- Page 1 All manuals and user guides at all-guides.com SM-CMD3011 MULTIMEDIA DVD/CD/MP3 RECEIVER WITH BUILT-IN AND TV TUNER Instruction manual DVD/CD/MP3- TFT-...
-
Page 2: Table Of Contents
All manuals and user guides at all-guides.com Dear customer! Thank you for purchasing our product. For safety, it is strongly recommended to r before connecting, operating and/or adjusting the product and keep the manual fo Table of contents Table of contents................... Important safeguards .................. -
Page 3: Important Safeguards
All manuals and user guides at all-guides.com Important safeguards Using the device at temperature below -10º may cause the breakage of please heat up the passenger compartment to the recommended temperature Disconnect the vehicle's negative battery terminal while mounting and conne When replacing the fuse, be sure to use one with an identical amperage ra higher amperage rating may cause serious damage to the unit. -
Page 4: Accessories
All manuals and user guides at all-guides.com Accessories 1. Mounting Sleeve 1 pc 2. Bracket 2 pcs 3. Key 2 pcs 4. Screw 2.6X4 2 pcs 5. Outer Frame 1 pc 6. Rear Mounting Bolt 1 pc 7. Harness Rubber 1 pc 8. -
Page 5: Installation/Connection
All manuals and user guides at all-guides.com Installation/Connection Installation method 1... - Page 6 All manuals and user guides at all-guides.com Installation method 2 This mounting method is used for Japanese c 1. Store small articles in places not accessib 2. Install only with the supplied screws. 3. Installation varies depending on the ty parts.
- Page 7 All manuals and user guides at all-guides.com Electrical connection Note: For your driving safety, please link your parking wire with low power level, manual brake switch. Wire should be high power level and the unit cannot play vi...
- Page 8 All manuals and user guides at all-guides.com Using the ISO Connector 1. If your car is equipped with the ISO connector, then co as illustrated. 2. For connections without the ISO connectors, check t carefully before connecting, incorrect connection may caus unit.
-
Page 9: Panel Controls
All manuals and user guides at all-guides.com Panel controls Front panel LOU/TA button OPEN button VOL knob/SEL button 1/OSD button 2/INT button 3/RPT button AMS button SD/MMC slot USB jack 10. PREVIOUS/NEXT button 11. DISP button 12. BND/SYS button 13. 6/PLAY button 14. - Page 10 All manuals and user guides at all-guides.com Remote control MODE button PWR button BND/SYS button Cursor buttons (LEFT/RIGHT/UP/DOWN), ENTER button STOP/RETURN button ST/PROG button AMS/RPT button LOC/RDM button OSD button 10. PBC button 11. Number buttons 12. 10+ button 13. PLAY/PAUSE button 14.
- Page 11 All manuals and user guides at all-guides.com Changing the battery 1. Press the catch and at the same time pull out the battery tra 2. Insert the 1 x lithium battery, type CR 2025 3V battery with facing upward. Insert the battery tray into the remote contro Warning: Store the battery where children cannot reach.
-
Page 12: General Operation
All manuals and user guides at all-guides.com General operation Reset the unit Operating the unit for the first time or after replacing the car battery, you must down the front panel. Press RESET button with a pointed object to restore the u settings. - Page 13 All manuals and user guides at all-guides.com Mode control Press MODE button on the panel or MOD button on the RC to select different s DISC (the type of disc in the unit if there is any) => USB (if a USB device is SD/MMC card is inserted) =>...
-
Page 14: Radio Operation
All manuals and user guides at all-guides.com Radio operation Band selection Press BND/SYS button repeatedly to select FM1, FM2, FM3, AM1, AM2. Display frequency and preset station number if already stored. Manual/Automatic tuning Manual tuning: Press PREVIOUS/NEXT buttons on the panel or SEEK+/SEE select a station upward or downward step-by-step. - Page 15 All manuals and user guides at all-guides.com Local mode Press LOC/RDM button on the RC to switch on/off Local tuning mode. When Local mode the display and only local stations are available. When Local mode is off both distanc received. RDS function RDS (Radio Data System) service availability varies with areas.
-
Page 16: Usb/Sd/Mmc Cards/Disc Operations
All manuals and user guides at all-guides.com USB/SD/MMC cards/Disc operations Disc glossary PBC (Play Back Control) PBC is a menu recorded on the disc with SVCD or VCD2.0 format. For the dis playback interactive software with the menu displayed on TV. And if the disc co playback high definition of still image. - Page 17 All manuals and user guides at all-guides.com Playing/pausing When the disc/card/USB has been loaded, the playback of the first track starts good system performance, wait until the unit finishes reading the disc informat press the PLAY/PAUSE button on the RC or 6/PLAY button on the unit to start p pause the playback.
