Summary of Contents for BKT Elektronik ACBS
- Page 1 BKT Elektronik - Headquarter Poland, Lochowska 69 Str. 86-005 Biale Blota Phone: +48 52 36 36 750 e-mail: export@bkte.pl BKT ACBS Access Control Bus System - the access control system with RS485 bus interface - installation and configuration manual - version 5 ©...
-
Page 2: Table Of Contents
9.5 Cabinet door configuration ..................................56 9.6 Cold/hot aisle containment sliding door configuration .......................... 61 9.7 Permanent opening of the cold/hot aisle containment sliding door ...................... 64 BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface... - Page 3 9.11 Emergency button use signalling ................................81 9.12 Adding user group ....................................87 9.13 Adding user to group ....................................88 10 DOCUMENT REVISIONS ....................................... 92 BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
-
Page 4: Introduction
It is also possible to configure the so-called committee entry when two users have to present cards to open the door. • Depending on the system, the readers may have an integrated keypad (BKT ACBS) or may be integrated in a cabinet handle (BKT ACWS). It is also possible to use any reader with a Wiegand interface. -
Page 5: Bkt Acbs And Bkt Acws Systems
BKT ACBS and BKT ACWS SYSTEMS The BKT ACS access control system is available in two variants: • BKT ACBS (Access Control Bus System) - system based on the RS485 bus, which is used by controller to communicate with card readers. •... -
Page 6: Bkt Acbs System Components
Temperature: 0°C - 60°C, Humidity: 0% - 95% RH (no condensation) Housing material Steel Housing colour Black, RAL 9005 Housing protection rating IP20 Compliance with directives 2014/35/EU (LVD), 2011/65/EU (RoHS) Part number 122AC001000 BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface... - Page 7 Power cord, plug IEC 320 C13 10A, plug DIN 49441(unischuko) 16A, 3x1,0 mm2, black, 2m 11480784.2 Power cord, plug IEC 320 C13 10A, plug IEC 320 C14 10A, 3x1,0 mm2 black, 2m 11480785.2 BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
- Page 8 3.1.4 Controller wiring schematic BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
-
Page 9: Ab101 Secondary Set
Temperature: 0°C - 60°C, Humidity: 0% - 95% RH (no condensation) Housing material Steel Housing colour Black, RAL 9005 Housing protection rating IP20 Compliance with directives 2014/35/EU (LVD), 2011/65/EU (RoHS) Part number 122AB001011 BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface... - Page 10 Power cord, plug IEC 320 C13 10A, plug DIN 49441(unischuko) 16A, 3x1,0 mm2, black, 2m 11480784.2 Power cord, plug IEC 320 C13 10A, plug IEC 320 C14 10A, 3x1,0 mm2 black, 2m 11480785.2 BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
- Page 11 3.2.4 Secondary set wiring BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
-
Page 12: Card Readers
RUD-1 - USB-RS485 interface/programmer 122AA101000 EMC-1 - UNIQUE EM 125 kHz thin proximity card 122AA101004 MFC-2 - MIFARE Classic 1k 13.56 MHz thin proximity card 122AA101011 BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface... - Page 13 Dimensions: 153 x 46 x 23 (HxWxD) More information can be found at www.roger.pl 3.3.4 AR121 card reader wiring schematic To controller To cabinet swinghandle BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
- Page 14 Dimensions: 153 x 46 x 23 (HxWxD) More information can be found at www.roger.pl 3.3.6 AR122 Card reader wiring schematic To controller To sliding doors controller BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
- Page 15 Dimensions: 153 x 46 x 23 (HxWxD) More information can be found at www.roger.pl 3.3.8 AR131 Card reader wiring schematic To controller To cabinet swinghandle BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
- Page 16 Dimensions: 153 x 46 x 23 (HxWxD) More information can be found at www.roger.pl 3.3.10 AR132 Card reader wiring schematic To controller To sliding doors controller BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
-
Page 17: Cabinet Swinghandles
The cable is used to connect the reader AR121, AR131 to AL200 swinghandle. Length: 0.55m, terminated with 10-pin male and 8-pin female connectors. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface... - Page 18 The cable is used to connect the reader AR121, AR131 to AL300 swinghandle. Length: 0.55m, terminated with 10-pin male and 6-pin female connectors. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
-
Page 19: Door Sensors
5m long wire terminated with an RJ45 plug to connect to the controller. The set has a two metal brackets that fixes the reed switches to the cabinet frame. 3.5.4 AD102 Door sensor wiring BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface... -
Page 20: Connection Cables
The cable is used to connect the reader AR121, AR122, AR131, AR132 with the cold/hot aisle containment sliding door controller. 5m long, terminated with RJ45 plug and male 10-pin connector. 3.6.4 AW113 cable wiring BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface... - Page 21 The cable is used to connect the reader AR121, AR131 to AL200 swinghandle. Length: 0.55m, terminated with 10-pin male and 8-pin female connectors. 3.6.8 AW212 cable wiring BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
