ROCKY – P288EV
Dual Pentium® II, III with
LAN & AGP VGA SBC
Ver 1.x
@Copyright 1999
All Rights Reserved.
Manual first edition November 15,1999
The information in this document is subject to change without prior notice in
order to improve reliability, design and function and does not represent a
commitment on the part of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special,
incidental, or consequential damages arising out of the use or inability to use
the product or documentation, even if advised of the possibility of such
damages.
This document contains proprietary information protected by copyright. All
rights are reserved. No part of this manual may be reproduced by any
mechanical, electronic, or other means in any form without prior written
permission of the manufacturer.
Trademarks
ROCKY-P288EV is registered trademarks of ICP Electronics Inc., IBM PC is
a registered trademark of International Business Machines Corporation. Intel
is a registered trademark of Intel Corporation. AMI is registered trademarks of
American Megatrends, Inc. Other product names mentioned herein are used
for identification purposes only and may be trademarks and/or registered
trademarks of their respective companies.
Support
Any questions regarding the content of this manual or related issues can be e-
support@voxtechnologies.com
mailed to us directly at :

Advertisement

Table of Contents
loading

Related Manuals for ICP Electronics ROCKY-P288EV

Summary of Contents for ICP Electronics ROCKY-P288EV

  • Page 1 Trademarks ROCKY-P288EV is registered trademarks of ICP Electronics Inc., IBM PC is a registered trademark of International Business Machines Corporation. Intel is a registered trademark of Intel Corporation. AMI is registered trademarks of American Megatrends, Inc.
  • Page 2 Downloaded from StockCheck.com...

  • Page 3: Table Of Contents

    What You Have................6 2. Installation ..............7 ROCKY – P288EV's Layout ............8 Unpacking Precautions..............9 Setting the CPU of ROCKY-P288EV (JP2, JP6)......10 BIOS Flash Type Setting (J12) ..........10 Watch-Dog Timer (J11, J10) ............. 11 DiskOnChip™ Flash Disk (J9) ........... 11 Clear CMOS Setup (JP1)............
  • Page 4 External Switches and Indicators (CN1) ........18 USB Port Connector (CN6) ............19 IrDA Infrared Interface Port (CN8) ........... 19 CPU Fan Connector (CN11, CN17, CN18)........ 20 3.10 LAN RJ45 Connector (CN14)............ 20 3.11 VGA Connector (CN12)............21 4. AMI BIOS Setup .............22 Getting Started ................

  • Page 5: Introduction

    Introduction Welcome to the ROCKY-P288EV Dual Pentium® II, III Single Board Computer. The ROCKY-P288EV board is an ISA/PCI form factor board, which comes equipped with high performance Pentium® II, III Processor and advanced high performance multi-mode I/O, designed for the system manufacturers, integrators, or VARs that want to provide all the performance, reliability, and quality at a reasonable price.

  • Page 6: Specifications

    Specifications Intel Pentium® II 233 - 450MHz Processor Intel Pentium® III 450 - 600MHz Processor Bus interface PCI/ISA bus, PICMG compliant Bus speed ISA : 8MHz, PCI: 33MHz DMA channels Interrupt levels Chipset Intel 440BX Real-time SGS M4T28 or equivalent device clock/calendar Three 168-pin DIMM sockets support SDRAM RAM memory...
  • Page 7 Supports Serial Infrared(SIR) and Amplitude IrDA port Shift Keyed IR(ASKIR) interface USB port Supports two USB ports for future expansion Can be set by 1,2,10,20,110 or 220 seconds Watch-dog period. Reset or NMI is generated when CPU does not periodically trigger the timer. Your timer program use hex 043 and 443 to control the watch-dog and generate a system reset.

  • Page 8: What You Have

    What You Have In addition to this User's Manual , the ROCKY-P288EV package includes the following items: • ROCKY-P288EV Dual Pentium Single Board Computer ® II, III • One RS-232 and Printer Cable with bracket • One FDD cable •...

  • Page 9: Installation

    Installation This chapter describes how to install the ROCKY-P288EV. At first, the layout of ROCKY-P288EV is shown, and the unpacking information that you should be careful is described. jumpers and switches setting for the ROCKY-P288EV's configuration, such as CPU type selection, system clock setting, and watch dog timer, are also included.

  • Page 10: Rocky - P288Ev's Layout

    ROCKY – P288EV's Layout Downloaded from StockCheck.com...

  • Page 11: Unpacking Precautions

    ü Ground yourself to remove any static charge before touching your ROCKY-P288EV SBC. You can do it by using a grounded wrist strap at all times or by frequently touching any conducting materials that is connected to the ground.

  • Page 12: Setting The Cpu Of Rocky-P288Ev (Jp2, Jp6)

    Note: All shaded rows in tables of this manual are the default settings for the ROCKY-P288EV. Setting the CPU of ROCKY-P288EV (JP2, JP6) • JP2 : Single or Dual Processor Operation Function Single Processor Dual Processor • JP6 : CPU Multiplier Setting...

