Summary of Contents for Coaster 100952
- Page 1 100952 OAK CHAIR ASSEMBLY INSTRUCTION COASTER FINE FURNITURE 100951 100952 www.coastercompany.com page 1 of 4 2012/05/...
- Page 2 ITEM : 100952 ASSEMBLY INSTRUCTION Assembly Instruction ASSEMBLY TIPS: 1.Remove hardware from box and sort by size. 2.Please check to see that all hardware and parts are present prior to start of assembly. 3.Please follow attached instructions in the same sequence as numbered to assure fast &...
- Page 3 ASSEMBLY INSTRUCTION ITEM : 100952 HARDWARE PACKAGE DESCRIPTION FIGURE Q’TY BOLT 4 PCS 4 PCS BOLT METAL WASHER 12PCS 13mm HEX NUT 8 PCS WOODEN PLUG 4 PCS GLUE 1 PC 1 PC ALLEN WRENCH STEP 2: STEP 1: Insert the Supporting Insert the Casters H into the Base G .
- Page 4 ASSEMBLY INSTRUCTION ITEM : 100952 STEP 5: Attach the Left (Right) Armrests (A /B) and the Left (Right) Bac rest (C /D) onto the Seat (E) with Metal Washer (3) and Nut (4) . (Don’t tighten the Bolts (1) untils step 6)
