PARTS LIST

Part Description
#
1 Moulded Case
2 Tube Set (4 piece)
3 Flat Base
4 Angled Toe
5 Plate Head
6 Wedge Head
7 Square V-Hand
8 Male Connector
9 Serrated Cap
10 Rubber Head
11 Valve Body
12 Oil Filter
13 O-Ring
14 Oil Reservoir
15 Seal Ring
16 Thumb Nut
17 Sealing Ring
18 Tie Rod
19 O-Ring
20 Pump Foot
21 Hydraulic Hose
22 Coupling
23 Dust Seal
24 Steel Ball
25 O-Ring
26 Hand Release Valve
27 Sealing Ball
28 Spring
29 Screw
30 Steel Ball
31 Ball Cup
32 Spring
33 Screw
34 Screw Protector
35 O-Ring
QTY Part #
1 36
1 37
1 38
1 39
1 40
1 41
1 42
1 43
1 44
1 45
1 46
1 47
1 48
1 49
1 50
1 51
1 52
1 53
1 54
1 55
1 56
1 57
1 58
1 59
1 60
1 61
1 62
1 63
1 64
1 65
1 66
1 67
1 68
1 69
1
Product Code: RL4TPP
Description
Nylon Sealing Ring
Screw
O-Ring Seal
Piston
Hinge Pin
Circlip
Pivot Pin
Handle Socket
Operating Handle
Handle Grip
Ram Cylinder
Ram Cylinder
Screw Cover
Screw M6
Connecting Nut
Cylinder Screw
O-Ring
Dust Cover
Tension Spring
Circlip
Nylon Sealing Ring
Bushing
O-Ring
Piston Rod
Piston End Cover
Fixed Jaw
Small Piston
Piston Ring
O-Ring
Screw Cover
Moving Jaw
Circlip
Hinge Pin
Spring
QTY
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
