- Page 1 NORDcanopy OZ 3.1 Ozone Cleaning System Installation Guide...
-
Page 2: Table Of Contents
® NORDcanopy | OZ 3.1 Installation Guide Table of contents Safety notes Installation flowchart 1. Check the product shipment 2. System overview 3. Prepare the Ozone Modules 3.1 Set the device addresses 4. Installation 4.1 General information 4.2 Connect the pressure measurement hoses 4.3 Mount the Control Panel 5. -
Page 3: Safety Notes
• The Ozone Cleaning System uses high voltage to create an electric charge that generates ozone (O ). Ozone significantly reduces odor, grease, mold and bacteria. ETS NORD AS disclaims any liability in the case that the product is not used in accordance with the manufacturer’s instructions contained in this manual. -
Page 4: Check The Product Shipment
® NORDcanopy | OZ 3.1 Installation Guide Check the product shipment Check that the parcel contains all components listed below and that there is no visible damage. Notify both the freight forwarder and supplier immediately of any damage or missing components. Before installing the device read through the entire instruction material. -
Page 5: Prepare The Ozone Modules
® NORDcanopy | OZ 3.1 Installation Guide NOTE! Installation may only be carried out byby specialist and authorized persons in accordance with local, regional, national standards and regulations. 3. Prepare the Ozone Modules 3.1 Set the device addresses Each Ozone Module must be set to a unique device address. Start by removing the bottom cover by unscrewing the four (4) M5x12 bolts from the side panel with T4 screwdriver and keep them in a secure place for later use. -
Page 6: Installation
® NORDcanopy | OZ 3.1 Installation Guide Installation 4.1 General information Ozone is drawn into the grease chamber through the ozone duct, which is located on the ceiling of the canopy. The ducting and bends necessary for connection are included with the canopy. Always install the ozone ducting according to the manufacturer’s drawings. -
Page 7: Connect The Pressure Measurement Hoses
® NORDcanopy | OZ 3.1 Installation Guide 4.2 Connect the pressure measurement hoses For an Ozone Module to operate properly its two pressure measurement hoses must be connected. NOTE! There are two hoses that need to be connected to each module. - Feed the long hose through the Ø100mm ozone duct into the exhaust chamber. -
Page 8: Mount The Control Panel
® NORDcanopy | OZ 3.1 Installation Guide 4.3 Mount the Control Panel Choose a visible and easily accessible location in the kitchen suitable for the Control Panel. Avoid positioning it near any sources of moisture or heat. The housing must be disassembled into three parts. Remove the two fixing screws on the sides of the case. -
Page 9: Electrical Installation
® NORDcanopy | OZ 3.1 Installation Guide Electrical Installation NOTE! Electrical installation must be performed by an authorized electrician and follow local, regional and national standards and regulations. The ozone generator system must be interlocked with the exhaust system, so that when the exhaust ventilation is not running, no electrical power is supplied to the ozone system. -
Page 10: Connect The Main Electrical Supply
® NORDcanopy | OZ 3.1 Installation Guide 5.1 Connect the main electrical supply Control Panel power cables may be fed through either the rear wall or the cable bushings in the bottom of the case. Connect the 230V supply cable to the power supply terminals L, N and PE, as shown in the diagram. 230V supply cable Power supply Each Ozone Module has its own power cable that can be found inside the packaging. -
Page 11: Control Panel And The Ozone Modules Data Wiring
® NORDcanopy | OZ 3.1 Installation Guide 5.2 Control Panel and the Ozone Modules data wiring Three cables are connected to the Control Panel. Data cable (3x0,25mm2) for communication between Control Panel and EOZ unit, I/O cable (5x0,5mm2) for connecting to the building automation and LAN cable to access the Control Panel via internet. - Page 12 Connect the five (5) terminals DI1, DI2, DO1, DO2 and COM+ and mark the other ends of the wires within the junction box with their corresponding terminal assignments. I/O cable COM+ For more technical information, please check our website or contact your ETS NORD representative. www.etsnord.com RDM-31-0322...
- Page 13 NOTE! After installing the ozone cleaning system and measuring the ventilation system, the ozone equipment must be commissioned for the first time. Only trained and authorized persons by ETS NORD may perform the initial commissioning. Inform the seller’s representative of the need to start the equipment for the first time.
-
Page 14: Control Panel Display Messages
NOTE! Cooking in the kitchen may continue when Control Panel alarm is active as long as there is no sign of ozone. Still service is required and information must be provided to ETS NORD representative or nearest authorized service company www.etsnord.com... -
Page 15: Facts About Ozone
• The new device is covered by a 2-year warranty against defects and manufacturing defects, if: - the initial commissioning of the device has been performed by an authorized partner of ETS NORD AS - the equipment is serviced every 12 months after commissioning - specified components (eg ozone generating equipment) have been replaced as required •... - Page 16 ETS NORD AS Address: Peterburi tee 53 11415 Tallinn Estonia Phone: +372 680 7360 info@etsnord.ee www.etsnord.ee ETS NORD Finland Address: Pakkasraitti 4 04360 Tuusula Finland Phone: +358 401 842 842 info@etsnord.fi www.etsnord.fi ETS NORD Sweden Address: Järsjögatan 7 69235 Kumla...
