581-504 4 ½" OD Single Post 4 Seat Swing
Please retain this instruction sheet in your files.
parts information.
instructions.
It is important to use and maintain all public playground equipment
properly.
Playground equipment, which is improperly maintained, can cause serious
injury.
Periodical inspections, maintenance, repair and/or replacement of damaged parts
is necessary for safe operation of equipment and safety of users.
should be used under all playground equipment.
charge, from the Consumer Product Safety Commission, include "A Handbook for Public
Playground Safety".
PACKING LIST
1 CTN
2 PIPE
583-510
2 PIPE
343-210A
1 PIPE
583-511
1 CTN
* IMPORTANT *
All equipment should be installed in accordance with these
You can receive your free copy by calling 1-301-504-0708.
Hardware Bag
4 ½" OD x 11'4" End Post
2 3/8" OD x 11' Top Rail
4 ½" OD x 11'4" Center post
5 PIPE
6 TOTAL PCS
It contains important replacement
Appropriate publications, available at no
HARDWARE BAG
4
196-802
½" x ½" Socket Set Screw
8
317-140
4/0 Chain x 5'6" long
1
416-400
¼" Socket Key
8
585-520
2 3/8" Swing Hanger
16
585-901
S-Hook
4
585-955
Cut Proof Belt Seat
1
805-532
Warning Label
1
805-534
SportsPlay Label
1
Maintenance Checklist
TOTAL WT 495#
Resilient surfacing
CLASS 70