-
Page 22: System Software
Connections are made using dedicated wires terminated from the controller's side with RJ45 plugs. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface... -
Page 23: System Structure In Cold/Hot Aisle Containment
The controller is connected to the local LAN network, which is accessed by a computer with system configuration and management software. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface... -
Page 24: Installation Of Cabinet Door Devices
Then press the controller onto the two plastic spacers located on the bottom plate of the housing. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface... - Page 25 Put the housing cover and tighten the screws. 5.1.3 Installing in the cabinet Attach the 19'' brackets to the housing using the provided four M3 screws (two on each side). BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
- Page 26 Pay attention to the Rail A and Rail B markings. Install the AC100 controller in the rack. Suggested position - at the top at the back of the cabinet. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
- Page 27 Rail A and Rail B. Make connections of the other devices according to 5.1.4 Connecting devices to the AC100 controller. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
-
Page 28: Ab101 Secondary Set Installing
AB101 secondary set installing 5.2.1 Package contents Obudowa AB101 Power supplies 1U 19’’ bracket Bolts set Quick Start Guide housing bracket BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface... - Page 29 0.14mm2. not exceed 100m. Use UTP cat 5e cable. Sliding AL200 AL200 door swing swing controller handle handle BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
-
Page 30: Ar121, Ar131 Readers Installing
Open the reader casing by unscrewing the screw at the bottom. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface... -
Page 31: Al200 Swinghandle Installing
More information on this subject can be found in the AL200 handle manual available on the website www.bkte.pl. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface... - Page 32 Then place the electronic handle in the cut-out in the door. Screw in all the elements you just unscrewed. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
-
Page 33: Al300 Swinghandle Installing
AL300 swinghandle installing Installation of the AL300 handle is similar to the AL200 handle. Additional mechanical components, including a cogwheel mechanism, may be required. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface... -
Page 34: Door Sensors Installing
RJ45 plug or its spare rolled up and fixed in such a way that it does not interfere with other devices in the cabinet. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface... -
Page 35: Installation Of Cabinet Door Wiring
Fix the cables in the cabinet using cable ties. Leave a spare cord between the door and the cabinet frame to allow the door to be opened. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface... - Page 36 Connect the AL200 handle to the reader using the AW212 cable or the AW112 cable (for the AL300 handle). Connect the cables to the reader and arrange them carefully. Secure them with electrical tape. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
- Page 37 Screw on the reader connector cover. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
-
Page 38: Diagram Of Functional Circuits For Operating The Cabinet Door
Diagram of functional circuits for operating the cabinet door BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface... -
Page 39: Installation Of Cold/Hot Aisle Containment Sliding Door Devices
Fix the buttons in dedicated places on the beam above the sliding door, as shown in the photo, or on the optional frame installed behind the sliding doors. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface... -
Page 40: Installing Optional Exit Buttons
Make connections as shown in the diagram 6.6 Connection diagram of sliding kiosk door control devices. Emergency AW113 cable button Exit button Sliding door controller BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface... -
Page 41: Connection Diagram Of Sliding Kiosk Door Control Devices
Connection diagram of sliding kiosk door control devices BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface... -
Page 42: Diagram Of Functional Circuits For Operating The Sliding Door
Diagram of functional circuits for operating the sliding door BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface... -
Page 43: Device Low Level Configuration
2. To run the firmware update on your device, select Tools-> Update firmware from the menu. Configuring the controller It is recommended to start a new configuration from restoring all default values. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface... - Page 44 Send settings to the device - click Send to Device button. Ending the controller low level configuration 1. In Roger VDM menu select Device-> Disconnect. 2. The controller will be rebooted. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
-
Page 45: Card Reader Low Level Configuration
