U-Line H-3046 Quick Start Manual

π
H-3046
LIGHT DUTY ELECTRIC
PRESSURE WASHER
TOOL NEEDED
1. Use a Phillips screwdriver to attach tool caddy and
power cord holder to back of pressure washer.
(See Figure 1)
2. Connect outlet hose to back of pressure washer.
(See Figure 2)
3. Connect hose to gun. Press blue release knob to
secure hose. (See Figure 3)
Figure 3
PAGE 1 OF 2
1-800-295-5510
uline.com
Phillips Screwdriver
ASSEMBLY
Figure 1
Figure 2
4. Connect either the turbo nozzle, adjustable spray
nozzle or detergent bottle to gun. (See Figure 4)
Figure 4
5. Screw the clear water filter to the front of the
pressure washer. (See Figure 5)
6. Screw garden hose adapter onto garden hose.
(See Figure 6)
Figure 5
Figure 6
0816 IH-3046
