Summary of Contents for commercial cool CCR77LBB
- Page 2 Page 2...
-
Page 3: Table Of Contents
CONTENTS SAFETY INFORMATION Important Safety Instructions ....................... 4-5 Refrigerant ................................. 5 Grounding Instructions ..........................6 Installation Guide ............................7 SET UP & USE Starting Your New Refrigerator ......................8 Parts & Features..............................9 Operating Instructions ..........................10 Food Storage ..............................11 Door Reversal Instructions ........................12-14 CLEANING &... -
Page 4: Safety Information
SAFETY INFORMATION DANGER WARNING CAUTION DANGER - Immediate hazards WARNING - Hazards or unsafe CAUTION - Hazards or unsafe which WILL result in severe practices which COULD result in practices which COULD result in personal injury or death severe personal injury or death minor personal injury IMPORTANT SAFETY INSTRUCTIONS WARNING... -
Page 5: Refrigerant
SAFETY INFORMATION 9. Do not refreeze foods that have been thawed completely. The United States Department of Agriculture in Home and Garden Bulletin No.69 reads: “…You may safely refreeze frozen foods that have thawed if they still contain ice crystals or if they are still cold-below 40˚F. -
Page 6: Grounding Instructions
SAFETY INFORMATION GROUNDING INSTRUCTIONS ELECTRICAL REQUIREMENTS The electrical requirements are a 115 volt 60 Hz, AC only, 15 amp. It is recommended that a separate circuit serving only the product be provided. The product is equipped with a 3-wire cord having a 3-prong grounding plug. It must be plugged into a wall receptacle that is properly installed and grounded. -
Page 7: Installation Guide
SAFETY INFORMATION INSTALLATION GUIDE 1. Unpack your refrigerator by removing all packaging materials like carton, base, foams, adhesive tape, etc. 2. Remove all accessories, internal packaging material used to hold shelves, ice tray, etc. in place. 3. Clean the remains of all adhesive tape used and remove all printed material supplied. -
Page 8: Set Up & Use
SET UP & USE PROTECTION FROM HEAT AND MOISTURE • Do not install your refrigerator in any location where heavy moisture is present or if the location is not properly insulated. This refrigerator is not designed to operate in temperature setting below 50°F. •... -
Page 10: Operating Instructions
SET UP & USE OPERATION INSTRUCTIONS TEMPERATURE CONTROL NOTE: • If the refrigerator/freezer has been placed in a horizontal or tilted position for any period of time wait 24 hours before plugging the unit in. • The settings on the temperature are 0,1,2,3,4,5. Adjust the temperature control to the setting that best suits your needs. -
Page 11: Food Storage
SET UP & USE FOOD STORAGE REFRIGERATOR AND FREEZER INTERIOR SHELF When storing fresh food that is not prepackaged, be sure to wrap or store 1. Carefully tilt the shelf up and slide food in airtight and moisture proof forward until the shelf has been material unless otherwise noted. -
Page 12: Door Reversal Instructions
SET UP & USE DOOR REVERSAL INSTRUCTIONS CAUTION: To avoid personal injury to yourself and/or property, we recommend someone assist you during the door reversal process. Make sure appliance is disconnected from outlet. 1. Use a flat head screwdriver to remove the top hinge cover. - Page 13 SET UP & USE 6. Remove the 2 screws of the middle hinge. 2 screws middle hinge 7. Remove the middle hinge. Lift off the bottom door and gently set it aside. 8. Remove the hole plugs and insert them in the holes of the removed screws. 9.
- Page 14 SET UP & USE 12. Turn over the bottom hinge bracket so the flat edge is facing the outer left side of the unit. Reinstall the pin, nut and washer into the bracket. Re-Insert the leg in the front hole of the bracket and the leg in the middle hole.
-
Page 15: Cleaning & Care
CLEANING AND CARE VACATION AND MOVING HOW TO DEFROST (Refer to Fig A) CARE • For maximum energy efficiency, • When going on vacation, it is best defrost freezer section whenever that you empty all the food from frost accumulates to a thickness of your refrigerator and freezer. -
Page 16: Troubleshooting & Warranty
TROUBLESHOOTING & WARRANTY BEFORE YOU CALL FOR SERVICE IF THE UNIT FAILS TO OPERATE: A) Check to make sure that the unit is plugged in securely. If it is not, remove the plug from the outlet, wait 10 seconds and plug it in again securely. B) Check for a blown circuit fuse or a tripped main circuit breaker. -
Page 17: Troubleshooting
TROUBLESHOOTING & WARRANTY TROUBLESHOOTING Troubleshoot your problem by using the chart below. If the refrigerator still does not work properly, contact W Appliance Co. customer service center or the nearest authorized service center. Customers must never troubleshoot internal components. TROUBLE POSSIBLE CAUSE POSSIBLE REMEDY Refrigerator does not... -
Page 18: Limited Warranty
TROUBLESHOOTING & WARRANTY LIMITED WARRANTY REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF Any repair, replacement, or warranty service, THE CUSTOMER; W Appliance Co. SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL and all questions about this product should be DAMAGES FOR BREACH OF ANY EXPRESS OR directed to W Appliance Co. - Page 19 © 2021 Commercial Cool is a W Appliance Company. All Rights Reserved.
