ZUDSEC ZDAC-236C User Manual

1. Product Specification

Model: ZDAC-236C Index
Operating Voltage 12VDC+10%; Current 1.2A
Lock Relay 12VDC/2A
Item
Environmental temperature working:0℃~45℃; storage:-10℃~55℃
Relative humidity working:40%~90%RH;storage:-20%~90%RH
RFID Card Capacity 1000 cards
4-digits public PIN Capacity 1
Proximity Reader Frequency 125KHz
Compatible Cards EM or EM compatible cards
Card Reading Distance 5—15CM

2. The LED and Buzzer

Status type
Normal Working State
Authorized Card Read /Valid PIN/Exit Button
Pressed
Wrong PIN Entered
Non Authorized Card Read
Acceptable Key Pressed
Door Sensor, Anti-Break Sensor Alarmed
Programming Mode
Key In Right Programming Instruction
Key In Wrong Programming Instruction

3. The Factory Default of the Product

Green LED Red LED Buzzer
flash
on a short beep
flash a long beep
flash a long beep
flash a short beep
flash continuous beeps
on flash 2 short beeps
on flash 2 short beeps
on flash 3 short beeps
Type Factory Default
6-digit Programming PIN 990101
Door Open Mode Authorized Card / Public PIN (Default Public PIN: 1234)
Lock Relay Time 3 seconds
Anti-Break Sensor Alarm Disabled
Door Sensor Alarm Disabled
Authorized Card Stored none
4. Functions and Settings (All functions should be set in programming mode; the
parameters can be set repeatedly; the effective setting should be the last one.)
1. Enter programming mode:
Press [*]+[6 digits programming PIN],2 beeps;
Under programming state, it should be noted that:
1） The controller cannot perform normal function instructions.
2） If there is no programming instruction within 20 seconds, system will automatically quit
programming mode and enter the normal working mode.
3） Successfully set parameters, 2 beeps;
4） Fail to set parameters, 3 beeps;
5） Before some setting instruction is finished（i.e. the controller have already given off 2 beeps for
successful setting, or 3 beeps for failed setting）, if the input instruction is mistaken, press [*], the
controller gives off a long beep, meaning that the setting of the instruction has been cancelled.
2. Change programming PIN:
Press [0]+[6 digits new programming PIN]+[repeat 6 digits new programming PIN], 2 beeps;
3. Set door open mode:
1） Card or Public PIN:
Press [1]+[0], 2 beeps;
2） Card plus Personal PIN;
Press [1]+[1], 2 beeps;
4. Set Lock Relay Time:
Press [2]+[TT], 2 beeps; TT represents unlocking time, second as unit; if unlocking time is 3 seconds,
TT=03;
5. Set Public PIN:
Press [3]+[4 digits public PIN], 2 beeps;
Press [3]+[0000], 2 beeps, eliminate all "public PIN"