3. The reader is ready for low-level configuration After completing the configuration, put the MEM jumper back, which will enable later remote configuration of the reader from the VISO program. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface... - Page 46 RogerISP software available at www.roger.pl. Configuring the reader It is recommended to start a new configuration from restoring all default values. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
- Page 47 Input IN3 – handle sensor Input IN3 – exit button Output REL – lock Output REL – lock Output IO1 - LED Output IO1 - LED BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
-
Page 48: Svc Software
RogerSVCSetup.exe. Then follow the windows that appear. It is necessary to select Install communication service Installing: Licence service Integration service Virtual controller service is not needed. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface... -
Page 49: Svc Software Configuration
SVC software configuration Open the service management application from the taskbar shortcut. Click on Database connection. Click on Configure connection. Click on Select database. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface... - Page 50 See section 9.2 Database configuration. Enter the database password if it was created and click OK. Go back to the main window. Click on Communication service. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
- Page 51 Click Start Go back to the main window. Services have been configured. Close the window. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
-
Page 52: Viso St Software
To add a new connection to the database, select System->Add Connection If this is the first time you run VISO, go to the next step. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface... -
Page 53: Controller Configuration
Enter the name of the subsystem to which the controller will belong - eg. Server room or DataCenter. Click Next. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface... - Page 54 Select Run Device Discovery Process. Click Run. The controller and all the readers connected to it should appear on the list. Click Finish. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
-
Page 55: Data Synchronising
Data synchronisation is an uploading to the system controllers the configuration created in the VISO software. For this purpose: Choose Synchronisation tab. Then click Synchronise. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface... -
Page 56: Cabinet Door Configuration
Choose Wizards->Add Access Door. In the pop up windows: Choose Read-in only (the door with card reader on one side). Click Next. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface... - Page 57 Drop down the Door Lock Output list and select REL1 from the appropriate card reader. Drop down the Door Contact Input list and select IN1 from the appropriate card reader. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
- Page 58 The program will suggest a name (C1_Cab-01- front_IN_AUTH). Choose Create new Authorisation. Click Next. System saves the settings to the database. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
- Page 59 Click on the door, which just has been added to the system – C1_Cab-01-front. Choose Inputs tab. Click Add. In the pop up window: Click on + in the field Input. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
- Page 60 Confirm the suggestion by clicking Yes Confirm the input line by clicking OK In the Function field, select the function [130]: Door Contact Click OK BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
-
Page 61: Cold/Hot Aisle Containment Sliding Door Configuration
Choose Wizards->Add Access Door. In the pop up windows: Choose Read-in only (the door with card reader on one side). Click Next. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface... - Page 62 Drop down the Door Lock Output list and select REL1-lock from the appropriate card reader. Drop down the Door Contact Input list and select IN1-door sensor from the appropriate card reader. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
- Page 63 The program will propose the name (C1_Aisle-01-front_IN_AUTH). Choose Create new Authorisation. Click Next. System savs the settings to the database. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
-
Page 64: Permanent Opening Of The Cold/Hot Aisle Containment Sliding Door
F1 and again apply the card. In the system tree view, click right on System->Networks-> ->DataCenter (configurable name)> C1 (configurable controller name)-> Access Doors and select Open BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface... - Page 65 Drop down the Object->Name list and select KEYPAD of the reader, which controls aisle door. The program will propose a name for the selected object Confirm the suggestion by clicking Yes BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
- Page 66 See chapter 9.4 Data synchronising. After synchronization the controller will restart and it will be possible to use this functionality. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
-
Page 67: Two User Entry
Select Main tab Select Edit In the newly opened window: Select Advanced Options tab Tick Two Users box Click OK BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface... -
Page 68: Open Door Signalling With Led
