Operating manual
Lighting fitting for welding
10503, 10504
1
General ............................................................................................................................................................. 1
2
Safety Information ............................................................................................................................................ 2
3
Delivery, Completeness, Storage ...................................................................................................................... 2
4
Installation, Operation, Maintenance ............................................................................................................... 2
1 General
1.1
1.2
1.3
1.4
1 / 4
Albert Handtmann Armaturenfabrik GmbH & Co. KG
Arthur-Handtmann-Str. 11; D-88400 Biberach
Tel.: +49(0) 73 51/3 42-0; Fax: +49(0) 73 51/ 3 42-44 80
E-Mail:
sales.fittings@handtmann.de
Lighting fitting is used in the food, beverage, pharmaceutical and chemical industries. It is
intended for the tank installation to improve the visual product control.
During installation, operation and maintenance please pay attention to the generally
accepted safety regulations as well as to the operating instructions.
Misuse is:
•
Application in different operating conditions as intended for the specific type.
•
Installation, operation and maintenance by unqualified staff.
•
Any unauthorized modification of the valve or a valve component.
•
On-observance of the operating instructions.
Any misuse will automatically lead to a loss of right to claim under guarantee as well as
any liability.
The operator has to make sure that:
•
The valve/component is operated properly and only in functional condition.
•
The legal requirements are kept during operation and maintenance.
•
Only sufficiently qualified and authorized staff maintain the valve/component.
•
The staff responsible for operation and maintenance know and obey the
operating instructions and in particular the safety advice.
•
The safety and warning signs remain on the valve/component and are
always legible.
Albert Handtmann Armaturenfabrik GmbH & Co. KG
BA_010503.05_EN
2018-03-26
Advertisement
Table of Contents
Related Manuals for handtmann 10503
Summary of Contents for handtmann 10503
- Page 1 Safety Information ............................2 Delivery, Completeness, Storage ........................2 Installation, Operation, Maintenance ....................... 2 1 General Manufacturer Albert Handtmann Armaturenfabrik GmbH & Co. KG Arthur-Handtmann-Str. 11; D-88400 Biberach Tel.: +49(0) 73 51/3 42-0; Fax: +49(0) 73 51/ 3 42-44 80 E-Mail: sales.fittings@handtmann.de Proper application Lighting fitting is used in the food, beverage, pharmaceutical and chemical industries.
- Page 2 Always check the material for transport damages. Possible damages have to be informed immediately. • Store the material in a dry place and if possible in its original packaging. 4 Installation, Operation, Maintenance BA_010503.05_EN 2018-03-26 Albert Handtmann Armaturenfabrik GmbH & Co. KG 2 / 4...
- Page 3 Sight glass from pressed hard glass DIN 8902: temperatures up to 150 °C max. operating pressure 6 bar Standard 10503 - Lighting fitting with halogen lamp. Optional 10504 - LED stainless steel light Assembly instructions Prior to welding-in the lighting fitting has to be dismounted.
- Page 4 Upon exchange – pay attention to the type of the halogen lamp. Spare parts 10503/10504 10503 10504 010503.00080LE 010503.00125LE 010504.00125LE 010503.00150LE 010504.00150LE 010503.00200LE 010504.00200LE LE – EPDM BA_010503.05_EN 2018-03-26 Albert Handtmann Armaturenfabrik GmbH & Co. KG 4 / 4...
