156"
PLAN VIEW
SCALE: 1/8" = 1'-0"
DRAWN BY:
J. SMITH
CHECKED BY:
J. OLSON
BASIC 14' x 14' GAZEBO
QUICK REFERENCE OVERVIEW SHOWING BASIC COMPONENTS
SCALE:
AS NOTED
DATE:
12/28/2015
82 3
"
8
ELEVATION
SCALE: 3/16" = 1'-0"
NOTE: MAKE SURE BUILDING SITE IS
LEVEL AND HAS NO OBSTRUCTIONS
(ROOF OVERHANGS, ELECTRICAL
WIRES, TREE BRANCHES, ETC.)
SKYLIGHT
MAINTENANCE
FREE ROOF
SILL FRAME
CORNER PILLARS
(DESIGN STYLES VARY
FROM MODEL TO MODEL)
EXISTING DECK OR
PATIO SURFACE
14' x 14' Gazebo
TITLE:
Overview
REVISION NUMBER:
JOB #:
14x14
DATE:
DWG #:
PAGE 1
Advertisement
Related Manuals for A&B Accessories BASIC 14 x 14
Summary of Contents for A&B Accessories BASIC 14 x 14
- Page 1 BASIC 14' x 14' GAZEBO QUICK REFERENCE OVERVIEW SHOWING BASIC COMPONENTS NOTE: MAKE SURE BUILDING SITE IS LEVEL AND HAS NO OBSTRUCTIONS (ROOF OVERHANGS, ELECTRICAL WIRES, TREE BRANCHES, ETC.) SKYLIGHT MAINTENANCE FREE ROOF 156" SILL FRAME 82 3 CORNER PILLARS "...
- Page 2 PART A: PART B: PART D: DIAGONAL PART D1: PART E: MIDDLE CORNER RAFTER MIDDLE RAFTER PART C: SILL PLATE CORNER GUSSET CORNER GUSSET ROOF SUPPORT QTY: 4 SIZE: 57 1/2" (1460mm) QTY: 8 SIZE: 26" (654mm) QTY: 8 SIZE: 79" (2010mm) QTY: 4 SIZE: 23"...
- Page 3 STEP #1: STEP #2: A. LAY OUT SILL PLATES (C) IN A SQUARE, ON A FLAT SURFACE. A. SCREW BRACKETS (T1 & T3) TO CORNER RAFTERS (A). B. ATTACH CORNER GUSSETS (D & D1) TO SILL PLATES (C) AS SHOWN. C.
- Page 4 STEP #5: STEP #6: A. CAREFULLY POSITION RAFTER ASSEMBLY ON TOP OF SILL PLATES. A. ATTACH EIGHT MIDDLE RAFTERS (B) TO SKYLIGHT FRAME. B. SCREW RAFTER ASSEMBLY TO SILL PLATES USING BRACKETS (T3). (U3) (T3) (U4) (U2) NOTE: DO NOT ATTACH LOWER END OF RAFTERS TO SILL PLATE UNTIL STEP #10.
- Page 5 STEP #9: STEP #10: A. POSITION LARGE CENTER PANELS (A-1, A-2 & A-3), A. ATTACH BOTTOM OF EIGHT MIDDLE RAFTERS (B) TO THEN SCREW INTO PLACE THROUGH PRE-DRILLED HOLES. SILL PLATES (C) WITH BRACKETS (T2) AS SHOWN. B. ALIGN LOWER CORNER PIECES (A-4 & A-5), THEN SCREW INTO PLACE. C.
