ADVANCED Network Devices IPCSL-L Quick Start Manual

Capabilities

Audio:
• 8" High efficiency PA Speaker
• Optional ancillary 8-ohm speaker
• Bell scheduling, reminders and alarms
• Clock chimes
• Voice paging from a PC or IP Phone, randomly, or at intervals
• Use provided notifications, alarms, audio files (sport, holiday, traditional,
etc.), or your own
Scrolling Text:
• Send many types of messages to it:
• Custom Configuration
• Reminders
• Alerts
• Advertising
• RSS feeds

IP Clock Overview

The IP Clock is a Power over Ethernet (PoE) synchronized clock and intercom
that requires only an RJ-45 connector to connect to existing data networks.
Simultaneously, broadcast to both phones and speakers. The clock auto synchro-
nizes and can be used as a scrolling text display. Standard built in microphone
and speaker that allows two way voice communication.
Advanced Network Devices • 3820 Ventura Dr. Arlington Hts. IL 60004 • Phone: 847-463-2236 • Fax: 847-359-5418
Website: www.anetd.com • E-Mail: sales@anetd.com
Microphone:
• Monitoring
• Two way talking/Intercom
• Paging Supervision
• Hands-free talk back
• Configurable Fonts
• 1 or 2 Line Display
Large Mounted IP Clock with Bright White Display

Auto Dimming:

• Automatically
reduce display
power usage
at night to save
energy
Clock:
• 4.5" numbers/text
• Atomic time
• Never needs setting
• Auto-adjust for Daylight Savings
• Display 4 or 6 digits
• Configurable fonts
IPCSL-L

Features

Built in Web Server:

• Send text messages to it from the web
page
• Configurable brightness and volume
• Configurable fonts
• Configurable NTP time server, time
zone, etc.
• Device Status
• Field upgradable

Line In/ Out:

• Independent line-in.
• Can be configured to send line in
audio to the speaker or add additional
speakers

Easy Installation:

• Only requires CAT 5 connection (up
to 300ft) to network
• Power over Ethernet (no power cord
or adapter). No other equipment
needed

GPIO:

• 2 inputs, 2 outputs
• Activate via telephone or program-
matically

Multicast:

• Full multicast and broadcast support.
Send audio and/or scrolling text to in-
dividual devices, all devices or groups
of devices.

Stop Watch / Timer:

• Count up and down with configurable
sounds
• Event based trigger

Sound Masking:

• Generate pink noise via push button
or programmatically for sound mask-
ing

Two Way Communication:

• Activate via push button
• Allows for full duplex hands free
communication
Options
• Optional button for hand-free push
to talk
