LIGHT ASSEMBLY DIAGRAM
18 Watts
Thank you for purchasing your Christmas tree. The instructions below will help you quickly and easily set up
your new tree.
1. Find a level surface near an electrical outlet and assemble the tree stand as shown in
Fig. A - Tree Stand Assembly
Fig. B - Tree and Lights Assembly
2
1
ITEM #: TG90P4368L04
Eye Bolt
5
4
3
Fig. A.
1. Pull apart the legs of the stand so that
they are x-shaped.
2. When inserting the bottom section of
the tree into the assembled stand,
thread the eyebolt into the stand and
tighten until the pole is firmly secured.
*Electrical Rating For The Tree
(For Indoor Use Only)
Input: AC 120V, 60Hz, 0.38A
Output: DC 28V, 0.643A
Do Not Tamper
Internal Parts
Align both arrows
in a straight line
before sliding
down to insert
To Be Plugged
1
Adapter
Into Wall
Outlet
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Williams-Sonoma TG90P4368L04
Summary of Contents for Williams-Sonoma TG90P4368L04
- Page 1 (For Indoor Use Only) Input: AC 120V, 60Hz, 0.38A Output: DC 28V, 0.643A Do Not Tamper Internal Parts Align both arrows in a straight line before sliding down to insert Adapter To Be Plugged Into Wall Outlet ITEM #: TG90P4368L04...
- Page 2 2. Each tree section is numbered with a tag. Identify all sections before assembling. 3. Assemble the tree from the bottom to the top. Insert the pole of Section 1 into the assembled stand. Make sure the pole is firmly inserted and secured into the stand. Note: Do not step on the tree legs during the setup.
