THIS MANUAL MUST BE LEFT WITH THE
HOMEOWNER FOR FUTURE REFERENCE
WARNING
If this unit is to be installed in a mobile or manufactured
home application, the duct system must be sized to
achieve static pressures within the manufacturer's
guidelines. All other installation guidelines must also
be followed. Failure to do so may result in equipment
damage, personal injury, and improper performance of
the unit.
WARNING
Improper installation, adjustment, alteration, service, or
maintenance can cause injury or property damage. Refer
to this manual. For assistance or additional information,
consult a licensed professional (or equivalent), HVAC
installer, service agency, or the gas supplier.
The installation of the unit, wiring, warm air ducts, venting, etc. must conform to the requirements of the National Fire
Protection Association; the National Fuel Gas Code, ANSI Z223.1 (latest edition) and the National Electrical Code, ANSI/
NFPA No. 70 (latest edition) in the United States; the Canadian Installation Codes CAN/CGA-B149.1 & .2 (latest edition)
and the Canadian Electrical Code Part 1, CSA 22.1 (latest edition) in Canada; and any state or provincial laws, local
ordinances, or local gas utility requirements. Local authorities having jurisdiction should be consulted before installation
is made. Such applicable regulations or requirements take precedence over the general instructions in this manual.
507295B03
CAUTION
Save these instructions for future reference
Issue 2122
INSTALLATION AND MAINTENANCE
INSTRUCTIONS
BPRPGE14 SERIES UNITS
RESIDENTIAL PACKAGED UNITS
Gas/Electric
507295B03
06/2021
Table of Contents
Unit Dimensions ..........................................................2
Roof Curb Dimensions ................................................4
Adjustable Roof Curb Dimensions...............................6
Installation ...................................................................8
Venting.......................................................................10
Duct System ..............................................................11
Filters .........................................................................11
Condensate Drain......................................................12
Gas Piping .................................................................12
Electrical Wiring ........................................................13
Heating Start-Up .......................................................14
Operation ...................................................................16
Maintenance ..............................................................17
WARNING
Do not store combustible materials, including gasoline
and other flammable vapors and liquids, near the unit,
vent pipe, or warm air ducts. Such actions could cause
property damage, personal injury, or death.
Manufactured By
Blue Summit LLC
8201 C National Turnpike
Louisville, KY 40214
*P507295B03*
(P) 507295B03
Page 1 of 19
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Blue Summit BPRPGE14
Summary of Contents for Blue Summit BPRPGE14
-
Page 1: Table Of Contents
INSTALLATION AND MAINTENANCE INSTRUCTIONS BPRPGE14 SERIES UNITS RESIDENTIAL PACKAGED UNITS Gas/Electric 507295B03 06/2021 Table of Contents Unit Dimensions ............2 Roof Curb Dimensions ..........4 THIS MANUAL MUST BE LEFT WITH THE Adjustable Roof Curb Dimensions.......6 HOMEOWNER FOR FUTURE REFERENCE Installation ..............8 Venting...............10... -
Page 2: Unit Dimensions
Unit Dimensions - Small Base Gas/Electric 47.66 2.48 1.98 2.33 2.33 16.77 14.02 RETURN SUPPLY 18.52 11.49 11.49 16.07 TOP VIEW 47.66 POWER ENTRY GAS ENTRY 6.94 3.25 4.56 20.31 21.06 23.19 SIDE VIEWS CONDENSATE DRAIN 3/4 NPT 5.75 3.55 40.89 21.63 4.12... - Page 3 Unit Dimensions - Large Base Gas/Electric 56.13 2.11 2.39 2.33 2.33 19.49 19.49 RETURN SUPPLY 18.52 11.49 11.49 TOP VIEW 16.07 47.66 POWER ENTRY GAS ENTRY 6.94 3.25 10.06 25.81 26.56 28.68 SIDE VIEWS CONDENSATE DRAIN 3/4 NPT 5.75 3.55 44.89 21.63 4.12...
