Summary of Contents for Booth EXL95H
- Page 1 Product Manual EXL95H/96H Chiller/Cooler Carbonator 3B7961-OR...
- Page 2 The wiring schematics included in the following pages reflect this modularity: Safety The EXL95H/96H models use a R290 (Care 40, Propane) refrigerant. Below are some safety points which the end user must adopt to mitigate the risk of unsafe conditions arising.
- Page 3 NLY12RAa (EXL96H) 520mm(H) This product contains Propane Refrigerant gas with a GWP of 3 in a hermetically sealed system EXL95HX – 49Kg EXL95HC - 59Kg R290, 105g (EXL95H) Refrigerant Dry Weight EXL96HX – 55Kg R290, 80g (EXL96H) EXL95HX – 3.1A EXL96HC - 65Kg EXL95HX –...
- Page 4 Non-Carbonator Deck + GPR10-15 Pump 1A6614 Non-Carbonator Deck + Mag Drive Pump 1A6673 Control Type 1A6543 DFx Digital Control 1A6544 Eliwell Digital Control 1A6545 EXL95H Mechanical Control 1A6712 EXL96H Mechanical Control Coils 1A6671 0 Coil Pack 1A6670 6 Coil Pack...
- Page 5 Locate a container beneath the bath overflow to prevent any water spillage as ice is formed in the bath, and fill the bath with cold water until it comes out of the overflow. For the EXL95H/96H Carbonator Deck Turn off the soda recirc pump and disable the can fill circuit by means of the 2 switches located on the front of the unit.
- Page 6 It is also advisable to initially pull off approx. 1ltr – 2litres of carbonated water per dispense point to allow the carbonated water to circulate round the system. For the EXL95H/EXL96H Non-Carbonator Deck ...
- Page 7 Schematics – EXL95H Base Wiring IEC TO DECK COMPRESSOR INDICATOR FAN OR GLYCOL PUMP GN/YE CONTROL MODULE CARBONATOR CA...
- Page 8 Schematics – EXL96H Base Wiring IEC TO DECK COMPRESSOR INDICATOR FAN OR GLYCOL PUMP GN/YE CONTROL MODULE CARBONATOR C...
- Page 9 Schematics – EXL95H/96H GPR10-15 Pump Carb Deck Wiring...
- Page 10 Schematics – EXL95H/96H RV/Mag Drive Pump Carb Deck Wiring...
- Page 11 Schematics – EXL95H/96H GRP10-15 Non Carb Deck Wiring...
- Page 12 Schematics – EXL95H/96H RV/MAG Drive Non Carb Deck Wiring...
- Page 13 Schematics – Module wiring...
- Page 14 Schematics – EXL95H/96H Carb Deck Water Circuit...
- Page 15 Schematics – EXL95H/96H Non Carb Deck Water Circuit...
- Page 16 Fault Finding – EXL95H/96H Carb Deck...
- Page 17 Fault Finding – EXL95H/96H Non Carb Deck...
- Page 18 Replacement Parts – EXL95H/96H Carb Deck Item No Description Part No 1A5417 Soda recirc pump GPR10-15 1A6677 Soda recirc pump RV Motor Only 1A5368 Soda recirc pump RV Pump Head Only 1A5907 Soda recirc pump Mag Drive 3B7844 Water Inlet Solenoid...
- Page 19 Replacement Parts – EXL95H/96H Non Carb Deck Replacement Parts – EXL65H Carb Deck Replacement Parts – EXL55H Non Carb Deck Item No Description Part No Soda recirc pump GPR10-15 1A6677 Soda recirc pump RV Motor Only 1A5368 Soda recirc pump RV Pump Head Only...
- Page 20 Replacement Parts – EXL95H Base Item No Description Part No Condenser Fan Motor CPART0045S Control Modules Mechanical Thermostat 1A6636 Eliwell Control 3B3472 Eliwell 1.5m Probe 3B4341 DFx Control 1A5625...
- Page 21 Replacement Parts – EXL96H Base Item No Description Part No ATEX Fan 3B7692 Glycol Pump – Totton GP20/18 3B4580 Toroidal Transformer 1A5662 Heat dump fan motor complete – HDU301 1A5742 Heat dump fan motor only 3B4830 Heat dump cartridge assembly – HDU301 1A5630 Control Mechanical Thermostat...
- Page 22 It is illegal to simply scrap a refrigeration unit. Before a unit can be scrapped it must first have the gas removed by a specialist using special equipment. Please contact Booth Dispensers Ltd., who will be happy to provide a quotation for disposal.
- Page 24 Booth Dispensers Ltd, Moor Park Avenue, Blackpool, Lancashire, FY2 0LZ, UK +44 1253 501800...