  • Page 13: Watch-Dog Timer (J11, J10)

    Watch-Dog Timer (J11, J10) The Watch-Dog Timer is enabled by reading I/O port 443H. It should be triggered before the time-out period ends, otherwise it will assume the program operation is abnormal and will issue a reset signal to start again, or activate NMI to CPU. The Watch- Dog Timer is disable by reading I/O port 043H or 843H.

  • Page 14: Clear Cmos Setup (Jp1)

    Clear CMOS Setup (JP1) If want to clear the CMOS Setup(for example forgot the password you should clear the setup and then set the password again.), you should close the JP1 about 3 seconds, then open it again. Set back to normal operation mode, open JP1. •...

  • Page 15: Connection

    Connection This chapter describes how to connect peripherals, switches and indicators to the ROCKY- P288EV board. Table of Connectors LABEL FUNCTION External Switches and Indicators Primary IDE Connector Secondary IDE Connector FDC Connector Parallel Port Connector USB Connector Serial Port 10-pin Connector IrDA connector PS/2 Mouse Connector CN10...

  • Page 16: Floppy Disk Drive Connector (Cn4)

    Floppy Disk Drive Connector (CN4) The ROCKY-P288EV board is equipped with a 34-pin daisy- chain drive connector cable. • CN4 : FDC Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION GROUND REDUCE WRITE GROUND GROUND GROUND INDEX# GROUND MOTOR ENABLE A#...

  • Page 17: Pci E-Ide Disk Drive Connector (Cn2, Cn3)

    PCI E-IDE Disk Drive Connector (CN2, CN3) You can attach four IDE( Integrated Device Electronics) hard disk drives to the ROCKY-P288EV IDE controller. CN2 (IDE 1) : Primary IDE Connector CN3 (IDE 2) : Secondary IDE Connector • CN2/CN3 : IDE Interface Connector PIN NO.

  • Page 18: Parallel Port (Cn5)

    Parallel Port (CN5) This port is usually connected to a printer. The ROCKY-P288EV includes an on-board parallel port, accessed through a 26-pin flat-cable connector CN5. • CN5 : Parallel Port Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION STROBE# DATA 0...

  • Page 19: Keyboard & Ps/2 Mouse Connector (Cn16)

    • CN15 : Serial Port 9-pin Connector PIN NO. DESCRIPTION DATA CARRIER DETECT (DCD) RECEIVE DATA (RXD) TRANSMIT DATA (TXD) DATA TERMINAL READY (DTR) GROUND (GND) DATA SET READY (DSR) REQUEST TO SEND (RTS) CLEAR TO SEND (CTS) RING INDICATOR (RI) •...

  • Page 20: External Switches And Indicators (Cn1)

    For alternative application, a keyboard and a PS/2 mouse pin header connector are also available on board, located on CN9 and CN10 respectively. • CN9 : PS/2 Mouse Connector PIN NO. DESCRIPTION MOUSE DATA GROUND MOUSE CLOCK • CN10 : 5-pin Header Keyboard Connector PIN NO.

  • Page 21: Usb Port Connector (Cn6)

    DATA- GROUND IrDA Infrared Interface Port (CN8) The ROCKY-P288EV has a built-in IrDA port which supports Serial Infrared(SIR) or Amplitude Shift Keyed IR(ASKIR) interface. If you want to use the IrDA port, you have to configure SIR or ASKIR model in the BIOS under Peripheral Setup COM2.

  • Page 22: Cpu Fan Connector (Cn11, Cn17, Cn18)

    IR-TX CIRRX CPU Fan Connector (CN11, CN17, CN18) The ROCKY-P288EV provides two CPU cooling fan connectors, CN17 and CN18 as well as a chassis fan connector, CN11. These connectors can supply 12V/500mA to the cooling fan. All connectors have the same pin assignments and provide a "rotation"...

  • Page 23: Vga Connector (Cn12)

    3.11 VGA Connector (CN12) The ROCKY-P288EV has a built-in 15-pin VGA connector directly connects to your CRT monitor. • CN12 : 15-pin Female Connector GREEN BLUE GROUND GROUND GROUND GROUND GROUND DDC DAT HSYNC VSYNC DDCCLK Downloaded from StockCheck.com...

  • Page 24: Ami Bios Setup

    AMI BIOS Setup The ROCKY-P288EV uses the AMI PCI/ISA BIOS for system configuration. The AMI BIOS setup program is designed to provide maximum flexibility in configuring the system by offering various options which selected end-user requirements. This chapter is written to assist you in the proper usage of these features.

  • Page 25: Standard Cmos Setup

    When choose Auto Configuration with Fail Safe Settings will load minimized settings Troubleshooting. performance should be very poor when use this setting. When choose Auto Configuration with Optimal Settings will load optimized defaults for regular use. Choosing this setting will modify all applicable settings.

