25-gallon low-profile portable oil drain with electric evacuation pump (4 pages)
Summary of Contents for JohnDow Industries JDI-17PK
Page 1
™ PUMP KIT FOR JDI-17PLP LOW-PROFILE OIL DRAIN USER’S MANUAL Part No. JDI-17PK READ AND SAVE THIS MANUAL FOR SERVICE ASSISTANCE, CALL 800-433-0708 OR VISIT JOHNDOW.COM 151 Snyder Ave. Barberton, OH 44203 Rev 9/2022 VI...
Page 2
General Information Read this manual before using this product. Indicates a hazardous situation that, if not avoided, DANGER could result in death or serious injury. • Do not overfill - maximum capacity is 17 gallons. • Do not use for flammable liquids. •...
Page 3
TOOLS & SUPPLIES NEEDED Adjustable Wrenches Flat Head Screwdriver 7/16” Wrenches ASSEMBLY INSTRUCTIONS 1. Remove screen from JDI-17PLP. Flip drain over. 2. Remove and discard the hose and ball valve from bottom port of drain. Keep hose clamp. 3. Mount electric pump [1] to bracket, making sure inlet port is facing drain port, using the 1/4”...
Page 4
OPERATION TO FILL: 1. Position the drain under the vehicle being serviced and drain fluid into the drain. TO EMPTY: 1. Position the drain by the used fluid container. 2. Hook the drain hose into a container port. 3. Plug the electric motor into a 110V outlet to start. 4.
