SPEAKER PLACEMENT
Proper placement of the
speakers is an important step
in obtaining the most realistic
soundstage possible. These
recommendations are for the
optimum placement of the
loudspeakers. Use these
placement recommendations
as a guide. Slight variations
will not diminish your listen-
ing pleasure.
All of the Northridge E Series
loudspeakers referred to in
MODELS: E30, E50
As front speakers
MODEL: EC35
The EC35 center channel
loudspeaker is designed to
complement all of the
Northridge E Series loud-
speakers. It is the ideal way
to re-create the cinematic
experience in your home.
this guide are video-shielded
and can safely be placed
near a television.
MODELS: E60, E80, E90, E100
As surround speakers
0 – 2 ft.
(0–0.6m)
NORTHRIDGE
E30, E50, E60, E80, E90,
E100, EC35
OWNER'S GUIDE
5 – 6 ft.
(1.5m–1.8m)
™
E SERIES
®
Advertisement
Related Manuals for JBL Northridge Series E 100
Summary of Contents for JBL Northridge Series E 100
-
Page 1: Speaker Placement
SPEAKER PLACEMENT Proper placement of the speakers is an important step in obtaining the most realistic soundstage possible. These recommendations are for the optimum placement of the loudspeakers. Use these placement recommendations as a guide. Slight variations will not diminish your listen- ing pleasure. -
Page 2: Speaker Connections
(–) terminals. It is impor- tant to connect both speakers identically: (+) on the speaker to (+) on the amplifier and (–) on the speaker to (–) on the amplifier. Wiring “out of phase” results in thin sound, weak bass and poor imaging. -
Page 3: Troubleshooting
If the problem has followed the speaker, consult your dealer for further assistance or, if that is not possible, visit www.jbl.com for further information. If the system plays at low volumes but shuts off as volume is increased: •... -
Page 4: Specifications
