Flight 60
Your Partner in Ventilation
Nebulizer Port
Synchronized &
Volume Compensated
The nebulization feature provides a synchronized flow of 7LPM (±1LPM) to power a pneumatic nebulizer
connected to the nebulizer outlet.
The in-line nebulizer is powered by 100% O
, is synchronized with the patient inspiratory phase of each
2
breath, and can be adjusted in increments of 5 minutes for a maximum of 60 minutes.
The ventilator volume ventilation algorithm compensates for the additional in-line volume.
The nebulizer should be connected to the inspiratory limb per the institution's policy and procedures.
Connecting the nebulizer between the flow sensor and the endotracheal tube increases the dead space
ventilation.
Note: Nebulizer cannot be activated when set volume < 200ml

Advertisement

loading

Related Manuals for Flight Medical Innovations Flight 60

Summary of Contents for Flight Medical Innovations Flight 60

  • Page 1 Flight 60 Your Partner in Ventilation Nebulizer Port Synchronized & Volume Compensated The nebulization feature provides a synchronized flow of 7LPM (±1LPM) to power a pneumatic nebulizer connected to the nebulizer outlet. The in-line nebulizer is powered by 100% O , is synchronized with the patient inspiratory phase of each breath, and can be adjusted in increments of 5 minutes for a maximum of 60 minutes.
  • Page 2 Flight 60 Your Partner in Ventilation Setting-Up the Nebulizer 1. Securely attach the nebulizer inlet to the port on the front panel and the nebulizer outlet to the patient circuit 2. On the ventilator front panel, press the Extended button.
