- Page 1 ROCKY-512 Version 2.1 December 25, 2003 ©Copyright 2003 by ICP Electronics Inc. All Rights Reserved.
- Page 2 Trademarks ROCKY-512 is a registered trademark of ICP Electronics Inc. IBM PC is a registered trademark of International Business Machines Corporation. Intel is a registered trademark of Intel Corporation.
-
Page 3: Table Of Contents
Table of Contents CHAPTER 1. INTRODUCTION......... 4 ............5 PECIFICATIONS ............7 ACKAGE ONTENTS CHAPTER 2. INSTALLATION ........8 ROCKY-512 B ..........8 OARD AYOUT ..........11 NPACKING RECAUTIONS (JP5) ........11 ATCHDOG IMER ETTING (JP3) ........12 OMPACT LASH ETTING COM2 S ............12 ETTING CMOS S (JP1/1,3,5) ........13... - Page 4 3.12 (CN8) ..........22 ARALLEL 3.13 (CN1) ......23 LOPPY RIVE ONNECTOR 3.14 I/O (CN2)............24 IGITAL CHAPTER 4. AWARD BIOS SETUP......25 ............25 ETTING TART CMOS S ..........26 TANDARD ETUP BIOS F ..........28 EATURES ETUP ..........29 HIPSET EATURES ETUP ..........30 OWER ANAGEMENT ETUP PNP / PCI CONFIGURATION ........31 LOAD BIOS DEFAULTS ..........32...
- Page 5 B.1 S I/O A ..........43 YSTEM DDRESS B.2 DMA ..........44 CHANNEL ASSIGNMENTS B.3 I ............44 NTERRUPT ASSIGNMENTS B.4 1 ............45 MEMORY MAP...
-
Page 6: Chapter 1. Introduction
Chapter 1. Introduction ROCKY-512 is designed for limited space applications with only the half size. It supports the full functions of an AT& ATX-compatible industrial computer on a single board. So it provides wake on LAN and Modem. The ROCKY-512 is equipped with a low-power consumption and high performance GXLV/GX1 processor on board. -
Page 7: Specifications
1.1 Specifications NS GXLV/GX1-233/266/300 MMX 32-Bit x86 Processor Supports Intel MMX instruction set extension for the acceleration of multi media applications 16 KB unified L1 cache Five-stage pipelined integer unit Integrated Floating Point Unit（FPU） System Memory: On board 64/128MB SDRAM and one 168-pin DIMM socket that supports up to 256MB SDRAM memory BIOS: AWARD 256 KB Flash memory... - Page 8 Watchdog Timer: Can be set to 1-255 seconds per period. Reset or NMI was generated when CPU did not periodically trigger the timer. 10/100Mbps Ethernet Controller: Realtek 8100 IEEE802.u 100 BASE-TX standard Dual Auto-sensing interface to 10MBps or 100MBps networks. On board RJ45 connectors provide for easy connection.