- Page 18 All manuals and user guides at all-guides.com Random playback During playback press the LOC/RDM button on the RC or 4/RDM button on th random playback mode. This function is not available for DVD discs. Intro playback (for CD/VCD) You can play the beginning of every track for 10 seconds in sequence. Press the play of whole disc.
- Page 19 All manuals and user guides at all-guides.com On-screen display (OSD) During playback press OSD button on the RC repeatedly to show various pla screen. The information may include (depending on the disc type): the title/track/chapter, the elapsed time of the current title/track/chapter, the rema title/track/chapter, the elapsed time of the disc, the remained time of the disc.
- Page 20 All manuals and user guides at all-guides.com Mixed disc operations When a disc containing audio, picture and video files is played, Category/Folder/F the display, and the name of currently played file/folder will be displayed on top. be highlighted. Category Select Use LEFT/RIGHT cursor buttons to select: Audio files Picture files...
-
Page 21: Mp3 Overview
All manuals and user guides at all-guides.com MP3 overview Notes on MP3: MP3 is short for MPEG Audio Layer 3 and refers to an audio compression techn This product allows playback of MP3 files on CD-ROM, CD-R or CD-RW discs. The unit can read MP3 files written in the format compliant with ISO 9660. -
Page 22: System Setup Menu
All manuals and user guides at all-guides.com System setup menu Press the SETUP button on the RC to display the system setup menu. Use the LEFT/RIGHT cursor buttons on RC to select the desired menu: System Audio setup, Video setup, Speaker setup, Digital setup. Press OK to enter it. - Page 23 All manuals and user guides at all-guides.com Language setup OSD language Select the OSD language. Audio language Select the audio language (if DVD disc supports several audio languages). Subtitle language Select the subtitle language (if DVD disc supports several subtitle languages).
-
Page 24: Tv Operation
All manuals and user guides at all-guides.com Speaker setup LT/RT: The audio out is Left and Right channels format even if the original sound is 5.1CH format. Stereo: The audio out format is stereo even if the original sound is 5.1CH format. -
Page 25: Back View Camera
All manuals and user guides at all-guides.com Back view camera This unit is equipped with back view camera output. The camera is used to observ vehicle when you are backing the car. Please connect your back view camera with the back car video input. And conn back a car with the rear gear light. -
Page 26: Troubleshooting Guide
All manuals and user guides at all-guides.com Troubleshooting guide Symptom Cause The car ignition is not on. If the power sup No power connected to th the ignition key The fuse is blown. Replace the fuse Disc cannot be loaded. Presence of disc inside the player. -
Page 27: Specification
All manuals and user guides at all-guides.com Specification General Power supply: 12 V DC Maximum power output: 50 W x 4 channels Compatible formats: DVD/SVCD/VCD/HDCD/MP3/WMA/CDDA/Picture-CD/ Supported disc types: DVD/DVD±R/DVD±RW/CD/CD-R/CD-RW/USB/SD/MM Dimensions (L x W x H): 165 x 178 x 50 mm ESP function: 40 sec. - Page 28 All manuals and user guides at all-guides.com ......................................................................................................................... USB- SD/MMC/ ...... 3 ..................................................................................................................................
- Page 29 All manuals and user guides at all-guides.com -10º...
- Page 30 All manuals and user guides at all-guides.com 1 pc 2 pcs 2 pcs 2.6X4 2 pcs 1 pc 1 pc 1 pc 1 pc 1 pc 1 pc 1 pc 1 pc...
- Page 31 All manuals and user guides at all-guides.com...
- Page 32 All manuals and user guides at all-guides.com...
- Page 33 All manuals and user guides at all-guides.com...
- Page 34 All manuals and user guides at all-guides.com ISO, ISO ( (+) - (-) - 12 (+)/ (-) - (-) - ACC+/ (+) - (-) -...
- Page 35 All manuals and user guides at all-guides.com LOU/TA OPEN VOL/ 1/OSD 2/INT 3/RPT SD/MMC PREVIOUS/NEXT DISP BND/SYS 6/PLAY 5/STOP 4/RDM AF/ST EQ/PTY RESET EJECT...
