581-706 5" OD Arch Post Swing 8' 6 Seat
PLEASE READ THESE INSTRUCTIONS BEFORE COMMENCING ASSEMBLY.
must be installed in accordance with these instructions.
against Bill of Lading and Parts list.
reported to your distributor within 10 days of receipt of your order.
properly installed and maintained, equipment will give many years of Safe,
Trouble-Free use.
must be tightened and broken parts must be replaced as they can possibly
create dangerous situations leading to unnecessary accidents.
Surfacing should be used under all playground equipment.
publications, available at no charge, from the Consumer Product Safety
Commission, include "A Handbook for Public Playground Safety".
receive your free copy by calling 1-301-504-7908.
1
CTN
3
PIPE
583-211
2
WF
583-573
2
WF
583-572
1 CTN
3 PIPE
Periodically check for loose or broken parts.
PACKING LIST
Hardware Bag
3 ½" Top Rail
Center Arch Posts
End Arch Posts
4 WF
TOTAL PCS= 1 SKID
IMPORTANT
Any missing or broken parts must be
12
585-521
6
585-955
12
317-140
24
585-901
12
196-802
1
416-400
1
805-532
1
805-534
1
All equipment
Check your shipment
When
Loose bolts
Resilient
Appropriate
You can
HARDWARE BAG
3 ½" Swing Hanger
Cut Proof Belt Seat
4/0 Chain 5'6"
S Hook
½" x ½" Socket Set Screw
¼" Socket Key
Warning Label
SportsPlay Label
Maintenance Checklist
1019 # WT
Class 70
Advertisement
Related Manuals for Terra Bound Solutions 581-706
Summary of Contents for Terra Bound Solutions 581-706
- Page 1 581-706 5” OD Arch Post Swing 8’ 6 Seat IMPORTANT PLEASE READ THESE INSTRUCTIONS BEFORE COMMENCING ASSEMBLY. All equipment must be installed in accordance with these instructions. Check your shipment against Bill of Lading and Parts list. Any missing or broken parts must be reported to your distributor within 10 days of receipt of your order.
- Page 2 581-706 5” OD Arch Post Swing 8’ 6 Seat GENERAL FOOTING RECOMMENDATIONS Diameter and depth of footings illustrated are satisfactory in most applications for pipe sizes up to 2 3/8” diameter. Varying soil & climatic conditions may require deeper and heavier footings in some areas.
- Page 3 581-706 5” OD Arch Post Swing 8’ 6 Seat Single Axis Swings: The Use/Fall Zone should extend to the front & rear, a minimum distance of twice the height of the Top Rail above the resilient surfacing material. Use/Fall Zone to the sides should follow the general recommendations of six feet minimum.
- Page 4 581-706 5” OD Arch Post Swing 8’ 6 Seat STEP #2: Remove swing hanger pendulums from the swing hanger assemblies. Using S-hooks, attach seats to chain and chain to swing hanger pendulums. Close the S-hooks to within .034” (1/32”) using S-hook pliers.
