KD-AHD79/KD-HDR70
CD RECEIVER / RECEPTOR CON CD /
RÉCEPTEUR CD
For canceling the display demonstration, see page 4. / Para cancelar
la demostración en pantalla, consulte la página 4. / Pour annuler la
démonstration des affichages, référez-vous à la page 4.
For installation and connections, refer to the separate manual.
Para la instalación y las conexiones, refiérase al manual separado.
Pour l'installation et les raccordements, se référer au manuel séparé.
MANUAL DE INSTRUCCIONES
MANUEL D'INSTRUCTIONS
INSTRUCTIONS
ENGLISH
ESPAÑOL
FRANÇAIS
For customer Use:
Enter below the Model
No. and Serial No. which
are located on the top or
bottom of the cabinet.
Retain this information
for future reference.
Model No.
Serial No.
GET0721-001A
[J]

Advertisement

Table of Contents
loading

Related Manuals for JVC KD-AHD79

Summary of Contents for JVC KD-AHD79

  • Page 1 KD-AHD79/KD-HDR70 CD RECEIVER / RECEPTOR CON CD / RÉCEPTEUR CD For canceling the display demonstration, see page 4. / Para cancelar la demostración en pantalla, consulte la página 4. / Pour annuler la démonstration des affichages, référez-vous à la page 4.
  • Page 2 – Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. – Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not approved by JVC could void the user’s authority to operate the equipment. 1. CLASS 1 LASER PRODUCT Do not open the top cover.

  • Page 3: Table Of Contents

    Therefore, the use of Non-DVD side of a DualDisc on this product may not be recommended. JVC bears no responsibility for any loss of data in an iPod/iPhone and/or USB mass storage class device while using this System. 3 How to attach/detach the control...

  • Page 4: Canceling The Display Demonstration

    [Hold] [Hold] [Hold] [Hold] ENGLISH (Initial setting) (Initial setting) (Initial setting) (Initial setting)

  • Page 5: Preparing The Remote Controller

    When you use the remote controller for the first time, pull out the insulation sheet. Insulation sheet For USA-California Only: This product contains a CR Coin Cell Lithium Battery which contains Perchlorate Material— special handling may apply. See www.dtsc. ca.gov/hazardouswaste/perchlorate This unit is equipped with the steering wheel remote control function.

  • Page 6: Basic Operations

    Loading slot Remote sensor • DO NOT expose to bright sunlight. Detaches the panel When you press or hold the following button(s)... — Control dial (turn) — Control dial (press) — — — — ENGLISH Control dial Turns on/off [Hold]. Selects the sources (FM, AM, CD, USB or USB-IPOD, F-AUX, BT AUDIO or R-AUX or BT PHONE).

  • Page 7: Listening To The Radio

    You can tune in to both conventional and HD Radio broadcasts. HD Radio stations can deliver high-quality digital sound—AM digital will have FM-like sound quality (in stereo) and FM digital will have CD-like sound quality—with static-free and clear reception. Furthermore, stations can offer text and data, such as artist names, song titles, and Program Service Data (PSD).
  • Page 8 [Hold] ] <TUNER> ] <MONO> ] <MONO ON> Reception improves, but stereo effect will be lost. procedure to select <MONO OFF>. While receiving an HD Radio broadcast, you can change the reception mode—digital or analog. • This setting cannot take effect for the conventional FM/AM stations.
  • Page 9 5 / ∞ : [Press] Changes the preset stations/ channels. [Hold] Searches for HD Radio stations only. 2 / 3 : [Press] Searches for stations automatically. [Hold] Searches for stations manually. = Frequency = PTY (Program Call Sign * = Text * = Clock = (back to the Type) * beginning)
  • Page 10 While receiving a song with PSD... Lights up while receiving a song with PSD. TAG SAVED The tagged PSD is stored on the unit. When an Apple iPod/iPhone is connected (page 14), the tagged PSDs are automatically transferred to the iPod/iPhone. Go to purchase the song.

  • Page 11: Listening To A Disc

    If the ejected disc is not removed within 15 seconds, it will automatically reload into the loading slot. Selects folder of the MP3/WMA. [Press] Selects track. [Hold] Fast-forwards or reverses the track. 5 / ∞ : Selects folder of the MP3/WMA. 2 / 3 : [Press] Selects track.

  • Page 12: Connecting The Other External Components

    You can connect an external component to the auxiliary input jack on the control panel (F-AUX) and/or on the rear side of the unit (R-AUX). Summary of using the external components through the auxiliary input jacks: Auxiliary External component input jack Portable audio Front player...

  • Page 13: Listening To A Usb Device

    • This unit can play MP3/WMA files stored in a USB mass storage class device (such as a USB memory, Digital Audio Player, etc.). [Hold] ] Turn on the power. All tracks will be played repeatedly until you change the source or disconnect the USB device. •...

  • Page 14: Listening To An Ipod/Iphone

    [Hold] ] Turn on the power. USB 2.0 cable (accessory of the iPod/iPhone) All tracks will be played repeatedly until you change the source or disconnect the iPod/iPhone. • Avoid using the iPod/iPhone if it might hinder your safety driving. •...
  • Page 15 • The song order displayed on the selection menu of this unit may differ from that of the iPod. • When operating an iPod/iPhone, some operations may not be performed correctly or as intended. In this case, visit the following JVC web site: <http://www. jvc.co.jp/english/car/> (English website only). ENGLISH...

