ref# Part# Description A0000330797 Tube, Exhaust 350381 Nut, Nylon Lock, Flange, 10-24, ZP... - Page 27 Schematic – Pro Handlebar and Bagger Assembly (XT Model) CONTACT US AT www.DRpower.com...
- Page 28 Parts List – Drive Assembly (XT Model) Note: Part numbers listed are available through DR Power Equipment. Ref# Part# Description Ref# Part# Description A0000330802 Frame A0000330843 Wheel, 8″ A0000331003 Housing, Impeller A0000330831 Wheel, 10″ A0000330904 Shield, Deflector A0000330832 Cover, Wheel, 10″...
- Page 29 Schematic – Drive Assembly (XT Model) CONTACT US AT www.DRpower.com...
- Page 30 Parts List –Handlebar and Bagger Assembly (XTSP Model) Note: Part numbers listed are available through DR Power Equipment. Ref# Part# Description Ref# Part# Description A0000330797 Tube, Exhaust A0000330875 Bolt, Barrel Female, 10-24 X 1/4″, 395721 Lever, Self Propel Drive A0000330926...
- Page 31 Schematic – Pro Handlebar and Bagger Assembly (XTSP Model) CONTACT US AT www.DRpower.com...
- Page 32 Parts List – Drive Assembly (XTSP Model) Note: Part numbers listed are available through DR Power Equipment. Ref# Part# Description Ref# Part# Description A0000330802 Frame A0000330855 Pulley, 3L V-Belt, 3.0″ OD, .38″ Shaft A0000331003 Housing, Impeller A0000330862 Belt, Linked, 3L...
- Page 33 Schematic – Drive Assembly (XTSP Model) CONTACT US AT www.DRpower.com...
- Page 34 WALK-BEHIND LEAF AND LAWN VACUUM is fit for ordinary purposes for which a product of this type is used. DR Power Equipment however, limits the implied warranties of merchantability and fitness in duration to a period of two (2) years in consumer use, ninety (90) days for any other use.
- Page 35 Notes: CONTACT US AT www.DRpower.com...
- Page 36 • If your DR WALK-BEHIND LEAF AND LAWN VACUUM will be idle for more than 30 days, we recommend using a gas stabilizer. This will prevent sediment from gumming up the Carburetor. If there is dirt or moisture in the gas or tank, remove it by draining the tank.
