BTR-1020
Bluetooth music receiver
With SBC supported
Feature
◎ SBC codec support
◎ A2DP Bluetooth profile supported
◎ 33 feet (10M) effective range
◎ Audio RL audio output
◎ 8 devices ID storable
◎ Micro USB Port for powering
What's in the box
AC/DC Adaptor
（option）
Main Unit
3.5mm male→
3.5mm female→
male Audio cable
audio RL cable
USB Cable
1
Advertisement
Related Manuals for Trans Electric BTR-1020
Summary of Contents for Trans Electric BTR-1020
- Page 1 BTR-1020 Bluetooth music receiver With SBC supported Feature ◎ SBC codec support ◎ A2DP Bluetooth profile supported ◎ 33 feet (10M) effective range ◎ Audio RL audio output ◎ 8 devices ID storable ◎ Micro USB Port for powering What’s in the box AC/DC Adaptor （option）...
- Page 2 Outlook and connectors Front Top View Back Side View Setup your BTR-1020 3.5mm male to male Audio RL Audio Amplifier...
- Page 3 Connect USB A to micro USB adaptor cable, the micro USB end to the micro USB jacket of BTR-1020, USB Type A connector to the USB port of your Audio Video Device or you can connect to an AC Adaptor with USB port(option) , the AC end to any AC outlet..
- Page 4 (some devices have no need “Music Receiver” then to input PIN). This will allow Tap on it. the iPad/iPhone/iPod touch to pair with “Music Receiver” 5. Your iPod/iPhone/iPad connected to BTR-1020 Now. And You can play music from your iPod/iPhone/iPad.
- Page 5 The Bluetooth “setting” 4. Once paired, the blue LED 2. Searched Bluetooth 3. Enter “0000” when light on the BTR-1020 will Devices will show up, the player asks for flash once. The Blue LED will please tap on “Music PIN code（some keep lighted when a Receiver”...
- Page 6 Although the BTR-1020 can only play music from one device at a time, it is capable of being paired to up to 8 devices. It means that you have to enter the PIN code once for each device. You can play the music now. Just play music on your device as you normally would and the sound will come out from your stereo system.
-
Page 7: Troubleshooting
SAFETY WARNINGS ◎ BTR-1020 requires full connection and both hands to install. ◎ Do not use BTR-1020 near water(for example, a bath tub, wash bowl, kitchen sink, laundry tub, wet basement, swimming pool, or other areas located near water). ◎ Clean with dry cloth. -
Page 8: Fcc Statement
FCC Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation...
