Trane Technologies WIR10523 Installer's Manual

WARNING:
ALL phases of this installation must comply with NATIONAL, STATE AND LOCAL CODES
IMPORTANT — This Document is customer property and is to remain with this unit. Please return to service information
pack upon completion of work.

GENERAL:

The new wire harness (WIR10523) needs to be installed
where the existing latching switchover valve (LSOV) harness
is. This new wire harness has a transient voltage suppressor
and is used to eliminate a potential voltage spike to the LSOV
solenoid when the LSOV gets commanded (This is NOT a
safety concern).
This kit is used with the following variable speed heat pump
models:
4TWV
4A6V
This information is intended for use by individuals
possessing adequate backgrounds of electrical and
mechanical experience. Any attempt to repair a central
air conditioning product may result in personal injury and/
or property damage. The manufacture or seller cannot
be responsible for the interpretation of this information,
nor can it assume any liability in connection with its use.
HAZARDOUS VOLTAGE!
Disconnect all electric power, including remote
disconnects before installing or servicing. Follow proper
lockout/tagout procedures to ensure the power can not
be inadverantly energized. Failure to disconnect power
before servicing could result in death or serious injury.
Installer's Guide
T.V.S. Harness for LSOV
WIR10523
HAZARDOUS VOLTAGE - DISCONNECT POWER BEFORE SERVICING
4TWL9
4A6L9
18-BC107D1-1A-

KIT CONTENTS:

Open and inspect contents for damage or missing items
Qty. Description
1 LSOV Wire Harness
Wiring Diagram (Danfoss
1
Drive)
Wiring Diagram (VSPD Side
1
Discharge Units)
1 Installer Guide

INSPECTION:

1. Unpack all components of the kit.
2. Check carefully for any shipping damage. If any damage
is found, this must be reported immediately and a claim
made against the transportation company.
3. Check to be sure all components are in the package. Any
missing components should be reported to your supplier
at once and replaced with authorized components only.

INSTALLATION:

1. Disconnect all the electrical power to the unit.
a. Wait two (2) minutes after disconnecting power as
the electrical components may hold a dangerous
voltage. Verify the DC Voltage is less than 42 VDC
as measured from the test points at the bottom of
the drive before servicing the drive.
2. Remove the unit control box cover.
3. Remove the unit top which allows access to the wire
routing (step not required for side discharge units).
4. Remove the unit side panel to gain access to the LSOV
solenoid.
EN
.
Part Number
WIR10523
D157619P05
D160092P01
18-BC107D1-1A-EN