-
Page 9: Package Contents
Before you begin installing the product, please check that all of the following materials are included in the package: One ROCKY-512 All-in-one single board computer One CD disk for utility and drivers One 3.5" IDE flat cable (40-pin to 40-pin 2.54mm pitch) One serial + parallel port cable with bracket One floppy cable (for 3.5"... -
Page 10: Chapter 2. Installation
Chapter 2. Installation This chapter is guidance to assist you setup ROCKY-512 hardware, including directions of setting jumpers and connecting peripherals, switches and indicators. Before installation, please pay attention to the unpacking precautions on the following page to ensure safety. -
Page 13: Unpacking Precautions
Ground yourself to remove any static charge before touching the ROCKY-512 SBC. You can do it by using a grounded wrist strap at all times or by frequently touching any conducting materials that is connected to the ground. -
Page 14: Compact Flash Setting (Jp3)
2.4 Compact Flash Setting (JP3) Set the operating mode of CompactFlash disk • JP3: Compact Flash Setting ADDRESS MASTER SHORT SLAVE OPEN 2.5 COM2 Setting The COM2 (CN4) can supply +5V or +12V power to the serial devices via RI pin (Pin 8) of the COM port connector. The max. support current is 1A with fuse protection between these two connector’s 5V/12V output. -
Page 15: Clear Cmos Setup (Jp1/1,3,5)
JP1 (2,4,6) DESCRIPTION RS232 RS422/RS485 2.6 Clear CMOS Setup (JP1/1,3,5) If you need to clear the CMOS Setup (for example, you forgot the password then you should clear setup and then reset the password), you should short the JP1 (3,5) for about 3 seconds, and then open it again and this will set system back to normal operation mode. - Page 16 • JP4 & JP6: DiskOnChip Memory Address Setting ADDRESS CC000 OPEN OPEN SHORT OPEN OPEN SHORT SHORT CE000 OPEN OPEN OPEN SHORT OPEN SHORT SHORT D0000 SHORT OPEN OPEN OPEN SHORT OPEN SHORT D2000 OPEN SHORT OPEN OPEN SHORT OPEN SHORT D4000 OPEN...
-
Page 17: Chapter 3. Connection
Chapter 3. Connection This chapter describes how to connect peripherals, switches and indicators to the ROCKY-512 board. 3.1 VGA Connector (CN17) The ROCKY-512 built-in 15-pin VGA connector that connects directly CRT monitors. • CN17: 15-pin VGA Connector GREEN BLUE GROUND... -
Page 18: External Power Connector (Cn16)
+12V GROUND GROUND VCC5V 3.4 ATX Power Connector (CN15, CN14) The ROCKY-512 can accept AT or ATX power supply. The CN15, CN14 provide the ATX power controlled signals and +5V standby voltage (+5VSB). • CN15: ATX Power connector DESCRIPTION +5VSB... -
Page 19: Lan Rj45 Connector (Cn12)
ATX function.CN14 connects to the power button in the chassis. 3.5 LAN RJ45 Connector (CN12) The ROCKY-512 built-in RJ45 LAN connector is for 10/100Mbps Ethernet (REALTEK 8100). Support wake-on-LAN when you use the ATX power supply. • CN12: LAN RJ45 Connector 3.6 USB Port Connector (CN11) -
Page 20: Compact Flash Connector -- Type Ii (Cn9)
3.7 CompactFlash Connector -- TYPE II (CN9) You can attach one Compact Flash Disk to CN18 that occupy the Secondary IDE channel. CN9 supports both the TYPE II and TYPE I module. • CN9: 50-pin CompactFlash Connector (secondary IDE) DESCRIPTION DESCRIPTION GROUND VCC-IN CHECK1... -
Page 21: E-Ide Hard Disk Connector (Cn10)
3.8 E-IDE Hard Disk Connector (CN10) For IDE HDD connection, The ROCKY-512 was designed with one2.54mm connector (CN10), which could be converted to two 2.54mm standard IDE connector via proprietary cable. • CN10: 40-pin Primary IDE Interface Connector DESCRIPTION DESCRIPTION... - Page 22 ROCKY-512. The detailed pin assignment of the connectors are specified in the following tables: • CN3 (com1) serial Port Connector (9-pin DSUB) DESCRIPTION DATA CARRIER DETECT (DCD) RECEIVE DATA (RXD) TRANSMIT DATA (TXD) DATA TERMINAL READY (DTR) GROUND (GND) DATA SET READY...
