Doc. N.° 1SDH002012A1621 - ECN000176800 - Rev. A

SACE Tmax XT

Flange Handle Breaker Mechanism XT6

Flange Handle Meccanismo Interruttore XT6

Kabelbetätigungsmechanismus XT6

Mécanisme de câble opérateur XT6

Mecanismo de operador de cable XT6

电缆操纵器机构

XT6

1SDA115551R1 Flange Handle Breaker Mechanism Kit XT6

XT6

Tools

Outils

Werkzeug

Herramienta

Utensile

Ferramentas

Gereedschap

Narzędzia

ST 5x18

T10

T25

#3/16

Page 1 Doc. N.° 1SDH002012A1621 - ECN000176800 - Rev. A SACE Tmax XT Flange Handle Breaker Mechanism XT6 Flange Handle Meccanismo Interruttore XT6 Kabelbetätigungsmechanismus XT6 Mécanisme de câble opérateur XT6 Mecanismo de operador de cable XT6 电缆操纵器机构 Tools Outils Werkzeug Herramienta Utensile Ferramentas Gereedschap Narzędzia...
Page 2 NOTE: Follow recommended installation conditions for XT6 breaker as per instruction sheet 1SDH002011A1002. TRIPPED Push to Trip...
Page 3 ST 5x18 Max. 1.0 N-m Max. 9 lb-in...
Page 4 5 Nm 44.25 lb in...
Page 5 Accessory wire routing through cable rack Cable rack Use the highlighted area for accessory wire routing out of the breaker...
Page 6 Cable short end (Pick from Cable XT1..XT6 Kit) Pick from Flange Handle Kit Cable long end(Pick from Cable XT1..XT6 Kit) Pick from Breaker Mechanism Kit...
Page 7 Pick from Flange Handle Kit...
Page 8 Ensure gap between Edge Guard and Breaker Handle as shown before inserting the Drive Pin into the hole of Yoke.
Page 9 TRIP TRIP...
Page 10 Ensure gap between edge guard and breaker handle as shown TRIP TRIPPED Push to Trip...
