Wireless Display Receiver
Smartphone(Android 4.2) to HDMI
Model: WFD-1000
Congratulations on your purchase of the WFD-1000 Wireless Display
Receiver. Your satisfaction is very important to us.
The WFD-1000 allows you to send image or video on your Smartphone to a
HDTV. Anything shows on the Smartphone will also show on the HDTV.
WFD-1000 now supports Miracast™ Wireless Display. You can launch the
wireless display application on a Miracast™-compatible Smartphone, tablet.
For the best performance of this Wireless Display Receiver, please read this
manual carefully and keep it for further information.
Features:
Wireless to HDMI Conversion (Smartphone to HDTV)
Mirroring display from Smartphone to HDTV
Up to 1080P/30fps
Support HDMI 1.3 output and HDCP 2.0
Micro USB powering
INTRODUCTION
FEATURES
1
Advertisement
Related Manuals for Trans Electric WFD-1000
Summary of Contents for Trans Electric WFD-1000
- Page 1 Congratulations on your purchase of the WFD-1000 Wireless Display Receiver. Your satisfaction is very important to us. The WFD-1000 allows you to send image or video on your Smartphone to a HDTV. Anything shows on the Smartphone will also show on the HDTV.
-
Page 2: Connection Illustration
(1) Connect HDMI cable from HDMI output to HDTV. (2) Connect USB Power cable (attached) the micro USB end to the power port of WFD-1000 and the USB A to the USB port of TV, Set Top Box or power adapter with USB A port. - Page 3 (3) Turn on your HDTV TV and select the correct HDMI input. Note: If you do not see this screen, make sure that the HDMI input of HDTV is set to the HDMI port where the WFD-1000 is connected and all cable connections are secured firmly.
- Page 4 Android version 4.1.2 or above . (If your android version of Samsung Smartphone is 4.1.2 or above, AllShare™ Cast is built in and workable with WFD-1000) Tap on the Setting and go to “More settings”, then select “AllShare Cast”. And...
- Page 5 2. Select the available devices _ AV Receiver-XXXXXX and press the pairing button on the front of WFD-1000 for 2 seconds. 3. When the pairing is finished successfully. You will see the Screen of Smartphone on your HDTV.
- Page 6 O.S to support Miracast. 2. The effective range of WFD-1000 is 30 feet (L.O.S), if WiFi signal in your area is too strong or too crowded, the distance and the quality of Picture quality will decrease.
-
Page 7: Troubleshooting
TROUBLE SHOOTING 1. When there is no picture presented, please: Check if the HDMI cable is high speed supported. (For resolution up to 1080p high speed HDMI cable is required.) Check all the connections are correct and connected well. Check the quality of connected HDMI cable, and make sure the cable does not damage. - Page 8 NOTICE Manufacturer reserves the right to make changes in the hardware, packaging and any accompanying documentation without prior written notice. The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
- Page 9 communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna.
