Description:
DESK EDGE TANGENT LIGHT
Tangent Task Light with Edge Clamp (YLTT2)
Installation Guides
A
B
D
Date:
May 2018
COM_407b
Part and Product Identification
A - Tangent Light x1
B - Upper Base Assembly x1
C - Socket Headed Cap Screw x4
D - Lower Base Assembly x1
Page No:
1 of 3
Rev. No: 0