LED1 – output OUT1 (IO1) of front door card reader LED2 – output OUT1 (IO1) of rear door card reader Please see 5.8 Diagram of functional circuits for operating the cabinet door. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface... - Page 69 Select input C1_100_IN1 Click Edit Tick Multifunction option Click OK Now you can use again the IN1-door sensor input for configuration. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
- Page 70 Automation Nodes and select Open A new automation node should be created that will be responsible for controlling the LED: Click Add BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
- Page 71 Drop down the Input list and select available IN1 line (door sensor) Drop down the Function list and select [166]: Set Node ON Toggle Click OK BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
- Page 72 It is now necessary to add the output line to which the LED1 is connected Click on Outputs tab. Click Add. In the pop up window: Click on + in Output field BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
- Page 73 In the field Function select [021]: Node Status Select Triggering Method: Set output ON for unlimited time Select Modulation Type: None (steady) Click OK BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
-
Page 74: Tamper Signalling
In the system tree, right-click on System->Networks-> ->DataCenter (configurable name)->C1 (configurable controller name)-> Automation Nodes and select Open. Click Add BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface... - Page 75 Make sure the proper automation node is selected. Click on Inputs tab. Click Add. In the pop up window: Click on + in Input field BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
- Page 76 The program will propose a name for the selected object Confirm the suggestion by clicking Yes. Confirm the input line by clicking OK. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
- Page 77 Click Outputs tab. Click Add. In the pop up window: Click on + in Output field BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
- Page 78 In the field Function select [021]:Automation Node Status Select Triggering Method: Set output ON for unlimited time Select Modulation Type: One Short Pulse repeated every 1s Click OK BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
- Page 79 Drop down the Object->Name list and select LED_SYSTEM output of the reader. The program will propose a name for the selected object Confirm the suggestion by clicking Yes. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
- Page 80 LED and buzz the buzzer once a second until the tamper condition returns to normal. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
-
Page 81: Emergency Button Use Signalling
->DataCenter (configurable name)> C1 (configurable controller name)> Automation Nodes and select Open Click Add Enter the name of automation node eg. C1_Aisle- front_emergency Click OK BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface... - Page 82 Drop down Object->Name list and select input IN2 of the reader, which controls aisle door. The program will propose a name for the selected object Confirm the suggestion by clicking Yes. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
- Page 83 In order to indicate the emergency button use with buzzer and/or LED, the appropriate output lines should be added: Click Outputs tab. Click Add. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
- Page 84 The program will propose a name for the selected object Confirm the suggestion by clicking Yes. Confirm the input line by clicking OK. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
- Page 85 In the next opened window, select the LED of the cold/hot aisle containment sliding door reader: Drop down the Object->Name list and select LED_SYSTEM output of the reader, which controls aisle door. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
- Page 86 LED and buzz the buzzer twice a second until the emergency exit button is reset. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
-
Page 87: Adding User Group
In the system tree view click with the right button on just created user group and select Open Click on Authorisations. Click on Assign. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface... -
Page 88: Adding User To Group
If there is no group, go to the chapter 9.12 Adding user group. Click Next. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface... - Page 89 Click Next. Once again click Next. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
- Page 90 Present the card to the reader. The number of the card read will appear in the Card Number Read field. Click OK. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
- Page 91 Data have been saved to database. Click OK. Upload the configuration to the device, that is, synchronise the controller. Click Send. After synchronisation click Finish. BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
-
Page 92: Document Revisions
Added comparison to the BKT ACWS system. Small updates have been made. November 2018 Added two user entry configuration February 2019 Updated with new AC100 controller and AB101 secondary set June 2022 BKT ACBS - installation and configuration manual of the access control system with RS485 bus interface...