  • Page 16: Selecting A Preset Sound Mode

    You can select a preset sound mode suitable for the music genre. (back to the beginning) While listening, you can adjust the subwoofer level and tone level of the selected sound mode. [Hold] Adjust the level: SUB.W : 00 to 08 BASS / MID / TRE : –06 to +06 The sound mode is automatically stored and changed to “USER.”...
  • Page 17 29 preset colors / buttons illumination (except for • If <ALL ZONE> is selected, the button and display illumination will change to the current/selected <BUTTON ZONE> color. • Initial color : : Changes the display and buttons (except for menu, list search and playback mode operations. / adjustments in <BRIGHTNESS>/<COLOR SETUP>...
  • Page 18 level. / “FM”), compared to the FM volume level. The volume level will automatically increase or decrease when you change the source. Before adjustment, select the source you want to adjust. (“VOL ADJ FIX” appears on the display if “FM” is selected as the source.) 55 Hz/85 Hz/120 Hz are sent to the subwoofer.

  • Page 19: Troubleshooting

    Check to be sure the terminals of the speaker leads are covered with insulating tape properly, then reset the unit. (page 3) If the message does not disappear, consult your JVC car audio dealer or a company supplying kits. Reset the unit. (page 3) above.)
  • Page 20 No sound can be heard. The song cannot be tagged. Disc cannot be played back. CD-R/CD-RW cannot be played back and track cannot be skipped. Disc sound is sometimes interrupted. “NO DISC” appears on the display. “PLEASE” and “EJECT“ appear alternately on the display.

  • Page 21: Additional Information

    Tracks/folders are not played back in the order you have intended. “CANNOT PLAY” flashes on the display. / “NO USB” appears on the display. / The unit cannot detect the USB device. The iPod does not turn on or does not work.

  • Page 22: Using Bluetooth ® Devices

    For Bluetooth operations, it is required to connect the Bluetooth adapter, KS-BTA100 (not supplied) to the auxiliary input jack (R-AUX/BT ADAPTER) on the rear of the unit. (page 12) • For details, refer also to the instructions supplied with the Bluetooth adapter and the Bluetooth device.

  • Page 23: Specifications

    Load Impedance : 4 Ω (4 Ω to 8 Ω allowance) Frequency Response : 40 Hz to 20 000 Hz Line-Out or Subwoofer-Out Level/Impedance : KD-AHD79 : 5.0 V/20 kΩ load (full scale) KD-HDR70 : 2.5 V/20 kΩ load (full scale) Output Impedance : ≤ 600 Ω...
  • Page 24 Still having trouble?? USA ONLY Call 1-800-252-5722 http://www.jvc.com We can help you! • HD Radio Technology manufactured under license from iBiquity Digital Corporation. U.S. and Foreign Patents. HD Radio™ and the HD, HD Radio, and “Arc” logos are proprietary trademarks of iBiquity Digital Corp.
  • Page 25 • If you have any questions or require information regarding installation kits, consult your JVC car audio dealer or a company supplying kits. • The unit can only be installed in a car with a 12 V DC power supply, negative ground.
  • Page 26 SW : To subwoofer / Al subwoofer / Au caisson de grave JVC Amplifier / FRONT : To front speakers / A Amplificador de JVC / los altavoces delanteros / Aux JVC Amplificateur enceintes avant REAR : To rear speakers / A los altavoces traseros / Aux enceintes arrière...
  • Page 29 Zip Code: Phone Number: E-Mail Address: 1) Would you like to receive the JVC Community e-mail newsletter? 2) Would you like to receive special offers from JVC? 3) Have you purchased an extended warranty for this product? Date of Purchase...
  • Page 30 This form is for Product Registration purposes only. Failure to return this form does not diminish your rights during the warranty period. THANK YOU FOR PURCHASING THIS JVC PRODUCT REGISTER ONLINE AT: REGISTER.JVC.COM 1111.1.111111 ••• 1.1.111.1 •••• 1111.111111.1.1111 •• 1.1.111111.11...
  • Page 31 JVC product distributed in Canada by JVC and sold by an authorized JVC dealer. JVC warrants that this JVC product is free, under Apt. normal use and maintenance, from any defects in App.
  • Page 32 I'acheteur doit assumer la responsabilite et les coOts pour un emballage adequat, I'expedition, ainsi que tous les coOts associes I'equipement chez et depuis Ie detaillant JVC autorise Ie plus pres pour un service d'entretien. Receivers and Home Speakers purchased separately, Front Projection and Car Audio "ARSENAL"...
  • Page 33 TO OUR VALUED CUSTOMER - - THANK YOU FOR PURCHASING THIS JVC PRODUCT. WE WANT TO HELP YOU ACHIEVE A PERFECT EXPERIENCE. NEED HELP ON HOW TO HOOK UP? NEED ASSISTANCE ON HOW TO OPERATE? NEED TO LOCATE A JVC SERVICE CENTER? LIKE TO PURCHASE ACCESSORIES? JVC®IS...
  • Page 34 ; WHAT WE WILL DO: ; If this product is found to be defective within the warranty period, JVC will repair or replace defective parts with new or ; * rebuilt equivalents at no charge to the original owner. Such repair and replacement services shall be rendered by JVC * during normal business hours at JVC authorized service centers.
