- Page 1 T24034BLK / T24034WHT / T24034SIL 20L 700W Microwave SAFETY AND INSTRUCTION MANUAL PLEASE READ CAREFULLY *Subject to registering your Extended Guarantee online at www.towerhousewares.co.uk.
- Page 2 GREAT BRITISH DESIGN, INNOVATION AND EXCELLENCE SINCE 1912 Since the turn of the 20th century, Tower has been designing, developing and manufacturing housewares and small appliances used by millions of households throughout the UK and beyond. During the 1960s, the rise in popularity of pressure cooking saw Tower become the UK’s largest producer of pressure cookers, right through into the late 1980s.
- Page 3 Contents: Specifications Components and Thank you for purchasing this appliance from the structure Tower range. Technical data Please read this manual carefully BEFORE using the appliance for your own safety. Important Safety Information It has been designed to provide many years of Before First Use trouble-free use.
- Page 4 1 - Specifications: This box contains: Instruction Manual Microwave Oven Roller Ring Glass Turntable Structure of your appliance: Door Safety Lock Roller Ring Control Panel System Glass Turntable Power Level Dial Oven Window Wave Guide Cooking Time Dial...
- Page 5 2 - Technical Data: Description: 20L Manual Microwave Model: T24034BLK / T24034WHT / T24034SIL Rated Voltage: 230-240V ~50Hz Input: 1100-1150W Output: 650-700W Microwave Frequency: 2450MHz Documentation We declare that this product conforms to the following product legislation in accordance with the following directive(s): 2014/30/EU Electromagnetic Compatibility Directive.
- Page 6 Important Safety Information: Please read these notes carefully BEFORE using your Tower appliance • • Check that the voltage Switch off at the wall of the main circuit socket then remove the corresponds with the plug from the socket rating of the appliance when not in use or before operating.
- Page 7 • This appliance can CAUTIONS be used by children • aged from 8 years and DO NOT operate the above and persons microwave with the with reduced physical, door open due to sensory or mental the safety interlocks capabilities or lack built into the door of experience and mechanism.
- Page 8 • • DO NOT operate the An exhaust outlet is microwave if it is rusty. located on the top, bottom or side of the • Please ensure cooking microwave. Don’t block times are correctly the outlet. It could set, small amounts of result in damage to food require shorter your microwave and...
- Page 9 • • DO NOT rinse the glass When food is heated or turntable by placing cooked in disposable it in water just after containers made of cooking. This may plastic, paper or other cause breakage or combustible materials damage. keep an eye on the microwave and check it •...
- Page 10 • • NOTE: The use of non- This appliance is compliant materials will intended to be used in void your warranty. household and similar applications such as: • DO NOT leave the oven Staff kitchen areas in unattended while corn shops, offices and other is being popped.
- Page 11 4 - Before First Use Take out all the packing. If there is a safe film over the oven, tear it off before use. Check carefully for damage. If any, immediately notify the place of purchase. Microwave ovens must be placed under dry and non-corrosive environments and kept away from heat and humidity, such as a gas burner or water tank.
- Page 12 5 - Using Your Appliance Door lock: The microwave door must be properly closed in order for the appliance to operate. Oven window: Allows the user to see the cooking status. Roller ring: The glass turntable sits on its wheels. It supports the turntable and helps it to balance when rotating.
- Page 13 take about 3 minutes to defrost, 0.4kg (400g) will take 6 minutes, and so on. To defrost food using the Intelligent Defrost function, set the power dial to Medium low, and use the timer dial to select the appropriate weight for the amount of food you are defrosting.
- Page 14 Microwave Material Notes Safe Grill rack Never to be used in the microwave. Microwaves Metal container cannot penetrate through metal. Microwaving with a metal container can result in fire. Poor heat resistance. Cannot be used for high Lacquer temperature cooking. Poor heat resistance.
- Page 15 Food arrangement: Place thicker foods towards the outside of the dish with the thinner foods towards the centre. Spread them evenly and avoid overlapping if possible. Cooking time length: Begin cooking on a shorter time setting and evaluate the food after it times out. Extend the time as necessary.
- Page 16 6 - Trouble Shooting & Faq’s Questions Answers Is it normal for the Yes. The glass turntable can rotate clockwise or glass turntable to turn anti-clockwise, depending on the rotation of the motor in either direction? when the cooking cycle starts. Can I operate my No, never run it empty or with a very small load for a microwave whilst it is...
- Page 17 7 - Servicing safeguards - Microwave radiation It is hazardous for anyone, other than a qualified service technician, to carry out any service for repairing operation which involves removal of any cover which gives protection against exposure to microwave energy. The temperature of accessible surfaces may be high when the appliance is operating.
- Page 18 8 - Recycling DISPOSAL OF THE UNIT Appliances bearing the symbol shown here may not be disposed of in domestic rubbish. You are required to dispose of old electrical and electronic appliances like this separately. Please visit www.recycle-more.co.uk or www.recyclenow.co.uk for access to information about the recycling of electrical items.
- Page 19 9 - Cleaning & Care • The microwave should be cleaned regularly and any food deposits removed. • Remove the power cord from the wall outlet before cleaning. Don’t immerse the appliance in water or other fluids when cleaning. • Failure to maintain the microwave in a clean condition could lead to deterioration of the surface.
- Page 20 9 - Wiring Safety for UK Use Only Earth Fuse (Green/Yellow) Neutral Live (Blue) (Brown) IMPORTANT As the colours in the mains lead of this Always ensure that the cord grip is fastened appliance may not correspond with the correctly. coloured markings identifying the terminals in your plug, please proceed as follows: The plug must be fitted with a fuse of the...
- Page 21 10 - Warranty This product is guaranteed for 12 months from the date of original purchase. If any defect arises due to faulty materials of workmanship, the faulty products must be returned to the place of purchase. Refund or replacement is at the discretion of the retailer.
- Page 22 11 - Your Receipt Affix your store receipt to this page for safe keeping.
- Page 23 NOTES...
- Page 24 thank you! We hope you enjoy your appliance for many years. As a thank you for purchasing one of our fantastic products, we are offering you an extra 2 years peace of mind in addition to your 1 year guarantee.. *To receive your extra 2 years guarantee, register your appliance online within 28 days of purchase by visiting: www.towerhousewares.co.uk...