-
Page 23: Keyboard & Ps/2 Mouse Connector (Cn5, Cn6)
KEYBOARD DATA 3.11 IrDA Infrared Interface Port (CN7) The ROCKY-512 built-in an IrDA port which support Serial Infrared (SIR) or Amplitude Shift Keyed IR (ASKIR) interface. When IrDA port is in use, you would have to set SIR or ASKIR model through BIOS’s Peripheral Setup’s COM2. -
Page 24: Parallel Port (Cn8)
• CN7: IrDA connector DESCRIPTION IRRX Ground IR-TX 3.12 Parallel Port (CN8) This port is usually connected to a printer; The ROCKY-512 includes an on-board parallel port (CN8), accessed through a 26-pin flat-cable connector. • CN8: Parallel Port Connector DESCRIPTION DESCRIPTION... -
Page 25: Floppy Disk Drive Connector (Cn1)
3.13 Floppy Disk Drive Connector (CN1) ROCKY-512 board is equipped with a 34-pin daisy-chain driver connector cable. • CN1: FDC CONNECTOR DESCRIPTION DESCRIPTION GROUND REDUCE WRITE GROUND GROUND GROUND INDEX# GROUND MOTOR ENABLE A# GROUND DRIVE SELECT B# GROUND DRIVE SELECT A#... -
Page 26: Digital I/O (Cn2)
This kind of response is highly needed for harsh and critical industrial operating environment. That’s why we design 4-bit digital inputs and 4-bit digital outputs on the ROCKY-512. Digital Input and Output, generally, are control signals. You can use these signals to control external devices that needs On/Off circuit or TTL devices. -
Page 27: Chapter 4. Award Bios Setup
Chapter 4. AWARD BIOS Setup ROCKY-512 uses the AWARD PCI/ISA BIOS for system configuration. The AWARD BIOS setup program is designed to provide maximum flexibility in configuring the system by offering various options that may be selected to meet end-user requirements. This chapter is written to assist you in proper usage of these features. -
Page 28: Standard Cmos Setup
4.2 Standard CMOS Setup The Standard CMOS Setup is used for basic hardware system configuration. The main function is for Date/Time setting and Floppy/Hard Disk Drive setting. Please refer to the following screen for this setup. - Page 29 To set the Date, for example, press either the arrow or <Enter> button on your keyboard to select one of the fields (Month, Date or Year) then press either <PgUp> or <PgDn> to increase or decrease the value of that field. Do the same steps for Time setting.
-
Page 30: Bios Features Setup
4.3 BIOS Features Setup This BIOS Features Setup is designed for the 'fine tuning' of your system in order to improve its performance. As for normal operation, you don‘t have to change any default setting. The default setting is pre-set for most reliable operation. -
Page 31: Chipset Features Setup
4.4 Chipset Features Setup This setup function works mostly on board's chipset. This option is used to change the chipset's configuration. Please be careful while making any changes in default setting, otherwise the system will become unstable. -
Page 32: Power Management Setup
4.5 Power Management Setup Power Management Setup helps user to handle the ROCKY-512 board‘s “green” function. This feature can shut down the video display and hard disk to save energy, for example. The power management setup screen is as following... -
Page 33: Pnp / Pci Configuration
4.6 PNP / PCI CONFIGURATION This menu is used to assign certain IRQ to your PNP/PCI devices manually. PNP OS Installed: if you install Plug and Play operating system (OS), the OS will reassign the interrupt if you select Yes in this field. -
Page 34: Load Bios Defaults
4.7 LOAD BIOS DEFAULTS If you select 'Y' to this field, the BIOS Defaults will be loaded except Standard CMOS SETUP. The default settings are not optimal and turning all high performance into disabled condition. Select 'N' to abort. Suggestion: For the first time or for our primary user, we suggest you to use LOAD SETUP DEFAULTS because it is the safest mode for your system. -
Page 35: Load Setup Defaults
4.8 LOAD SETUP DEFAULTS If you select 'Y' to this field, the Setup Defaults will be loaded except Standard CMOS SETUP. The default settings are optimal configuration settings for your system. -
Page 36: Integrated Peripherals
