  • Page 1 HS Series Hot Water Generator Heater Module Operator’s Manual MODELS: HS-3000 1.103-900.0 8.913-943.0-P 12/13/19...
  • Page 2: Machine Data Label

    Machine Data Label Landa HS Operator’s Manual 8.913-943.0 - P...
  • Page 3: Table Of Contents

    Maintenance Schedule ..... . 20 Oil Change Record ......21 Landa HS Operator’s Manual 8.913-943.0 - P...
  • Page 4: How To Use This Manual

    KIT INSTRUCTIONS which came with the kit. It contains replacement parts numbers needed for ordering future parts. NOTE: The manual part number is located on the lower right corner of the front cover. Landa HS Operator’s Manual 8.913-943.0 - P...
  • Page 5: Safety

    Be thoroughly familiar with the controls. available at the time of printing. 3. Stay alert - watch what you are doing. Landa, Inc. reserves the right to make changes at any 4. All installations must comply with local codes. time without incurring any obligation.
  • Page 6 MUST BE WORN. amperage ratings. Do not spray water on or near particules dans l'air et leur projec- electrical components. Do not touch machine with tion à hautes vitesses. Pour éviter les lésions corpo- Landa HS Operator’s Manual 8.913-943.0 - P...
  • Page 7 DO NOT SPRAY area clear of all persons. MACHINE OR ANY PEOPLE, ANIMALS OR 20. Landa will not be liable for any changes made to our ELECTRICAL PARTS. standard machines, or any components not purchased from Landa. Landa HS Operator’s Manual 8.913-943.0 - P...
  • Page 8: Operations

    Spray Gun (Not Included) NOTE: The water in this machine is hot. The Hose, spray gun & wand and attached pressure wand and spray gun must be insulated washer not included on the HS-3000 Landa HS Operator’s Manual 8.913-943.0 - P...
  • Page 9: Assembly Instructions

    CAUTION: Never replace nozzles without engaging the safety latch on the spray gun trigger. ATTENTION: Ne jamais remplacer les buses sans d'abord mettre le dispositif de sécurité sur la détente du pistolet pulvérisateur. Landa HS Operator’s Manual 8.913-943.0 - P...
  • Page 10: Installation

    Adjust burner air settings after stack is the amount of fuel being burned. installed Electrical This machine, when installed, must be electrically grounded in accordance to local codes. Check for proper power supply using a volt meter. Landa HS Operator’s Manual 8.913-943.0 - P...
  • Page 11: Operating Instructions

    NOTE: High pressure hose, nozzles, gun and wand are included with attached pressure washer and not part of model HS-3000. IMPORTANT NOTICE: Read operating instructions of connected pressure washer. Landa HS Operator’s Manual 8.913-943.0 - P...
  • Page 12: Detergent And General Cleaning Techniques

    • Ammoniac ou produits à base d'acide coupler. These chemicals will harm the machine and will NOTE: Detergent cannot be damage the surface being cleaned. applied using red, yellow, green or white nozzles. Landa HS Operator’s Manual 8.913-943.0 - P...
  • Page 13: Rinsing

    à pression. 2. Use compressed air at the inlet hose to blow water out discharge nipple. Landa HS Operator’s Manual 8.913-943.0 - P...
  • Page 14: Maintenance

    Check air inlet to make sure it is not clogged or blocked. Wipe off any oil spills and keep this equipment clean and dry. The areas around the Landa washer should be kept clean and free of combustible materials, gasoline and other flammable vapors and liquids.
  • Page 15: Removal Of Soot And Heating Coil

    Transformer test: (CAUTION 10,000 VOLTS) use defect free insulated screwdriver and keep fingers off blade! Lay blade across one contact: OK if arc will span 1/2" between end of blade and other contact. Landa HS Operator’s Manual 8.913-943.0 - P...
  • Page 16: Fuel Control System

    Consider alternate nozzle configurations from the Landa HS Operator’s Manual 8.913-943.0 - P...
  • Page 17: Coil Removal Hs-3000

    11. Reinstall new or cleaned coil reversing Steps 9 through 1. NOTE: Before step 6, lift coil and tank assembly onto some type of exposed support for ease of removing inlet and discharge fittings. Landa HS Operator’s Manual 8.913-943.0 - P...
  • Page 18: Troubleshooting

    Obstruction in smoke stack objects. Soot build up on coils Clean coils with soot remover. Lime build up in coils Clean inside of coils using Landa’s coil cleaner. Improper burner nozzle See exploded view parts list. Landa HS Operator’s Manual 8.913-943.0 - P...
  • Page 19 Replace as needed. Soot build up on coils Clean coils with soot remover. Lime build up on coils Clean inside of coils using Landa’s coil cleaner. Improper burner nozzle See exploded view parts list. Incoming water to machine warm or Lower incoming water temperature.
  • Page 20: Preventative Maintenance

    Attention to regular preventative maintenance procedures will assist in preserving the performance of your equipment. Contact your Landa dealer for maintenance. Regular preventative maintenance will add many hours to the life of your pressure washer.
  • Page 21: Oil Change Record

    Check pump oil level before first use of your new Power Washer. Change pump oil after first 50 hours and every year or 500 hours thereafter. Use SAE 10W-40 non-foaming oil. Estimated Operating Estimated Operating Date Oil Changed Date Oil Changed Hours Since Last Oil Hours Since Last Oil Month/Day/Year Month/Day/Year Change Change Landa HS Operator’s Manual 8.913-943.0 - P...
  • Page 22 Notes Landa HS Operator’s Manual 8.913-943.0 - P...
  • Page 23 8.913-943.0 • Printed in U.S.A.