  • Page 26: Advanced Cmos Setup

    Advanced CMOS Setup The Advanced CMOS Setup is designed for the user's tuning best performance of the ROCKY-P288EV board. As for normal operation, users don‘ t have to change any default setting. The default setting is pre-set for most reliable operation.
  • Page 27 You can change the value of each options by using <PgUp> and <PgDn> key. The available values are shown on the right screen. Quick Boot > Enabled : this will enable the BIOS to boot quickly when you turn on your computer. The BIOS will only check the first 1MB of the system memory.

  • Page 28: Advanced Chipset Setup

    S.M.A.R.T. for Hard Disks > to allow BIOS to use the S ystem Ma nagement and R eporting T echnologies protocol for reporting server system information on a network BootUp Num-Lock > to turn on/off the Num-Lock option on a enhanced keyboard when you boot.
  • Page 29 Please carefully change any default setting, otherwise the system may become unstable. Configure SDRAM Timing by SPD > The S erial P resence D etect is a 2048bits EEPROM which contains of the data of the chip module, capacity, timing, voltage, etc. The system will configure the SDRAM timing according to the data in the SPD when it is set enabled.

  • Page 30: Power Management Setup

    this setting. Memory from 15MB and up will be unavailable to the system because expansion cards can only access memory up to 16MB. VGA Frame Buffer USWC > to specify whether or not a caching of the video A000-BFFF RAM is allowed. Enabled will give you better system performance.
  • Page 31 Power Management Setup helps user handle the ROCKY- P288EV board‘ s “ green” function. The features could shut down the video display and hard disk to save energy for example. The power management setup screen is as following: Power Management/APM : Disable, Max Saving, Min Saving, or User Defined >...

  • Page 32: Peripheral Setup

    Green PC Monitor Power State > to specify the power state of the monitor after the specified period of display-idle has ended. Video Power Down Mode > to specify the power state of the VESA VGA video subsystem after the specified period of display-idle has ended.
  • Page 33 Onboard FDC > to enable the FDC on your board. If you set it Auto, the BIOS will decide if the FDC should be enabled, automatically). Onboard Serial Port A (/B) > to specify the I/O port address of the serial port A(/B). If you set it Auto, the BIOS will decide the correct I/O port address, automatically.

  • Page 34: Pci / Plug And Play Setup

    Secondary, Both and Disabled. PCI / PLUG AND PLAY SETUP The setup helps users handle the ROCKY-P288EV board‘ s “PCI” function. All PCI bus slots on the system use INTA#, thus all installed PCI slots must be set to this value.
  • Page 35 When PNP OS is installed, interrupts may be reassigned by the OS when the setting is Yes. When a non-PNP OS is installed or to prevent reassigning of interrupt settings, select setting to No. Plug and Play Aware O/S > Yes or No When PNP OS is installed, interrupts will be reassigned by the OS when the setting is Yes.

  • Page 36: Hardware Monitor Setup

    Hardware Monitor Setup This setup helps users monitor the ROCKY-P288EV board‘ s on board system voltage and fan speed. The function is implemented by on board LM78 chip. The voltage monitoring will cover +5V,+12V,-12V,and –5V. And there are three fan connectors for chassis and CPU fans.

  • Page 37: E 2 Key™ Function

    Key™ Function The ROCKY-P288EV provides an outstanding E KEY™ function for system integrator. Based on the E KEY™ you could free to store the ID Code, Pass Word, or Critical Data in the 1Kbit EEPROM. Because the EEPROM is nonvolatile memory, you don’...
  • Page 38 To easy start to use the function, please refer the include EKEYDEMO.C code at first. Please note the E KEY™ function is based on the working of parallel port. So you should enable the ROCKY-P288EV’s parallel port, otherwise will be not working. Downloaded from StockCheck.com...

  • Page 39: Appendix A. Watch-Dog Timer

    Appendix A. Watch-Dog Timer The Watch-Dog Timer is provided to ensure that standalone systems can always recover from catastrophic conditions that caused the CPU to crash. This condition may be occurred by external EMI or a software bug. When the CPU stops working correctly, hardware on the board will either perform a hardware reset (cold boot) or a non-maskable interrupt (NMI) to bring the system back to a known state.

  • Page 40: Appendix B. I/O Address Map

    Appendix B. I/O Address Map • I/O Address Map I/O Address Description 000-01F DMA Controller #1 020-021 Interrupt Controller # 1, Master 040-05F System Timer 060-06F Standard 101/102 keyboard Controller 070-07F Real time Clock, NMI Controller 080-0BF DMA Page Register 0A0-0BF Interrupt Controller # 2 0C0-0DF...
  • Page 41 1 st MB Memory Address Map Memory address Description 00000-9FFFF SYSTEM MEMORY A0000-BFFFF VGA BUFFER C0000-C7FFF VGA BIOS C8000-CFFFF NO USE D6000-D7FFF DEFAULT DOC2000 ADDRESS E0000-FFFFF SYSTEM BIOS 100000 EXTEND MEMORY IRQ Mapping Chart IRQ0 System Timer IRQ8 RTC clock IRQ1 Keyboard IRQ9 IRQ2 IRQ Controller...