4.9 INTEGRATED PERIPHERALS This option is used to assign Onboard I/O, IRQ, and DMA etc. If you don't know how to configure them, just press <F7> to load Setup Defaults. The flat panels will then be applied with two modes: 640x480 or 800x600, for which it needs to set up from BIOS for proper flat panel resolution. -
Page 37: Ide Hdd Autodetection
password, enter the BIOS SETUP room with Password and then just press the <Enter> key instead of entering a new password when the 'Enter Password' prompt pop-up. Note: If you forget the password, do the Clear/Reset CMOS procedure (see Section 2.5 Clear CMOS Setup) 4.11 IDE HDD AUTODETECTION This option detects the parameters of an IDE hard disk drive (HDD sector, cylinder, head, etc) automatically and will put the parameters... -
Page 38: Save And Exit Setup
4.12 SAVE AND EXIT SETUP Select this option when you finish setting all the parameters and want to save them into the CMOS. Simply press <Enter> key and all the configuration changes will be saved... -
Page 39: Quit Without Saving
4.13 Quit Without Saving Select this option if you want to exit the Setup without saving the changes that you made. Simply press <Enter> key and you will exit the BIOS SETUP without saving the changes. -
Page 40: Chapter 5. Svga Setup
The ROCKY-512 is equipped with on-board VGA interface. The description below is its specifications and features: 5.1.1 Chipset The ROCKY-512 uses a Cyrix CX5530A chipset as its SVGA controller for traditional analog CRT monitors. The VGA BIOS does not support LCD. Moreover, it also accepts interlaced and... -
Page 41: Further Information
\VGA\MediaGX\Nt40Vga\ 5.2 Further Information For more detailed information about the PCI/SVGA installation in your ROCKY-512, including driver updates, troubleshooting instructions, please refer to the following webs, which provide some resources you may need. If not find the information you need,... -
Page 42: Chapter 6. Pci Bus Ethernet Interface
Chapter 6. PCI Bus Ethernet Interface The ROCKY-512 provides a high performance 32-bit Ethernet chipset, which is completely compliant with IEEE 802.3 100 Mbps CSMA/CD standards. As it is both 100Base-T and 10Base-T compatible so it is suitable for most major network operating systems. -
Page 43: Appendix A. Watchdog Timer
Appendix A. Watchdog Timer The Watchdog Timer is a device to ensure that standalone systems can always recover from catastrophic conditions that cause the CPU to crash. This condition may have occurred by external EMI or a software bug. When the CPU stops working normally, hardware on the board will perform hardware reset (cold boot) to bring the system back to a known state. - Page 44 been set to 10 seconds, the I/O port 443H must be read within 7 seconds. Note: When exiting a program it is necessary to disable the Watchdog Timer, otherwise the system will reset. Example Assembly Program: TIMER_PORT = 443H TIMER_START = 443H TIMER_STOP = 843H ;;INITIAL TIME PERIOD COUNTER...
-
Page 45: Appendix B. I/O Address Map
Appendix B. I/O Address Map B.1 System I/O Address Map I/O ADDRESS MAP DESCRIPTION 000-01F DMA Controller #1 020-021 Interrupt Controller # 1, Master 022-023 Chipset address 040-05F System Timer 060-06F Standard 101/102 keyboard Controller 070-07F Real time Clock, NMI Controller 080-0BF DMA Page Register 0A0-0BF... -
Page 46: Dma Channel Assignments
B.2 DMA channel assignments CHANNEL FUNCTION Available Available Floppy disk (8-bit transfer) Parallel** Cascade for DMA controller 1 Available Available Available ** parallel port DMA default setting: DMA 3 parallel port DMA select: DMA 1.3 B.3 Interrupt assignments INTERRUPT # INTERRUPT SOURCE Parity error detected IRQ 0... -
Page 47: St Mb Memory Map
B.4 1 MB memory map ADDRESS DESCRIPTION F000h-FFFFh System ROM D800h-EFFFh Unused C800h-D7FFh Ethernet ROM* C000h-C7FFh Expansion ROM* B800h-BFFFh CGA/EGA/VGA text B000h-B7FFh Unused A000h-AFFFh EGA/VGA graphics 0000h-9FFFh Base memory D000-D400H Available * Default setting ** If Ethernet boot ROM is enabled.