-
Page 4: Roof Curb Dimensions
Roof Curb Dimensions - Small Base Gas/Electric 3/4 (19) RETURN Opening for Power Entry OPENING Through Unit Base 5-1/2 x 5-5/8 in. (140 x 31 mm) 16-7/8 44-3/8 (429) (1127) 11-1/2 2-1/8 (287) (54) Insulated Panels 5-3/4 13-7/8 (146) (352) SUPPLY 5-1/2 OPENING... - Page 5 Roof Curb Dimensions - Large Base Gas/Electric 3/4 (19) Opening for Power Entry Through Unit Base 5-1/2 x 5-5/8 in. 19-1/2 (140 x 31 mm) 44-3/8 (380) 11-1/2 2-1/8 (1127) (287) (54) RETURN Insulated OPENING Panels 19-1/2 (380) SUPPLY OPENING 11-1/2 (287) 8 (203)
-
Page 6: Adjustable Roof Curb Dimensions
Adjustable Roof Curb Dimensions - Small Base Gas/Electric CLIPLOCK CORNER DETAIL Top Edge Wood Nailer Strip CURB PROFILE Bottom Flange Typical Slot Typical Locking Tab NOTE: See Cliplock 1000 installation instructions for complete assembly and installation procedures and requirements. 1-3/4 Opening for Power Line Entry thru base 16-7/8... - Page 7 Adjustable Roof Curb Dimensions - Large Base Gas/Electric CLIPLOCK CORNER DETAIL Top Edge Wood Nailer Strip Bottom Flange CURB PROFILE Typical Slot Typical Locking Tab NOTE: See Cliplock 1000 installation instructions for complete assembly and installation procedures and requirements. 1-3/4 Opening for Power Line Entry thru base 19-5/8...
-
Page 8: Installation
Installation Unit is designed for outdoor installation only. Unit must be installed so all electrical components are protected These instructions must be saved for future reference. from water. These units are single package air conditioners with gas Condenser coils must have an unlimited supply of air. heat designed for outdoor installation on a rooftop or a For ground level installation, use a level prefabricated slab. - Page 9 • Return air temperature range between 55°F (13°C) Clearance to Clearance for and 80°F (27°C) must be maintained. Combustibles Service Access Air filters must be replaced and pre-filters must be • Front of unit 0 in. 24 in. removed upon construction completion. Back of unit 0 in.
-
Page 10: Venting
All panels must be in place for rigging. Venting Place field-provided spreaders in place. Spreaders The vent outlet must be installed in a location as to prevent must be of adequate strength and length (must exceed building degradation and must be consistent with the unit dimension by 6 inches). -
Page 11: Duct System
Duct System NOTE: The duct system should be designed and sized according to the methods in the Air Conditioning Contractors of If an existing gas furnace is being removed from a America (ACCA) manual that is most appropriate to the common venting system when this packaged unit is installation application. -
Page 12: Condensate Drain
To prime trap, pour several quarts of water into drain, Unit Model Filter 1 Filter 2 enough to fill drain trap and line. 24, 30, 36 14 x 20 x 1 20 x 20 x 1 42, 48, 60 20 x 20 x 1 CAUTION Table 2. -
Page 13: Electrical Wiring
NOTE: An optional bottom-entry gas kit is available for Carefully rinse piping thoroughly after completing these units. See the kit instructions for proper installation leak detection. details. NOTE: An optional bottom-entry gas kit is available for these units. See the kit instructions for proper installation details. -
Page 14: Heating Start-Up
Four wires are required for cooling. The heat anticipator FIELD-SUPPLIED FUSED setting is 0.75 amp. OR CIRCUIT BREAKER CONTACTOR GROUND DISCONNECT Compressor Units are shipped with compressor mountings factory- adjusted and ready for operation. CAUTION Do not loosen compressor mounting bolts. If 208 Volt is supplied, transformer connection must be changed Figure 5. - Page 15 To Shut Down Main Burners 99,750 BTU/HR, which is close to the 100,000 BTU/HR rating of the furnace. Turn off electrical power to unit. Slide the gas valve switch to the “OFF” position (see Manifold Gas Pressure Adjustment Regulator – LP/ Figure 7).
-
Page 16: Operation
To change orifice: A combustion air inducer operates for the first 10 seconds of every cooling cycle to prevent insects from nesting in Remove screws that fasten the manifold to the the flue outlet. burner box assembly and remove the manifold. Remove the orifices, then install replacement Blower Delay –... -
Page 17: Maintenance
Heating Sequence of Operation Flame Sensor When the thermostat calls for heating, R is closed to W. The If the ignition control does not receive a signal from the following describes the gas heating sequence of operation. flame sensor indicating that the burners have established flame, the gas valve closes after the 10-second trial for A call for heat from the room thermostat starts the ignition period. - Page 18 Condenser coil may need to be cleaned at startup in clean the wheel and housing. Run the wire brush down the flue extension at the outlet of the vent housing. case oil from the manufacturing process is found on the condenser coil.
- Page 19 Figure 8. Wiring Diagram – Single Phase CT 507295B03 Issue 2122 Page 19 of 19...
