JL AUDIO
e1800D
monoblock subwoofer amplifier
o w n e r ' s m a n u a l
Thank you for purchasing a JL Audio amplifier for
your automotive sound system.
Your amplifier has been designed and manufactured to exacting
standards in order to ensure years of musical enjoyment in your
vehicle. For maximum performance and extended warranty
coverage, we highly recommend that you have your new amplifier
installed by an authorized JL Audio dealer. Your authorized
dealer has the training, expertise and installation equipment to
ensure optimum performance from this product. Should you
decide to install the amplifier yourself, please take the time
to read this manual thoroughly so as to familiarize yourself
with its installation requirements and setup procedures.
If you have any questions regarding the instructions in this
manual or any aspect of your amplifier's operation, please contact
your authorized JL Audio dealer for assistance. If you need further
assistance, please call the JL Audio Technical Support Department at
(954) 443-1100 during business hours (Eastern Time Zone).
Advertisement
Table of Contents
Related Manuals for JL Audio E1800D
Summary of Contents for JL Audio E1800D
- Page 1 If you have any questions regarding the instructions in this manual or any aspect of your amplifier’s operation, please contact your authorized JL Audio dealer for assistance. If you need further assistance, please call the JL Audio Technical Support Department at...
-
Page 2: Protect Your Hearing
Cooling Efficiency Considerations: The outer shell of your JL Audio amplifier is designed to remove heat from the amplifier circuitry. For optimum cooling performance, this outer shell should be exposed to as large a volume of air as possible. -
Page 3: Product Description
If only the e1800D is being run from that power wire, we recommend a 80A fuse be used. ANL (big blade fuse), AGU (big glass fuse) or MaxiFuse™ (big plastic-body fuse) types are recommended. -
Page 4: Input Section
1) Filter Operation: The low-pass filter in the e1800D is fully variable between 40 Hz and 200 Hz via the “Filter Freq.” control knob and features the ability to select between a moderate “12dB” per octave or a steep “24dB”... - Page 5 If your amplifier fails or malfunctions, please return it to your authorized JL Audio dealer so that it may be sent in to JL Audio for service. There are no user serviceable parts or fuses inside the amplifier.The unique nature of the circuitry in the JL Audio amplifiers requires specifically trained service personnel.
- Page 6 APPENDIX A: Input Sensitivity Level Setting Following the directions below will allow the 9) Once you have adjusted the e1800D to its installer to adjust the input sensitivity of the maximum low-distortion output level, lower the amplifier(s) simply and easily in just a few minutes...
-
Page 7: Appendix D: Trouble Shooting
“MY AMPLIFIER’S OUTPUT FLUCTUATES WHEN I TAP ON IT OR HIT A BUMP” “HOW DO I PROPERLY SET THE INPUT SENSITIVITY ON MY AMPLIFIER” JL AUDIO e1800D JL AUDIO e1800D Check the input signal using an AC voltmeter to measure the voltage... -
Page 8: Installation Notes
INSTALLATION NOTES: Use this diagram to document your amplifier’s switch and control positions. JL AUDIO e1800D JL AUDIO e1800D... - Page 9 LIMITED WARRANTY - AMPLIFIERS (USA) JL AUDIO warrants this product to be free of defects in materials and workmanship for a period of ninety (90) days from the original date of purchase. The warranty term is extended to two (2) years if installation is performed or approved by an authorized JL AUDIO dealer (proof of installation or approval required on purchase receipt).