- Page 36 All manuals and user guides at all-guides.com MODE BND/SYS ENTER STOP/RETURN ST/PROG AMS/RPT LOC/RDM PLAY/PAUSE MUTE TITLE SUB-T SETUP ANGLE SLOW VOL-/VOL+/SEEK-/PREVIOUS/ SEEK+/NEXT/SEL ZOOM AUDIO GOTO...
- Page 37 All manuals and user guides at all-guides.com (CR 2025 3V),...
- Page 38 All manuals and user guides at all-guides.com OPEN, RESET VOL+/- MUTE «MUTE ON». SEL, : VOL ( ) => BAS ( ) => BAL ( ) => FAD ( ) => COT ( ) => COR ( ) => HUE ( VOL,...
- Page 39 All manuals and user guides at all-guides.com MODE : TUNER ( ) => DISC ( ) => USB ( => CARD ( SD/MMC ) => AUX => TV. DISP; VOL+/- SEL; VOL+/- LOUD LOU/TA LOUD EQ/PTY, => CLAS.
- Page 40 All manuals and user guides at all-guides.com BND/SYS, : FM1, FM2, FM3, PREVIOUS/NEXT SEEK-/SEEK+ (18 FM, 12 AM). PREVIOUS/NEXT (1-6), AMS, AMS.
- Page 41 All manuals and user guides at all-guides.com AF/ST, “ST ON”. LOC/RDM Local “LOC ON”. RDS ( RDS. “RDS”. AF ( AF/ST, «AF ON». EQ/PTY, PTY. VOL+/- TA ( LOU/...
- Page 42 All manuals and user guides at all-guides.com USB- SD/MMC/ PBC ( – PBC, – DVD- – OPEN DISC. EJECT (...
- Page 43 All manuals and user guides at all-guides.com SD/MMC/USB SD/MMC USB- PLAY/PAUSE 6/PLAY STOP/RETURN PLAY/PAUSE STOP/RETURN 5/STOP PREVIOUS/NEXT DVD/VCD: : X2 => X4 => X8 => X16 => X20. PLAY/PAUSE...
- Page 44 All manuals and user guides at all-guides.com DVD/VCD) DVD/VCD SLOW, X1/2 => X1/3 => X1/4 => X1/5 => X1/6 => X1/7. PLAY/PA 6/PLAY VCD/CD . 1 ( ) => ) => ) => . 1 ( ) => => LOC/RDM Intro ( CD/VCD) 2/INT,...
- Page 45 All manuals and user guides at all-guides.com PBC ( PBC, ST/PROG VCD, CD, MP3, WMA PLAY ENTER, CLEAR ST/PROG, SUB-T DVD) AUDIO...
- Page 46 All manuals and user guides at all-guides.com DVD/VCD) ZOOM : X2, X3, X4, X1/2, X1/3, X1/4, DVD- VCD) AUDIO Left ( ) => Right ( ) => Stereo ( DVD/VCD) BAND/SYS : NTSC => PAL => GOTO ( GOTO,...
- Page 47 All manuals and user guides at all-guides.com ENTER ENTER ENTER PLAY/PAUSE, STOP/RET 5/STOP,...
- Page 48 All manuals and user guides at all-guides.com MPEG3 CD-ROM, “.mp3”. “.mp “ PC “ ” “ ” 448. VBR, . VBR:...
- Page 49 All manuals and user guides at all-guides.com CD-R CD-RW, 44,1 ISO 9660, CD-R MP3 CD-R CD-RW CD-R CD-RW CD-R CD-RW...
- Page 50 All manuals and user guides at all-guides.com SETUP ENTER, NTSC: PAL: 4:3 PS: 4:3 LB: 16:9:...
- Page 51 All manuals and user guides at all-guides.com SPDIF/RAW: SPDIF/PCM:...
- Page 52 All manuals and user guides at all-guides.com LOGIC Dolby, 5.1,...
- Page 53 All manuals and user guides at all-guides.com AMS, «SCAN ONE». AMS, ALL», NEXT NEXT PREVIOUS, ST/PROG,...
- Page 54 All manuals and user guides at all-guides.com...
- Page 55 All manuals and user guides at all-guides.com “...
- Page 56 All manuals and user guides at all-guides.com DVD/SVCD/VCD/HDCD/MP3/WMA/CDDA/P (DivX) DVD/DVD±R/DVD±RW/CD/CD-R/CD-RW/U 165 x 178 x 50 CD, 120 3.5- TFT- 480x272 300:1 .: 120 .: 120 65.0 – 74.0/87.5 – 108.0 - 1620 - 20 RCA- (2V)
